| 086 |
I1-09440 003-0 |
|
NUT; FLANGE |
4 |
2203- |
|
FRR |
|
| 094 |
I1-47600 956-0 |
|
CYLINDER; WHEEL,RR BRK |
1 |
2203- |
|
FRR |
FORWARD |
| 157 |
I1-09060 015-0 |
|
BOLT; RR BRK SET |
12 |
2203- |
|
FRR |
M14X45 SQUARE HEAD |
| 094 |
I1-47600 959-0 |
|
CYLINDER; WHEEL,RR BRK |
1 |
2203- |
|
FRR |
BACKWARD |
| 035 |
I1-09333 033-0 |
|
GROMMET; CHECK HOLE |
4 |
2203- |
|
FRR |
|
| 101 |
I1-47622 033-0 |
|
SCREW; ADJ,RR WHEEL CYL |
2 |
2203- |
|
FRR |
M22 LH THREAD |
| 094 |
I1-47600 958-0 |
|
CYLINDER; WHEEL,RR BRK |
1 |
2203- |
|
FRR |
FORWARD |
| 003 |
I1-88310 552-1 |
|
LINING SET; RR BRK,OVER SIZE |
2 |
2203- |
|
FRR |
|
| 157 |
I1-09060 015-0 |
|
BOLT RR BRK SET |
12 |
2203- |
|
FRR |
M14X45 SQUARE HEAD |
| 200 |
I1-47162 050-0 |
|
BOLT |
2 |
2203- |
|
FRR |
|
| 003 |
I1-88310 552-1 |
|
LINING SET RR BRK,OVER SIZE |
2 |
2203- |
|
FRR |
|
| 053 |
I1-47162 050-0 |
|
BOLT LOCK PLATE |
2 |
2203- |
|
FRR |
|
| 007 |
I1-09732 029-0 |
|
RIVET; LINING,RR BRK |
96 |
2203- |
|
FRR |
|
| 096 |
I1-47615 020-0 |
|
SCREW; BLEEDER,RR BRK |
2 |
2203- |
|
FRR |
|
| 095 |
I1-87830 770-0 |
|
CUP SET; RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 001 |
I1-47120 626-0 |
|
SHOE; BRK,RR |
4 |
2203- |
|
FRR |
|
| 103 |
I1-47629 072-0 |
|
SPRING LK,RR WHEEL CYL,ADJ |
4 |
2203- |
|
FRR |
|
| 136 |
I9-09956 640-A |
|
GROMMET |
4 |
2203- |
|
FRR |
|
| 002 |
I1-88310 551-1 |
|
LINING SET; RR BRK,STANDARD |
2 |
2203- |
|
FRR |
|
| 094 |
I1-47600 956-0 |
|
CYLINDER WHEEL,RR BRK |
1 |
2203- |
|
FRR |
FORWARD |
| 111 |
I1-47159 103-0 |
|
COVER WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 026 |
I1-47150 468-0 |
|
PLATE BACK,RR BRK |
1 |
2203- |
|
FRR |
|
| 005 |
I1-47125 803-0 |
|
LINING; RR BRK SHOE,STANDARD |
8 |
2203- |
|
FRR |
|
| 053 |
I1-47162 050-0 |
|
BOLT; LOCK PLATE |
2 |
2203- |
|
FRR |
|
| 103 |
I1-47629 072-0 |
|
SPRING; LK,RR WHEEL CYL,ADJ |
4 |
2203- |
|
FRR |
|
| 055 |
I1-47139 064-0 |
|
PLATE; LK,RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 035 |
I1-09333 033-0 |
|
GROMMET CHECK HOLE |
4 |
2203- |
|
FRR |
|
| 199 |
I1-09400 100-0 |
|
NUT |
2 |
2203- |
|
FRR |
|
| 009 |
I1-09583 271-0 |
|
SPRING RETURN,BRK SHOE |
4 |
2203- |
|
FRR |
|
| 101 |
I1-47622 034-0 |
|
SCREW ADJ,RR WHEEL CYL |
2 |
2203- |
|
FRR |
M22 RH THREAD |
| 026 |
I1-47150 467-0 |
|
PLATE; BACK,RR BRK |
1 |
2203- |
|
FRR |
|
| 199 |
I1-09400 100-0 |
|
NUT |
2 |
2203- |
|
FRR |
|
| 102 |
I1-47624 311-0 |
|
PISTON; REAR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 200 |
I1-47162 050-0 |
|
BOLT |
2 |
2203- |
|
FRR |
|
| 094 |
I1-47600 957-0 |
|
CYLINDER WHEEL,RR BRK |
1 |
2203- |
|
FRR |
BACKWARD |
| 055 |
I1-47139 064-0 |
|
PLATE LK,RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 101 |
I1-47622 034-0 |
|
SCREW; ADJ,RR WHEEL CYL |
2 |
2203- |
|
FRR |
M22 RH THREAD |
| 007 |
I1-09732 029-0 |
|
RIVET LINING,RR BRK |
96 |
2203- |
|
FRR |
|
| 032 |
I0-91510 512-0 |
|
WASHER; LK |
4 |
2203- |
|
FRR |
ID=12.2 |
| 110 |
I8-94128 727-0 |
|
