| 527 |
I8-98032 433-1 |
|
TANK; LWR,RADIATOR CORE |
1 |
2203- |
|
FTR |
|
| 064 |
I0-91610 510-0 |
|
WASHER; STAY TO RAD |
2 |
2203- |
|
FTR |
ID=10.5 |
| 092 |
I8-97386 233-0 |
|
BRACKET; FAN GUIDE |
1 |
2203- |
|
FTR |
(B) |
| 211 |
I8-98206 622-3 |
|
HOSE; RAD TO PIPE |
1 |
2203- |
|
FTR |
(B) L=1815 |
| 059 |
I8-97359 052-0 |
|
PIN; SNAP,STAY |
2 |
2203- |
|
FTR |
L=32.6 |
| 220 |
I7-05108 010-A |
|
NUT; CLIP |
2 |
2203- |
|
FTR |
M8 FLANGE |
| 260 |
I7-04508 025-A |
|
BOLT; BRKT |
2 |
2203- |
|
FTR |
M8X20 FLANGE |
| 528 |
I8-98206 626-0 |
|
PLATE; SIDE,RADIATOR CORE |
1 |
2203- |
L |
FTR |
|
| 092 |
I8-97350 997-0 |
|
BRACKET; FAN GUIDE |
1 |
2203- |
|
FTR |
(A) |
| 080 |
I1-21559 481-0 |
|
BOLT; FAN GUIDE |
4 |
2203- |
|
FTR |
(A) M6X16 |
| 062 |
I0-28050 812-A |
|
BOLT; STAY |
2 |
2203- |
|
FTR |
(A) M8X12 FLANGE |
| 115 |
I8-98204 117-0 |
|
BRACKET; FAN GUIDE |
1 |
2203- |
|
FTR |
|
| 074 |
I1-09503 154-2 |
|
WASHER; PL,CUSHION RUBBER |
2 |
2203- |
|
FTR |
ID=11 OD=54 |
| 528 |
I8-98206 627-0 |
|
PLATE; SIDE,RADIATOR CORE |
1 |
2203- |
R |
FTR |
|
| 096 |
I0-28151 020-0 |
|
BOLT; STAY FIX |
2 |
2203- |
|
FTR |
(A) M10X20 FLANGE |
| 001 |
I8-98206 624-0 |
|
RADIATOR ASM |
1 |
2203- |
|
FTR |
|
| 070 |
I8-98010 657-0 |
|
STAY; RAD |
1 |
2203- |
|
FTR |
(B) |
| 117 |
I1-09337 027-0 |
|
RUBBER; MTG,FAN GUIDE |
6 |
2203- |
|
FTR |
OD=32 |
| 089 |
I0-28050 812-A |
|
BOLT |
2 |
2203- |
|
FTR |
(A) M8X12 FLANGE |
| 425 |
I0-28650 825-0 |
|
BOLT; BRKT |
2 |
2203- |
|
FTR |
M8X25 FLANGE |
| 089 |
I1-21469 153-A |
|
BOLT |
2 |
2203- |
|
FTR |
(B) M8X25 W/PL WASHER |
| 259 |
I8-98179 846-0 |
|
BRACKET; RAD STAY |
1 |
2203- |
|
FTR |
(B) |
| 526 |
I8-98107 793-0 |
|
TANK; UPR,RADIATOR CORE |
1 |
2203- |
|
FTR |
|
| 070 |
I8-98018 941-0 |
|
STAY; RAD |
1 |
2203- |
|
FTR |
(A) |
| 232 |
I8-98141 232-0 |
|
COLLAR; DIST,CUSHION RUBBER |
2 |
2203- |
|
FTR |
|
| 078 |
I0-91180 212-0 |
|
NUT; CUSHION RUBBER |
2 |
2203- |
|
FTR |
(B) M12 FLANGE |
| 096 |
I8-94399 669-1 |
|
BOLT; STAY FIX |
2 |
2203- |
|
FTR |
(B) M10X75 FLANGE |
| 051 |
I8-97171 437-A |
|
PLUG; DRAIN |
1 |
2203- |
|
FTR |
W/GASKET |
| 073 |
I1-21467 011-1 |
|
RUBBER; CUSHION,RAD MTG |
2 |
2203- |
|
FTR |
(B) T=24 |
| 080 |
I0-28650 830-0 |
|
BOLT; FAN GUIDE |
3 |
2203- |
|
FTR |
(B) M8X30 FLANGE |
| 002 |
I8-97350 995-0 |
|
GUIDE; FAN |
1 |
2203- |
|
FTR |
|
| 267 |
I1-21467 023-0 |
|
RUBBER; CUSHION |
2 |
2203- |
|
FTR |
(A) |
| 091 |
I1-21469 111-0 |
|
WASHER; PL |
2 |
2203- |
|
FTR |
|
| 079 |
I8-98010 297-A |
|
GUIDE; FAN,RAD |
1 |
2203- |
|
FTR |
|
| 082 |
I8-98006 478-0 |
|
COVER; FAN,RAD |
1 |
2203- |
|
FTR |
|
| 427 |
I1-09470 009-0 |
|
CLIP; FAN GUIDE |
2 |
2203- |
|
FTR |
|
| 075 |
I1-21466 007-3 |
|
BOLT; CUSHION RUBBER,RAD MTG |
2 |
2203- |
|
FTR |
M12X26.5,M10X19 L=86.5 |
| 261 |
I7-05108 010-A |
|
NUT; BRKT |
2 |
2203- |
|
FTR |
M8 FLANGE |
| 073 |
I8-97916 015-0 |
|
RUBBER; CUSHION,RAD MTG |
2 |
2203- |
|
FTR |
(A) |
| 218 |
I7-05108 010-A |
|
NUT; BRKT |
2 |
2203- |
|
FTR |
M8 FLANGE |
| 016 |
I8-98096 226-0 |
|
CAP; RAD |
1 |
2203- |
|
FTR |
|
| 232 |
I8-98141 232-A |
|
COLLAR; DIST,CUSHION RUBBER |
2 |
2203- |
|
FTR |
|
| 138 |
I8-98226 427-0 |
|
BRACKET; CLIP |
1 |
2203- |
|
FTR |
|
| 529 |
I8-98032 435-0 |
|
GASKET; CORE,RADIATOR |
2 |
2203- |
|
FTR |
|
| 092 |
I8-97382 827-2 |
|
BRACKET; FAN GUIDE |
1 |
2203- |
|
FTR |
(C) |
| 078 |
I7-05110 010-A |
|
NUT; CUSHION RUBBER |
2 |
2203- |
|
FTR |
(A) M10 FLANGE |
