| 024 |
I1-47624 318-0 |
|
PISTON FRT WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 076 |
I1-47414 242-0 |
|
PIPE OIL,BACKWARD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 035 |
I5-09030 026-0 |
|
BOLT; FRT WHEEL CYL |
8 |
2203- |
|
FRR |
(B) M8X22 |
| 025 |
I1-47622 020-1 |
|
SCREW ADJ,FRT WHEEL CYL |
2 |
2203- |
|
FRR |
LH THREAD |
| 029 |
I1-09583 288-0 |
|
SPRING; RETURN,FRT BRK SHOE |
4 |
2203- |
|
FRR |
|
| 015 |
I1-47600 938-0 |
|
CYLINDER WHEEL,FRT BRK |
2 |
2203- |
|
FRR |
|
| 016 |
I8-98050 476-0 |
|
SCREW; BLEEDER,FRT BRK |
4 |
2203- |
|
FRR |
|
| 004 |
I1-88310 501-0 |
|
LINING SET FRT BRK,STANDARD |
1 |
2203- |
|
FRR |
|
| 003 |
I1-47125 802-0 |
|
LINING; FRT BRK SHOE,OVER SIZE |
4 |
2203- |
|
FRR |
|
| 075 |
I1-47414 238-0 |
|
PIPE OIL,FWD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 004 |
I6-88310 501-0 |
|
LINING SET FRT BRK,STANDARD |
1 |
2203- |
|
FRR |
(IADG) |
| 076 |
I1-47414 241-0 |
|
PIPE; OIL,BACKWARD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 035 |
I1-09000 365-0 |
|
BOLT; FRT WHEEL CYL |
4 |
2203- |
|
FRR |
(A) M14X30 |
| 025 |
I1-47622 020-1 |
|
SCREW; ADJ,FRT WHEEL CYL |
2 |
2203- |
|
FRR |
LH THREAD |
| 111 |
I1-09440 002-0 |
|
NUT FLANGE,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 092 |
I9-09956 640-A |
|
GROMMET ADJ HOLE |
4 |
2203- |
|
FRR |
|
| 074 |
I1-47631 071-0 |
|
CONNECTOR FRT BRK |
1 |
2203- |
|
FRR |
|
| 067 |
I1-47150 376-0 |
|
PLATE; BACK,FRT BRK |
1 |
2203- |
|
FRR |
|
| 024 |
I1-47624 318-0 |
|
PISTON; FRT WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 075 |
I1-47414 237-0 |
|
PIPE OIL,FWD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 004 |
I6-88310 501-0 |
|
LINING SET; FRT BRK,STANDARD |
1 |
2203- |
|
FRR |
(IADG) |
| 071 |
I1-09333 033-0 |
|
GROMMET; CHECK HOLE |
4 |
2203- |
|
FRR |
|
| 121 |
I8-94128 727-0 |
|
SCREW LK SPR FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 076 |
I1-47414 242-0 |
|
PIPE; OIL,BACKWARD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 015 |
I1-47600 938-0 |
|
CYLINDER; WHEEL,FRT BRK |
2 |
2203- |
|
FRR |
|
| 004 |
I1-88310 501-0 |
|
LINING SET; FRT BRK,STANDARD |
1 |
2203- |
|
FRR |
|
| 017 |
I8-98050 479-0 |
|
CAP; BLEEDER,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 067 |
I1-47150 375-0 |
|
PLATE; BACK,FRT BRK |
1 |
2203- |
|
FRR |
|
| 026 |
I1-87830 679-0 |
|
CUP SET FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 067 |
I1-47150 376-0 |
|
PLATE BACK,FRT BRK |
1 |
2203- |
|
FRR |
|
| 026 |
I1-87830 679-0 |
|
CUP SET; FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 111 |
I1-09440 002-0 |
|
NUT; FLANGE,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 016 |
I8-98050 476-0 |
|
SCREW BLEEDER,FRT BRK |
4 |
2203- |
|
FRR |
|
| 005 |
I1-88310 502-1 |
|
LINING SET; FRT BRK,OVER SIZE |
1 |
2203- |
|
FRR |
|
| 024 |
I1-47624 319-0 |
|
PISTON FRT WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 074 |
I1-47631 070-0 |
