| Key |
PART NO |
ITC |
DESCRIPTION |
QTY |
APP DATE |
LR |
MODEL |
REMARKS |
|
|
|
|
|
|
|
|
|
| 004 |
I1-09440 098-0 |
|
NUT; PITMAN ARM |
1 |
2203- |
|
FVM |
M36 FLANGE |
| 009 |
I8-98313 151-2 |
|
LINK; DRAG |
1 |
2203- |
|
FVM |
|
| 003 |
I1-09500 056-0 |
|
WASHER; LK,PITMAN ARM |
1 |
2203- |
|
FVM |
ID=36.5 |
| 021 |
I1-09442 028-0 |
|
NUT; LK,JOINT BALL |
2 |
2203- |
|
FVM |
M24 SLOTTED |
| 011 |
I8-98160 122-0 |
|
NIPPLE; GREASE,DRAG LINK |
2 |
2203- |
|
FVM |
|
| 021 |
I1-09442 028-0 |
|
NUT; LK,JOINT BALL |
2 |
2203- |
|
FVM |
M24 SLOTTED |
| 001 |
I8-98315 881-A |
|
ARM; PITMAN,STRG |
1 |
2203- |
|
FVM |
|
| 013 |
I1-43159 134-0 |
|
BOOT; DRAG LINK |
2 |
2203- |
|
FVM |
|
| 036 |
I0-81125 035-0 |
|
PIN; SPLIT,DRAG LINK |
2 |
2203- |
|
FVM |
OD=4.6 L=35 |
| 036 |
I0-81125 035-0 |
|
PIN; SPLIT,DRAG LINK |
2 |
2203- |
|
FVM |
OD=4.6 L=35 |
| 001 |
I8-98315 881-A |
|
ARM; PITMAN,STRG |
1 |
2203- |
|
FVM |
|
| 011 |
I8-98160 122-0 |
|
NIPPLE; GREASE,DRAG LINK |
2 |
2203- |
|
FVM |
|
| 009 |
I8-98313 151-2 |
|
LINK; DRAG |
1 |
2203- |
|
FVM |
|
| 003 |
I1-09500 056-0 |
|
WASHER; LK,PITMAN ARM |
1 |
2203- |
|
FVM |
ID=36.5 |
| 004 |
I1-09440 098-0 |
|
NUT; PITMAN ARM |
1 |
2203- |
|
FVM |
M36 FLANGE |
| 013 |
I1-43159 134-0 |
|
BOOT; DRAG LINK |
2 |
2203- |
|
FVM |
|
