| 172 |
I1-37515 127-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(H) |
| 074 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
2203- |
|
FTR |
M14X37 |
| 172 |
I1-37515 074-1 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(D) FTR90 P |
| 008 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
2203- |
|
FTR |
(F) |
| 019 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=1.95 BLUE |
| 022 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
3 |
2203- |
|
FTR |
|
| 001 |
I1-37151 628-1 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=821; FTR90T |
| 025 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
2 |
2203- |
|
FTR |
(B) MT6 STRAIGHT |
| 001 |
I8-98083 013-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(D) L=1084; FTR90P |
| 063 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
2203- |
|
FTR |
M10X35 FLANGE |
| 021 |
I8-97548 974-0 |
|
SEAL; OIL,CENTER BRG |
6 |
2203- |
|
FTR |
|
| 014 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
8 |
2203- |
|
FTR |
|
| 001 |
I8-98069 684-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1366; FTR90P |
| 001 |
I8-98090 992-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1351; FTR90S |
| 023 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
3 |
2203- |
|
FTR |
|
| 172 |
I1-37515 074-1 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(D) FTR90 P |
| 064 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
8 |
2203- |
|
FTR |
M10 FLANGE |
| 056 |
I0-91110 514-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
(A) M14 |
| 060 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
2203- |
|
FTR |
ID=10.5 OD=22 |
| 106 |
I0-90301 406-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
2203- |
|
FTR |
M6 STRAIGHT |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
2203- |
|
FTR |
M10X25 FLANGE |
| 001 |
I8-98069 590-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=1234; FTR90S |
| 025 |
I8-98020 889-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
2203- |
|
FTR |
(A) |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 008 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
2203- |
|
FTR |
(E) |
| 024 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
2 |
2203- |
|
FTR |
(A) |
| 064 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 019 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=2.00 WHITE |
| 128 |
I1-37247 024-0 |
|
SEAL; SLEEVE |
1 |
2203- |
|
FTR |
|
| 225 |
I8-98020 885-0 |
|
YOKE; SLEEVE,PROP SHAFT |
1 |
2203- |
|
FTR |
L=254 |
| 019 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=1.95 BLUE |
| 063 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
8 |
2203- |
|
FTR |
M10X35 FLANGE |
| 172 |
I1-37515 136-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(E) |
| 008 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
2 |
2203- |
|
FTR |
(F) |
| 046 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
2 |
2203- |
|
FTR |
(A) |
| 057 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
8 |
2203- |
|
FTR |
ID=14.2 |
| 052 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
2203- |
|
FTR |
ID=14.2 |
| 025 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
2203- |
|
FTR |
(B) MT6 STRAIGHT; FTR90 P; FTR90 S |
| 074 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
12 |
2203- |
|
FTR |
M14X37 |
| 020 |
I8-97503 902-0 |
|
BEARING ASM; CTR,PROP SHAFT |
3 |
2203- |
|
FTR |
(B) |
| 172 |
I1-37515 135-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(D) FTR90 S |
| 014 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
8 |
2203- |
|
FTR |
|
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 017 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
2 |
2203- |
|
FTR |
PT1/8 ELBOW |
| 021 |
I8-97548 974-0 |
|
SEAL; OIL,CENTER BRG |
6 |
2203- |
|
FTR |
|
| 001 |
I8-98090 991-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1336; FTR90T |
| 022 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
3 |
2203- |
|
FTR |
|
| 023 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
3 |
2203- |
|
FTR |
|
| 014 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
12 |
2203- |
|
FTR |
|
| 172 |
I1-37515 134-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(C) |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 019 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=2.00 WHITE |
| 104 |
I1-09600 064-0 |
|
PLUG; SLEEVE YOKE |
1 |
2203- |
|
FTR |
|
| 052 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
2203- |
|
FTR |
ID=14.2 |
| 056 |
I0-91110 514-0 |
|
NUT; YOKE |
8 |
2203- |
|
FTR |
(A) M14 |
| 017 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
3 |
2203- |
|
FTR |
PT1/8 ELBOW |
| 071 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
M16 FLANGE |
| 057 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
2203- |
|
FTR |
ID=14.2 |
| 001 |
I8-98090 992-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1351; FTR90S |
| 019 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=1.95 BLUE |
| 046 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
2 |
2203- |
|
FTR |
(A) |
| 024 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
2 |
2203- |
|
FTR |
(A) |
| 172 |
I1-37515 102-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(C) FTR90 P; FTR90 S |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
8 |
2203- |
|
FTR |
M10X25 FLANGE |
| 001 |
I8-98180 201-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=584; FTR90P |
