2-26 | MANUAL TRANSMISSION GEAR
GIGA E4
GIGA FVR E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 050 | IE-43045 440-0 | GEAR; 2ND,MAINSHAFT | 1 | 2203- | FVR | |||
| 473 | IE-55565 090-0 | BEARING; INPUT SHAFT | 1 | 2203- | FVR | |||
| 014 | IE-33157 370-0 | BEARING; NEEDLE,5TH | 2 | 2203- | FVR | |||
| 096 | IE-43085 500-0 | GEAR; COUNTER DRIVE | 1 | 2203- | FVR | |||
| 105 | IE-43085 470-0 | GEAR; 3RD,COUNTER | 1 | 2203- | FVR | |||
| 296 | IE-33157 190-0 | WASHER; THRUST | 1 | 2203- | FVR | (B) | ||
| 033 | IE-33157 220-0 | BEARING; NEEDLE,3RD GEAR | 2 | 2203- | FVR | |||
| 190 | IE-10706 000-0 | BALL; LK,REV SHAFT | 1 | 2203- | FVR | |||
| 013 | IE-43014 770-0 | GEAR; 5TH,MAINSHAFT | 1 | 2203- | FVR | |||
| 325 | IE-33156 810-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.004 | ||
| 320 | IE-33029 600-0 | HUB; CLU,4TH & 3RD | 1 | 2203- | FVR | |||
| 070 | IE-43045 450-0 | GEAR; 1ST,MAINSHAFT | 1 | 2203- | FVR | |||
| 087 | IE-10706 000-0 | BALL; THRUST WASHER | 2 | 2203- | FVR | |||
| 058 | IE-33048 200-0 | HUB; CLU,REV | 1 | 2203- | FVR | |||
| 075 | IE-71078 700-0 | BEARING; MAINSHAFT | 1 | 2203- | FVR | |||
| 030 | IE-43040 980-0 | GEAR; 4TH,MAINSHAFT | 1 | 2203- | FVR | |||
| 325 | IE-33156 810-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.004 | ||
| 087 | IE-10706 000-0 | BALL; THRUST WASHER | 2 | 2203- | FVR | |||
| 325 | IE-33156 820-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.007 | ||
| 286 | IE-33039 100-0 | NUT; LK,MAINSHAFT | 1 | 2203- | FVR | |||
| 282 | IE-86190 000-0 | SYNCHRONIZER; 5TH & 6TH | 1 | 2203- | FVR | |||
| 059 | IE-33048 100-0 | GEAR; REV MAINSHAFT | 1 | 2203- | FVR | |||
| 108 | IE-43085 910-0 | SHAFT; COUNTER | 1 | 2203- | FVR | |||
| 252 | IE-33156 760-0 | SPACER | 1 | 2203- | FVR | (C) | ||
| 296 | IE-33157 270-0 | WASHER; THRUST | 1 | 2203- | FVR | (A) | ||
| 252 | IE-33156 760-0 | SPACER | 1 | 2203- | FVR | (C) | ||
| 050 | IE-43045 440-0 | GEAR; 2ND,MAINSHAFT | 1 | 2203- | FVR | |||
| 296 | IE-33157 190-0 | WASHER; THRUST | 1 | 2203- | FVR | (B) | ||
| 473 | IE-55565 090-0 | BEARING; INPUT SHAFT | 1 | 2203- | FVR | |||
| 319 | IE-33048 300-0 | CLUTCH; SLIDING | 1 | 2203- | FVR | |||
| 325 | IE-43009 770-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.040 | ||
| 448 | IE-79340 000-0 | SYNCHRONIZER ASM; 1ST & 2ND | 1 | 2203- | FVR | |||
| 058 | IE-33048 200-0 | HUB; CLU,REV | 1 | 2203- | FVR | |||
| 110 | IE-33157 520-0 | RING; SNAP,COUNTER BRG | 1 | 2203- | FVR | (B) | ||
| 280 | IE-43014 670-0 | CUP; SYN | 2 | 2203- | FVR | (A) | ||
| 296 | IE-33157 270-0 | WASHER; THRUST | 1 | 2203- | FVR | (A) | ||
| 280 | IE-43014 670-0 | CUP; SYN | 2 | 2203- | FVR | (A) | ||
