2-85 | POWER TAKE OFF CONTROL
GIGA E4
GIGA FVZ E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 015 | I1-79996 092-0 | LEVER ASM; PTO CONT | 1 | 2203- | FVZ | (A) | ||
| 015 | I1-79996 092-0 | LEVER ASM; PTO CONT | 1 | 2203- | FVZ | (A) | ||
| 060 | I0-28650 820-0 | BOLT; CLIP FIX | 1 | 2203- | FVZ | M8X20 FLANGE | ||
| 153 | I0-91180 108-0 | NUT; CLIP | 1 | 2203- | FVZ | M8 FLANGE | ||
| 208 | I0-28650 830-0 | BOLT; BRKT,AIR PIPE | 1 | 2203- | FVZ | M8X30 FLANGE | ||
| 208 | I0-28650 830-0 | BOLT; BRKT,AIR PIPE | 1 | 2203- | FVZ | M8X30 FLANGE | ||
| 153 | I0-91180 108-0 | NUT; CLIP | 1 | 2203- | FVZ | M8 FLANGE | ||
| 062 | I1-09700 813-0 | CLIP; PIPE,AIR | 1 | 2203- | FVZ | ID=13 H=18 L=20 | ||
| 303 | I8-98353 156-0 | BRACKET; CLIP | 1 | 2203- | FVZ | |||
| 003 | I8-94279 207-0 | BOLT; BRKT,DUMP CONT LEVER | 6 | 2203- | FVZ | M8X20.5 W/LK&PL WASHER | ||
| 004 | I8-98060 621-0 | BRACKET; PTO CONT | 1 | 2203- | FVZ | FVZ MIXER | ||
| 015 | I1-79907 048-1 | LEVER ASM; PTO CONT | 1 | 2203- | FVZ | (B) FVZ MIXER | ||
| 004 | I8-98060 621-0 | BRACKET; PTO CONT | 1 | 2203- | FVZ | FVZ MIXER | ||
| 003 | I8-94279 207-0 | BOLT; BRKT,DUMP CONT LEVER | 3 | 2203- | FVZ | M8X20.5 W/LK&PL WASHER | ||
| 209 | I0-91180 108-0 | NUT; BRKT,AIR PIPE | 1 | 2203- | FVZ | M8 FLANGE | ||
| 015 | I1-79907 048-1 | LEVER ASM; PTO CONT | 1 | 2203- | FVZ | (B) FVZ MIXER | ||
| 182 | I0-92124 306-0 | CONNECTOR; FLARE | 1 | 2203- | FVZ | M12 & PT1/8 | ||
| 182 | I0-92124 306-0 | CONNECTOR; FLARE | 1 | 2203- | FVZ | M12 & PT1/8 | ||
| 209 | I0-91180 108-0 | NUT; BRKT,AIR PIPE | 1 | 2203- | FVZ | M8 FLANGE | ||
| 060 | I0-28650 820-0 | BOLT; CLIP FIX | 1 | 2203- | FVZ | M8X20 FLANGE | ||
| 003 | I8-94279 207-0 | BOLT; BRKT,DUMP CONT LEVER | 6 | 2203- | FVZ | M8X20.5 W/LK&PL WASHER | ||
| 003 | I8-94279 207-0 | BOLT; BRKT,DUMP CONT LEVER | 3 | 2203- | FVZ | M8X20.5 W/LK&PL WASHER | ||
| 048 | I8-98330 429-0 | HOSE; FLEX,PTO | 1 | 2203- | FVZ | L=640 | ||
| 048 | I8-98330 429-0 | HOSE; FLEX,PTO | 1 | 2203- | FVZ | L=640 | ||
| 303 | I8-98353 156-0 | BRACKET; CLIP | 1 | 2203- | FVZ | |||
| 062 | I1-09700 813-0 | CLIP; PIPE,AIR | 1 | 2203- | FVZ | ID=13 H=18 L=20 |