| 063 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
8 |
2203- |
|
FTR |
M10X35 FLANGE |
| 009 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
2 |
2203- |
|
FTR |
|
| 025 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
2203- |
|
FTR |
(B) MT6 STRAIGHT; FTR90 P; FTR90 S |
| 008 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
2203- |
|
FTR |
(E) |
| 001 |
I8-98069 618-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(F) L=809; FTR90T |
| 172 |
I1-37515 135-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(D) FTR90 S |
| 106 |
I0-90301 406-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
2203- |
|
FTR |
M6 STRAIGHT |
| 045 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
2203- |
|
FTR |
ID=10.5 OD=22 |
| 019 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=2.05 YELLOW |
| 056 |
I0-91110 514-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
(A) M14 |
| 056 |
I0-91110 514-0 |
|
NUT; YOKE |
8 |
2203- |
|
FTR |
(A) M14 |
| 045 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
2203- |
|
FTR |
ID=10.5 OD=22 |
| 064 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 008 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
2 |
2203- |
|
FTR |
(F) |
| 074 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
2203- |
|
FTR |
M14X37 |
| 025 |
I8-98020 889-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
2203- |
|
FTR |
(A) |
| 051 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
3 |
2203- |
|
FTR |
M30 |
| 225 |
I8-98020 885-0 |
|
YOKE; SLEEVE,PROP SHAFT |
1 |
2203- |
|
FTR |
L=254 |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
8 |
2203- |
|
FTR |
M10X25 FLANGE |
| 057 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
8 |
2203- |
|
FTR |
ID=14.2 |
| 009 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
2 |
2203- |
|
FTR |
|
| 049 |
I0-91110 514-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
(A) M14 |
| 063 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
2203- |
|
FTR |
M10X35 FLANGE |
| 049 |
I0-91110 514-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
(A) M14 |
| 074 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
12 |
2203- |
|
FTR |
M14X37 |
| 172 |
I1-37515 136-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(E) |
| 019 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=2.00 WHITE |
| 128 |
I1-37247 024-0 |
|
SEAL; SLEEVE |
1 |
2203- |
|
FTR |
|
| 001 |
I1-37151 628-1 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=821; FTR90T |
| 001 |
I8-98083 013-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(D) L=1084; FTR90P |
| 064 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
8 |
2203- |
|
FTR |
M10 FLANGE |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
2203- |
|
FTR |
M10X25 FLANGE |
| 057 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
2203- |
|
FTR |
ID=14.2 |
| 001 |
I8-98180 201-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=584; FTR90P |
| 172 |
I1-37515 134-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(C) |
| 019 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=1.95 BLUE |
| 046 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
2203- |
|
FTR |
(B) 2ND |
| 019 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=2.05 YELLOW |
| 001 |
I8-98116 103-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(D) L=1454; FTR90S |
| 001 |
I8-98090 991-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1336; FTR90T |
| 172 |
I1-37515 127-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(H) |
| 017 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
2 |
2203- |
|
FTR |
PT1/8 ELBOW |
| 008 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
2203- |
|
FTR |
(F) |
| 060 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
2203- |
|
FTR |
ID=10.5 OD=22 |
| 071 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
2203- |
|
FTR |
M16 FLANGE |
| 024 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
2203- |
|
FTR |
(B) |
| 046 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
2203- |
|
FTR |
(B) 2ND |
| 025 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
2 |
2203- |
|
FTR |
(B) MT6 STRAIGHT |
| 019 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=2.05 YELLOW |
| 020 |
I8-97503 902-0 |
|
BEARING ASM; CTR,PROP SHAFT |
3 |
2203- |
|
FTR |
(B) |
| 024 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
2203- |
|
FTR |
(B) |
| 001 |
I8-98069 684-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(G) L=1366; FTR90P |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
2203- |
|
FTR |
M10 FLANGE |
| 051 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
3 |
2203- |
|
FTR |
M30 |
| 017 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
3 |
2203- |
|
FTR |
PT1/8 ELBOW |
| 014 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
12 |
2203- |
|
FTR |
|
| 172 |
I1-37515 102-0 |
|
BRACKET; CENTER BRG |
1 |
2203- |
|
FTR |
(C) FTR90 P; FTR90 S |
| 001 |
I8-98069 618-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(F) L=809; FTR90T |
| 001 |
I8-98069 590-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(E) L=1234; FTR90S |
| 019 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
8 |
2203- |
|
FTR |
OD=45.5 T=2.05 YELLOW |
| 019 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT, 1ST |
12 |
2203- |
|
FTR |
OD=45.5 T=2.00 WHITE |
| 104 |
I1-09600 064-0 |
|
PLUG; SLEEVE YOKE |
1 |
2203- |
|
FTR |
|
| 001 |
I8-98116 103-0 |
|
SHAFT; PROP |
1 |
2203- |
|
FTR |
(D) L=1454; FTR90S |
