| 106 |
I8-94392 236-0 |
|
PLUG; GLOW PLUG HOLE |
4 |
2203- |
|
FTR |
|
| 201 |
I1-09639 034-0 |
|
GASKET; SLEEVE,INJ PUMP |
4 |
2203- |
|
FTR |
OD=30 |
| 249 |
I8-94391 310-0 |
|
GASKET; CONNECTOR |
1 |
2203- |
|
FTR |
|
| 182 |
I0-28050 845-0 |
|
BOLT; CASE |
4 |
2203- |
|
FTR |
(B) M8X45 FLANGE |
| 266 |
I8-98018 462-0 |
|
SLEEVE ASM; NOZZLE HOLDER |
4 |
2203- |
|
FTR |
|
| 003 |
I8-98260 005-0 |
|
BOLT; CYL HD TO BLOCK |
18 |
2203- |
|
FTR |
(C) M14X115 FLANGE |
| 007 |
I5-11129 006-0 |
|
CUP; SEALING,CYL HEAD |
5 |
2203- |
|
FTR |
(C) OD=16 |
| 071 |
I0-28050 835-0 |
|
BOLT; CAM BRKT |
2 |
2203- |
|
FTR |
M8X35 FLANGE |
| 007 |
I1-09600 016-0 |
|
CUP; SEALING,CYL HEAD |
4 |
2203- |
|
FTR |
(B) OD=25 |
| 007 |
I8-97096 821-0 |
|
CUP; SEALING,CYL HEAD |
5 |
2203- |
|
FTR |
(A) OD=32 |
| 059 |
I8-97381 603-1 |
|
GUIDE; BRIDGE |
8 |
2203- |
|
FTR |
|
| 023 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
10 |
2203- |
|
FTR |
M8 FLANGE |
| 004 |
I8-97376 719-2 |
|
GUIDE; VLV |
16 |
2203- |
|
FTR |
L=57 |
| 007 |
I9-11129 128-0 |
|
CUP; SEALING,CYL HEAD |
7 |
2203- |
|
FTR |
(D) OD=20 |
| 024 |
I8-94322 512-2 |
|
STUD; CM/SHF BRKT |
2 |
2203- |
|
FTR |
(B) M8X54 L=79 |
| 002 |
I8-98288 503-0 |
|
GASKET; CYL HD |
1 |
2203- |
|
FTR |
T=1.575 2-HOLE |
| 005 |
I8-98028 875-0 |
|
SEAT; VLV INSERT |
8 |
2203- |
|
FTR |
(B) ID=31 OD=38 |
| 122 |
I8-97331 360-1 |
|
GASKET; COVER |
1 |
2203- |
|
FTR |
|
| 002 |
I8-98288 502-0 |
|
GASKET; CYL HD |
1 |
2203- |
|
FTR |
T=1.525 1-HOLE |
| 003 |
I8-94399 554-0 |
|
BOLT; CYL HD TO BLOCK |
1 |
2203- |
|
FTR |
(A) M10X73 |
| 014 |
I8-94397 286-0 |
|
STUD; EXH MANIF |
2 |
2203- |
|
FTR |
M10X60 L=75 |
| 001 |
I8-98170 620-0 |
|
HEAD ASM; CYL |
1 |
2203- |
|
FTR |
|
| 168 |
I8-97383 001-1 |
|
HANGER; ENG,FRT |
1 |
2203- |
|
FTR |
(A) |
| 047 |
I0-49140 860-0 |
|
STUD; CYL HD |
2 |
2203- |
|
FTR |
M8X60 L=72 |
| 058 |
I8-97604 916-0 |
|
GASKET; SLEEVE,NOZZLE HOLDER |
4 |
2203- |
|
FTR |
(A) ID=26.4 |
| 024 |
I8-94322 513-2 |
|
STUD; CM/SHF BRKT |
8 |
2203- |
|
FTR |
(A) M8X41 L=66 |
| 247 |
I8-97331 362-1 |
|
CASE; CYL HEAD,C/H COVER |
1 |
2203- |
|
FTR |
|
| 005 |
I8-98028 874-0 |
|
SEAT; VLV INSERT |
8 |
2203- |
|
FTR |
(A) ID=32 OD=38 |
| 025 |
I8-98003 416-0 |
|
PLUG; CYL HD |
1 |
2203- |
|
FTR |
M8X10 |
| 002 |
I8-98288 501-0 |
|
GASKET; CYL HD |
1 |
2203- |
|
FTR |
T=1.475 NON-HOLE |
| 182 |
I0-28050 812-A |
|
BOLT; CASE |
2 |
2203- |
|
FTR |
(A) M8X12 FLANGE |
| 058 |
I8-98004 187-0 |
|
GASKET; SLEEVE,NOZZLE HOLDER |
4 |
2203- |
|
FTR |
(B) ID=26.2 |
| 013 |
I0-28151 020-0 |
|
BOLT; HANGER |
2 |
2203- |
|
FTR |
M10X20 FLANGE |
| 248 |
I8-94390 858-1 |
|
CONNECTOR |
1 |
2203- |
|
FTR |
|
| 003 |
I8-94399 555-0 |
|
BOLT; CYL HD TO BLOCK |
1 |
2203- |
|
FTR |
(B) M10X43 |