|
CONNECTOR; FRT BRK |
1 |
2203- |
|
FRR |
|
| 005 |
I1-88310 502-1 |
|
LINING SET FRT BRK,OVER SIZE |
1 |
2203- |
|
FRR |
|
| 075 |
I1-47414 237-0 |
|
PIPE; OIL,FWD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 002 |
I1-47125 801-0 |
|
LINING FRT BRK SHOE,STANDARD |
4 |
2203- |
|
FRR |
|
| 035 |
I5-09030 026-0 |
|
BOLT FRT WHEEL CYL |
8 |
2203- |
|
FRR |
(B) M8X22 |
| 029 |
I1-09583 288-0 |
|
SPRING RETURN,FRT BRK SHOE |
4 |
2203- |
|
FRR |
|
| 001 |
I1-47120 624-0 |
|
SHOE; BRK,FRT |
4 |
2203- |
|
FRR |
|
| 025 |
I1-47622 021-1 |
|
SCREW; ADJ,FRT WHEEL CYL |
2 |
2203- |
|
FRR |
RH THREAD |
| 092 |
I9-09956 640-A |
|
GROMMET; ADJ HOLE |
4 |
2203- |
|
FRR |
|
| 101 |
I9-47461 158-0 |
|
PROTECTOR OIL PIPE,FRT BRK |
2 |
2203- |
|
FRR |
|
| 007 |
I1-09732 029-0 |
|
RIVET LINING,FRT BRK |
56 |
2203- |
|
FRR |
|
| 067 |
I1-47150 375-0 |
|
PLATE BACK,FRT BRK |
1 |
2203- |
|
FRR |
|
| 090 |
I5-09030 036-1 |
|
BOLT; CONNECTOR |
2 |
2203- |
|
FRR |
|
| 074 |
I1-47631 070-0 |
|
CONNECTOR FRT BRK |
1 |
2203- |
|
FRR |
|
| 035 |
I1-09000 365-0 |
|
BOLT FRT WHEEL CYL |
4 |
2203- |
|
FRR |
(A) M14X30 |
| 003 |
I1-47125 802-0 |
|
LINING FRT BRK SHOE,OVER SIZE |
4 |
2203- |
|
FRR |
|
| 015 |
I1-47600 939-0 |
|
CYLINDER WHEEL,FRT BRK |
2 |
2203- |
|
FRR |
|
| 017 |
I8-98050 479-0 |
|
CAP BLEEDER,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 074 |
I1-47631 071-0 |
|
CONNECTOR; FRT BRK |
1 |
2203- |
|
FRR |
|
| 002 |
I1-47125 801-0 |
|
LINING; FRT BRK SHOE,STANDARD |
4 |
2203- |
|
FRR |
|
| 015 |
I1-47600 939-0 |
|
CYLINDER; WHEEL,FRT BRK |
2 |
2203- |
|
FRR |
|
| 076 |
I1-47414 241-0 |
|
PIPE OIL,BACKWARD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 120 |
I1-47629 072-0 |
|
SPRING LK,ADJ,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 086 |
I0-91510 614-0 |
|
WASHER LK,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
ID=14.2 |
| 090 |
I5-09030 036-1 |
|
BOLT CONNECTOR |
2 |
2203- |
|
FRR |
|
| 120 |
I1-47629 072-0 |
|
SPRING; LK,ADJ,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 086 |
I0-91510 614-0 |
|
WASHER; LK,FRT WHEEL CYL |
4 |
2203- |
|
FRR |
ID=14.2 |
| 121 |
I8-94128 727-0 |
|
SCREW; LK SPR FRT WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 071 |
I1-09333 033-0 |
|
GROMMET CHECK HOLE |
4 |
2203- |
|
FRR |
|
| 114 |
I9-09874 040-0 |
|
PIN; SPLIT,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 114 |
I9-09874 040-0 |
|
PIN SPLIT,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 025 |
I1-47622 021-1 |
|
SCREW ADJ,FRT WHEEL CYL |
2 |
2203- |
|
FRR |
RH THREAD |
| 007 |
I1-09732 029-0 |
|
RIVET; LINING,FRT BRK |
56 |
2203- |
|
FRR |
|
| 001 |
I1-47120 624-0 |
|
SHOE BRK,FRT |
4 |
2203- |
|
FRR |
|
| 075 |
I1-47414 238-0 |
|
PIPE; OIL,FWD,FRT BRK |
1 |
2203- |
|
FRR |
|
| 024 |
I1-47624 319-0 |
|
PISTON; FRT WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 101 |
I9-47461 158-0 |
|
PROTECTOR; OIL PIPE,FRT BRK |
2 |
2203- |
|
FRR |
|