| 036 | IE-43040 570-0 | GEAR; 3RD,MAINSHAFT | 1 | 2203- | FVR | |||
| 084 | IE-55570 080-0 | BEARING; COUNTER SHAFT,FRT | 1 | 2203- | FVR | |||
| 033 | IE-33157 220-0 | BEARING; NEEDLE,3RD GEAR | 2 | 2203- | FVR | |||
| 036 | IE-43040 570-0 | GEAR; 3RD,MAINSHAFT | 1 | 2203- | FVR | |||
| 109 | IE-55565 110-0 | BEARING; COUNTER SHAFT,RR | 1 | 2203- | FVR | |||
| 449 | IE-86180 000-0 | SYNCHRONIZER ASM; 3RD & 4TH | 1 | 2203- | FVR | |||
| 109 | IE-55565 110-0 | BEARING; COUNTER SHAFT,RR | 1 | 2203- | FVR | |||
| 049 | IE-33157 030-0 | BEARING; NEEDLE,2ND GEAR | 2 | 2203- | FVR | |||
| 325 | IE-33156 820-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.007 | ||
| 190 | IE-10706 000-0 | BALL; LK,REV SHAFT | 1 | 2203- | FVR | |||
| 306 | IE-33157 170-0 | RING; SNAP,MAINSHAFT | 2 | 2203- | FVR | (E) | ||
| 325 | IE-33156 840-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.020 | ||
| 325 | IE-33156 830-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.010 | ||
| 313 | IE-33157 030-0 | BEARING; NEEDLE,LOW GEAR | 2 | 2203- | FVR | |||
| 320 | IE-33029 600-0 | HUB; CLU,4TH & 3RD | 1 | 2203- | FVR | |||
| 030 | IE-43040 980-0 | GEAR; 4TH,MAINSHAFT | 1 | 2203- | FVR | |||
| 104 | IE-43085 480-0 | GEAR; 4TH,COUNTER | 1 | 2203- | FVR | |||
| 082 | IE-33027 200-0 | SHAFT; MAIN,TRANS | 1 | 2203- | FVR | |||
| 049 | IE-33157 030-0 | BEARING; NEEDLE,2ND GEAR | 2 | 2203- | FVR | |||
| 082 | IE-33027 200-0 | SHAFT; MAIN,TRANS | 1 | 2203- | FVR | |||
| 286 | IE-33039 100-0 | NUT; LK,MAINSHAFT | 1 | 2203- | FVR | |||
| 471 | IE-33056 900-0 | SHAFT; INPUT | 1 | 2203- | FVR | |||
| 342 | IE-33010 600-0 | FLANGE; OUTPUT | 1 | 2203- | FVR | OD=150MM | ||
| 084 | IE-55570 080-0 | BEARING; COUNTER SHAFT,FRT | 1 | 2203- | FVR | |||
| 448 | IE-79340 000-0 | SYNCHRONIZER ASM; 1ST & 2ND | 1 | 2203- | FVR | |||
| 135 | IE-33010 500-0 | GEAR; REV IDLER | 1 | 2203- | FVR | |||
| 075 | IE-71078 700-0 | BEARING; MAINSHAFT | 1 | 2203- | FVR | |||
| 306 | IE-33157 280-0 | RING; SNAP,MAINSHAFT | 1 | 2203- | FVR | (C) | ||
| 306 | IE-33157 250-0 | RING; SNAP,MAINSHAFT | 1 | 2203- | FVR | (D) | ||
| 342 | IE-33057 200-0 | FLANGE; OUTPUT | 1 | 2203- | FVR | OD=170MM | ||
| 108 | IE-43085 910-0 | SHAFT; COUNTER | 1 | 2203- | FVR | |||
| 296 | IE-43043 720-0 | WASHER; THRUST | 1 | 2203- | FVR | (C) | ||
| 468 | IE-33027 100-0 | HUB; CLU,5TH & 6TH | 1 | 2203- | FVR | |||
| 306 | IE-33157 170-0 | RING; SNAP,MAINSHAFT | 2 | 2203- | FVR | (E) | ||
| 110 | IE-33156 860-0 | RING; SNAP,COUNTER BRG | 1 | 2203- | FVR | (A) | ||
| 105 | IE-43085 470-0 | GEAR; 3RD,COUNTER | 1 | 2203- | FVR | |||
| 132 | IE-33026 800-0 | SHAFT; REV | 1 | 2203- | FVR | |||
