| 112 |
I0-50551 232-0 |
|
BOLT; WHEEL CYL SETTING |
4 |
2203- |
|
FTR |
M12X32 W/LK WASHER |
| 097 |
I1-47619 011-0 |
|
CAP; BLEEDER,RR WHEEL CYL |
2 |
2203- |
|
FTR |
OD=12 |
| 099 |
I1-47624 302-0 |
|
PISTON; RR WHEEL CYL |
4 |
2203- |
|
FTR |
|
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 099 |
I1-47624 302-0 |
|
PISTON; RR WHEEL CYL |
4 |
2203- |
|
FTR |
|
| 003 |
I1-88311 354-1 |
|
LINING SET; RR BRK,OVER SIZE |
2 |
2203- |
|
FTR |
|
| 062 |
I1-47169 030-0 |
|
PIN; ADJ CAM SPINDLE,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 096 |
I1-47615 005-0 |
|
SCREW; BLEEDER,RR BRK |
2 |
2203- |
|
FTR |
L=66.5 |
| 053 |
I0-20851 016-0 |
|
BOLT; LOCK PLATE |
2 |
2203- |
|
FTR |
M10X16 |
| 057 |
I1-47169 046-0 |
|
SPRING; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 058 |
I1-47169 034-0 |
|
BOOT; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 006 |
I1-47126 759-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
2203- |
|
FTR |
|
| 009 |
I1-09583 185-2 |
|
SPRING; RETURN,BRK SHOE |
2 |
2203- |
|
FTR |
|
| 095 |
I1-87830 886-0 |
|
CUP SET; RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 094 |
I1-47601 220-0 |
|
CYLINDER; WHEEL,RR BRK |
2 |
2203- |
|
FTR |
|
| 005 |
I1-47126 758-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
2203- |
|
FTR |
|
| 061 |
I1-47169 032-1 |
|
INDICATOR; WEAR,RR BRK SHOE |
4 |
2203- |
|
FTR |
|
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
2203- |
|
FTR |
M10X12 |
| 062 |
I1-47169 030-0 |
|
PIN; ADJ CAM SPINDLE,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 100 |
I1-47621 009-0 |
|
ROD; PUSH,RR WHEEL CYL |
4 |
2203- |
|
FTR |
|
| 061 |
I1-47169 032-1 |
|
INDICATOR; WEAR,RR BRK SHOE |
4 |
2203- |
|
FTR |
|
| 056 |
I1-47169 033-0 |
|
WASHER; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 006 |
I1-47126 759-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
2203- |
|
FTR |
|
| 025 |
I1-47151 458-0 |
|
COVER SET; RR BRK DRUM |
2 |
2203- |
|
FTR |
|
| 096 |
I1-47615 005-0 |
|
SCREW; BLEEDER,RR BRK |
2 |
2203- |
|
FTR |
L=66.5 |
| 008 |
I1-47119 017-1 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
2203- |
|
FTR |
L=73.5 |
| 011 |
I1-47131 038-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
2203- |
|
FTR |
L=106.5 |
| 112 |
I0-50551 232-0 |
|
BOLT; WHEEL CYL SETTING |
4 |
2203- |
|
FTR |
M12X32 W/LK WASHER |
| 060 |
I1-47169 031-0 |
|
COVER; ADJ CAM BOOT,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
80 |
2203- |
|
FTR |
L=18.5 |
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 098 |
I1-09580 019-0 |
|
SPRING; RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 060 |
I1-47169 031-0 |
|
COVER; ADJ CAM BOOT,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 100 |
I1-47621 009-0 |
|
ROD; PUSH,RR WHEEL CYL |
4 |
2203- |
|
FTR |
|
| 004 |
I1-47112 011-0 |
|
BUSHING; BRK SHOE,RR WHEEL |
4 |
2203- |
|
FTR |
|
| 004 |
I1-47112 011-0 |
|
BUSHING; BRK SHOE,RR WHEEL |
4 |
2203- |
|
FTR |
|
| 098 |
I1-09580 019-0 |
|
SPRING; RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 051 |
I1-47165 059-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
2203- |
|
FTR |
(B) |
| 015 |
I1-47116 002-0 |
|
PIN; GUIDE,ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 047 |
I1-47137 112-4 |
|
BRACKET; ANCHOR PIN,RR WHEEL BRK |
2 |
2203- |
|
FTR |
|
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
2203- |
|
FTR |
|
| 047 |
I1-47137 112-4 |
|
BRACKET; ANCHOR PIN,RR WHEEL BRK |
2 |
2203- |
|
FTR |
|
| 095 |
I1-87830 886-0 |
|
CUP SET; RR WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 053 |
I0-20851 016-0 |
|
BOLT; LOCK PLATE |
2 |
2203- |
|
FTR |
M10X16 |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
2203- |
|
FTR |
|
| 008 |
I1-47119 017-1 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
2203- |
|
FTR |
L=73.5 |
| 001 |
I1-47170 441-0 |
|
SHOE; BRK,RR |
4 |
2203- |
|
FTR |
|
| 001 |
I1-47170 441-0 |
|
SHOE; BRK,RR |
4 |
2203- |
|
FTR |
|
| 094 |
I1-47601 220-0 |
|
CYLINDER; WHEEL,RR BRK |
2 |
2203- |
|
FTR |
|
| 025 |
I1-47151 458-0 |
|
COVER SET; RR BRK DRUM |
2 |
2203- |
|
FTR |
|
| 056 |
I1-47169 033-0 |
|
WASHER; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 005 |
I1-47126 758-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
2203- |
|
FTR |
|
| 111 |
I1-47159 080-0 |
|
COVER; WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
80 |
2203- |
|
FTR |
L=18.5 |
| 051 |
I1-47165 059-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
2203- |
|
FTR |
(B) |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
2203- |
|
FTR |
M10X12 |
| 051 |
I1-47165 058-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
2203- |
|
FTR |
(A) |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
2203- |
|
FTR |
|
| 009 |
I1-09583 185-2 |
|
SPRING; RETURN,BRK SHOE |
2 |
2203- |
|
FTR |
|
| 002 |
I1-88311 353-1 |
|
LINING SET; RR BRK,STANDARD |
2 |
2203- |
|
FTR |
|
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
2203- |
|
FTR |
|
| 058 |
I1-47169 034-0 |
|
BOOT; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 002 |
I1-88311 353-1 |
|
LINING SET; RR BRK,STANDARD |
2 |
2203- |
|
FTR |
|
| 097 |
I1-47619 011-0 |
|
CAP; BLEEDER,RR WHEEL CYL |
2 |
2203- |
|
FTR |
OD=12 |
| 111 |
I1-47159 080-0 |
|
COVER; WHEEL CYL |
2 |
2203- |
|
FTR |
|
| 003 |
I1-88311 354-1 |
|
LINING SET; RR BRK,OVER SIZE |
2 |
2203- |
|
FTR |
|
| 011 |
I1-47131 038-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
2203- |
|
FTR |
L=106.5 |
| 015 |
I1-47116 002-0 |
|
PIN; GUIDE,ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 057 |
I1-47169 046-0 |
|
SPRING; ADJ CAM,RR WHEEL BRK |
4 |
2203- |
|
FTR |
|
| 051 |
I1-47165 058-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
2203- |
|
FTR |
(A) |
