| Key |
PART NO |
ITC |
DESCRIPTION |
QTY |
APP DATE |
LR |
MODEL |
REMARKS |
|
|
|
|
|
|
|
|
|
| 050 |
I9-00093 621-1 |
|
BEARING; FINAL PINION |
1 |
1802- |
|
TRAGA |
|
| 024 |
I8-97079 518-0 |
|
GEAR; PINION,DIFF |
2 |
1802- |
|
TRAGA |
Z = 10 |
| 039 |
I8-94472 099-0 |
|
BEARING; FINAL PINION |
1 |
1802- |
|
TRAGA |
|
| 051 |
I9-41519 162-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.36 |
| 051 |
I9-41519 171-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.54 |
| 051 |
I9-41519 155-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.22 |
| 039 |
I8-94472 099-A |
|
BEARING; FINAL PINION |
1 |
1802- |
|
TRAGA |
(IADG) |
| 051 |
I9-41519 158-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .28 |
| 070 |
I9-00093 074-1 |
|
BEARING; DIFF CAGE |
2 |
1802- |
|
TRAGA |
|
| 126 |
I8-97321 411-1 |
|
COUPLING; DRIVING PINION |
1 |
1802- |
|
TRAGA |
|
| 055 |
I5-41110 014-3 |
|
CARRIER; DIFF |
1 |
1802- |
|
TRAGA |
|
| 051 |
I9-41519 159-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .30 |
| 100 |
I8-97146 826-0 |
|
SEAL; OIL,FINAL PINION |
1 |
1802- |
|
TRAGA |
NOK |
| 051 |
I9-41519 166-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .44 |
| 073 |
I8-97130 386-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1802- |
|
TRAGA |
T=0.10 |
| 060 |
I4-SPART 353-A |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1802- |
|
TRAGA |
(IADG) 43/8 |
| 051 |
I9-41519 168-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .48 |
| 020 |
I5-41562 006-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1802- |
|
TRAGA |
T=1 . 05 |
| 051 |
I9-41519 160-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .32 |
| 051 |
I9-41519 167-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .46 |
| 020 |
I5-41562 005-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1802- |
|
TRAGA |
T=1.00 |
| 051 |
I9-41519 161-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.34 |
| 073 |
I9-41519 109-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1802- |
|
TRAGA |
T=0 . 24 |
| 100 |
I6-97146 826-0 |
|
SEAL; OIL FINAL PINION |
1 |
1802- |
|
|
(IADG) |
| 051 |
I9-41519 154-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.20 |
| 037 |
I8-94376 262-0 |
|
NUT; DRIVING PINION |
1 |
1802- |
|
TRAGA |
M18 LOCK NUT |
| 001 |
I8-98259 600-0 |
|
DRIVE ASM; FINAL,RR |
1 |
1802- |
|
TRAGA |
43/9 |
| 073 |
I9-41519 111-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1802- |
|
TRAGA |
T=0 . 15 |
| 051 |
I9-41519 153-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.18 |
| 051 |
I9-41519 172-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.56 |
| 039 |
I8-94472 100-1 |
|
BEARING; FINAL PINION |
1 |
1802- |
|
TRAGA |
|
| 051 |
I9-41519 170-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.52 |
| 051 |
I9-41519 156-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .24 |
| 051 |
I9-41519 164-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .40 |
| 022 |
I9-41521 044-1 |
|
SPIDER; DIFF PINION |
1 |
1802- |
|
TRAGA |
|
| 072 |
I8-97481 632-1 |
|
CAGE; DIFF |
1 |
1802- |
|
TRAGA |
|
| 060 |
I8-98013 590-1 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1802- |
|
TRAGA |
43/9 |
| 084 |
I8-97038 065-0 |
|
8-97038-065-0 |
10 |
1802- |
|
TRAGA |
M10X17 |
| 042 |
I8-94472 118-0 |
|
COLLAR; DIST,COLLAPSIBLE |
1 |
1802- |
|
TRAGA |
|
| 050 |
I9-00093 621-A |
|
BEARING; FINAL PINION |
1 |
1802- |
|
TRAGA |
(IADG) |
| 051 |
I9-41519 163-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.38 |
| 051 |
I9-41519 165-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .42 |
| 074 |
I9-09878 096-0 |
|
PIN; LK,CROSS PIN |
1 |
1802- |
|
TRAGA |
OD= 5 L=3 5 |
| 100 |
I8-97146 826-0 |
|
SEAL; OIL,FINAL PINION |
1 |
1802- |
|
TRAGA |
|
| 073 |
I8-97130 387-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1802- |
|
TRAGA |
T=0 . 50 |
| 070 |
I9-00093 074-A |
|
BEARING; DIFF CAGE |
2 |
1802- |
|
TRAGA |
(IADG) |
| 060 |
I6-98013 590-0 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1802- |
|
TRAGA |
(IADG) 43/9 |
| 051 |
I9-41519 169-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2.50 |
| 021 |
I8-97079 519-2 |
|
GEAR; SIDE,DIFF |
2 |
1802- |
|
TRAGA |
Z = 17 |
| 051 |
I9-41519 157-1 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1802- |
|
TRAGA |
T=2 .26 |
| 020 |
I5-41562 007-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1802- |
|
TRAGA |
T=1 . 10 |
| 056 |
I8-94376 322-0 |
|
BOLT; BRG CAP |
4 |
1802- |
|
TRAGA |
M12X62 |