| 282 | IE-86190 000-0 | SYNCHRONIZER; 5TH & 6TH | 1 | 2203- | FVR | |||
| 280 | IE-43080 330-0 | CUP; SYN | 2 | 2203- | FVR | (B) | ||
| 296 | IE-43043 720-0 | WASHER; THRUST | 1 | 2203- | FVR | (C) | ||
| 110 | IE-33157 520-0 | RING; SNAP,COUNTER BRG | 1 | 2203- | FVR | (B) | ||
| 432 | IE-41240 750-0 | BEARING; NEEDLE,4TH | 2 | 2203- | FVR | |||
| 014 | IE-33157 370-0 | BEARING; NEEDLE,5TH | 2 | 2203- | FVR | |||
| 306 | IE-33157 280-0 | RING; SNAP,MAINSHAFT | 1 | 2203- | FVR | (C) | ||
| 325 | IE-33156 840-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.020 | ||
| 449 | IE-86180 000-0 | SYNCHRONIZER ASM; 3RD & 4TH | 1 | 2203- | FVR | |||
| 129 | IE-33156 740-0 | BEARING; NEEDLE,IDLER | 2 | 2203- | FVR | |||
| 314 | IE-33049 400-0 | BEARING; NEEDLE,REV GEAR | 1 | 2203- | FVR | |||
| 110 | IE-33156 860-0 | RING; SNAP,COUNTER BRG | 1 | 2203- | FVR | (A) | ||
| 313 | IE-33157 030-0 | BEARING; NEEDLE,LOW GEAR | 2 | 2203- | FVR | |||
| 135 | IE-33010 500-0 | GEAR; REV IDLER | 1 | 2203- | FVR | |||
| 284 | IE-33156 870-0 | WASHER; COUNTER SHAFT | 1 | 2203- | FVR | |||
| 059 | IE-33048 100-0 | GEAR; REV MAINSHAFT | 1 | 2203- | FVR | |||
| 104 | IE-43085 480-0 | GEAR; 4TH,COUNTER | 1 | 2203- | FVR | |||
| 129 | IE-33156 740-0 | BEARING; NEEDLE,IDLER | 2 | 2203- | FVR | |||
| 097 | IE-43085 490-0 | GEAR; 5TH,COUNTER | 1 | 2203- | FVR | |||
| 280 | IE-43080 330-0 | CUP; SYN | 2 | 2203- | FVR | (B) | ||
| 132 | IE-33026 800-0 | SHAFT; REV | 1 | 2203- | FVR | |||
| 432 | IE-41240 750-0 | BEARING; NEEDLE,4TH | 2 | 2203- | FVR | |||
| 342 | IE-33010 600-0 | FLANGE; OUTPUT | 1 | 2203- | FVR | OD=150MM | ||
| 284 | IE-33156 870-0 | WASHER; COUNTER SHAFT | 1 | 2203- | FVR | |||
| 314 | IE-33049 400-0 | BEARING; NEEDLE,REV GEAR | 1 | 2203- | FVR | |||
| 342 | IE-33057 200-0 | FLANGE; OUTPUT | 1 | 2203- | FVR | OD=170MM | ||
| 468 | IE-33027 100-0 | HUB; CLU,5TH & 6TH | 1 | 2203- | FVR | |||
| 471 | IE-33056 900-0 | SHAFT; INPUT | 1 | 2203- | FVR | |||
| 393 | IE-55570 020-0 | BEARING; MAINSHAFT END | 1 | 2203- | FVR | |||
| 325 | IE-43009 770-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.040 | ||
| 393 | IE-55570 020-0 | BEARING; MAINSHAFT END | 1 | 2203- | FVR | |||
| 013 | IE-43014 770-0 | GEAR; 5TH,MAINSHAFT | 1 | 2203- | FVR | |||
| 325 | IE-33156 830-0 | SHIM; COUNTER SHAFT BRG | 1 | 2203- | FVR | T=0.010 | ||
| 070 | IE-43045 450-0 | GEAR; 1ST,MAINSHAFT | 1 | 2203- | FVR | |||
| 097 | IE-43085 490-0 | GEAR; 5TH,COUNTER | 1 | 2203- | FVR | |||
| 306 | IE-33157 250-0 | RING; SNAP,MAINSHAFT | 1 | 2203- | FVR | (D) | ||
| 096 | IE-43085 500-0 | GEAR; COUNTER DRIVE | 1 | 2203- | FVR | |||
| 319 | IE-33048 300-0 | CLUTCH; SLIDING | 1 | 2203- | FVR |