SCREW LOCK SPRING,RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 002 |
I6-88310 551-0 |
|
LINING SET; RR BRK,STANDARD |
2 |
2203- |
|
FRR |
(IADG) |
| 141 |
I9-47461 158-0 |
|
PROTECTOR; RR BRK PIPE |
2 |
2203- |
|
FRR |
|
| 094 |
I1-47600 959-0 |
|
CYLINDER WHEEL,RR BRK |
1 |
2203- |
|
FRR |
BACKWARD |
| 032 |
I0-91510 512-0 |
|
WASHER LK |
4 |
2203- |
|
FRR |
ID=12.2 |
| 163 |
I9-09874 040-0 |
|
PIN; SPLIT,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 096 |
I1-47615 020-0 |
|
SCREW BLEEDER,RR BRK |
2 |
2203- |
|
FRR |
|
| 006 |
I1-47125 804-0 |
|
LINING RR BRK SHOE,OVER SIZE |
8 |
2203- |
|
FRR |
|
| 006 |
I1-47125 804-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
8 |
2203- |
|
FRR |
|
| 005 |
I1-47125 803-0 |
|
LINING RR BRK SHOE,STANDARD |
8 |
2203- |
|
FRR |
|
| 095 |
I1-87830 770-0 |
|
CUP SET RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 136 |
I9-09956 640-A |
|
GROMMET |
4 |
2203- |
|
FRR |
|
| 026 |
I1-47150 468-0 |
|
PLATE; BACK,RR BRK |
1 |
2203- |
|
FRR |
|
| 102 |
I1-47624 311-0 |
|
PISTON REAR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 081 |
I1-09400 100-0 |
|
NUT |
2 |
2203- |
|
FRR |
|
| 141 |
I9-47461 158-0 |
|
PROTECTOR RR BRK PIPE |
2 |
2203- |
|
FRR |
|
| 163 |
I9-09874 040-0 |
|
PIN SPLIT,SHOE HOLD |
4 |
2203- |
|
FRR |
|
| 002 |
I6-88310 551-0 |
|
LINING SET RR BRK,STANDARD |
2 |
2203- |
|
FRR |
(IADG) |
| 086 |
I1-09440 003-0 |
|
NUT FLANGE |
4 |
2203- |
|
FRR |
|
| 111 |
I1-47159 103-0 |
|
COVER; WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 001 |
I1-47120 626-0 |
|
SHOE BRK,RR |
4 |
2203- |
|
FRR |
|
| 094 |
I1-47600 957-0 |
|
CYLINDER; WHEEL,RR BRK |
1 |
2203- |
|
FRR |
BACKWARD |
| 110 |
I8-94128 727-0 |
|
SCREW; LOCK SPRING,RR WHEEL CYL |
4 |
2203- |
|
FRR |
|
| 112 |
I1-47159 232-0 |
|
BOLT WHEEL CYL SETTING |
16 |
2203- |
|
FRR |
M12 |
| 009 |
I1-09583 271-0 |
|
SPRING; RETURN,BRK SHOE |
4 |
2203- |
|
FRR |
|
| 097 |
I1-47619 009-0 |
|
CAP BLEEDER,RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 036 |
I1-47421 815-0 |
|
PIPE OIL,RR BRK |
2 |
2203- |
|
FRR |
|
| 094 |
I1-47600 958-0 |
|
CYLINDER WHEEL,RR BRK |
1 |
2203- |
|
FRR |
FORWARD |
| 101 |
I1-47622 033-0 |
|
SCREW ADJ,RR WHEEL CYL |
2 |
2203- |
|
FRR |
M22 LH THREAD |
| 097 |
I1-47619 009-0 |
|
CAP; BLEEDER,RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 081 |
I1-09400 100-0 |
|
NUT |
2 |
2203- |
|
FRR |
|
| 099 |
I1-47624 309-0 |
|
PISTON; RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 036 |
I1-47421 815-0 |
|
PIPE; OIL,RR BRK |
2 |
2203- |
|
FRR |
|
| 099 |
I1-47624 310-0 |
|
PISTON RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 002 |
I1-88310 551-1 |
|
LINING SET RR BRK,STANDARD |
2 |
2203- |
|
FRR |
|
| 099 |
I1-47624 309-0 |
|
PISTON RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 099 |
I1-47624 310-0 |
|
PISTON; RR WHEEL CYL |
2 |
2203- |
|
FRR |
|
| 026 |
I1-47150 467-0 |
|
PLATE BACK,RR BRK |
1 |
2203- |
|
FRR |
|
| 112 |
I1-47159 232-0 |
|
BOLT; WHEEL CYL SETTING |
16 |
2203- |
|
FRR |
M12 |
