| 009 |
I8-98332 611-0 |
|
PIN; WHEEL,RR AXLE |
20 |
2203- |
|
FVZ |
M22X98 RH THREAD |
| 037 |
I1-09812 233-0 |
|
BEARING; HUB INNER,RR AXLE |
2 |
2203- |
|
FVZ |
|
| 008 |
I8-98128 135-A |
|
HUB; RR AXLE |
2 |
2203- |
|
FVZ |
|
| 025 |
I8-98146 166-0 |
|
SHAFT; AXLE,RR |
1 |
2203- |
|
FVZ |
L=990 |
| 021 |
I9-09854 112-0 |
|
WASHER; LK,BRG NUT |
2 |
2203- |
|
FVZ |
ID=88 |
| 076 |
I8-98149 153-0 |
|
NUT; RR BRK ASM SETTING |
16 |
2203- |
|
FVZ |
M14 FLANGE |
| 021 |
I9-09854 112-0 |
|
WASHER; LK,BRG NUT |
2 |
2203- |
|
FVZ |
ID=88 |
| 025 |
I8-98146 166-0 |
|
SHAFT; AXLE,RR |
1 |
2203- |
|
FVZ |
L=990 |
| 024 |
I0-28650 616-0 |
|
BOLT; LK WASHER |
6 |
2203- |
|
FVZ |
M6X16 FLANGE |
| 074 |
I8-98353 031-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
2203- |
|
FVZ |
(A) M14X50 FLANGE |
| 015 |
I1-09812 232-0 |
|
BEARING; HUB OUTER,RR AXLE |
2 |
2203- |
|
FVZ |
|
| 043 |
I1-09587 057-0 |
|
RING; SNAP,HUB SEAL,RR AXLE |
2 |
2203- |
|
FVZ |
OD=179 |
| 071 |
I0-91510 816-0 |
|
WASHER; LK,FINAL DRIVE SETTING |
12 |
2203- |
|
FVZ |
ID=16.2 |
| 074 |
I8-98353 031-0 |
|
BOLT; RR BRK ASM SETTING |
16 |
2203- |
|
FVZ |
(A) M14X50 FLANGE |
| 015 |
I1-09812 232-A |
|
BEARING; HUB OUTER,RR AXLE |
2 |
2203- |
|
FVZ |
(IADG) |
| 049 |
I8-97656 775-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(C) FORWARD; SPLIT TYPE |
| 025 |
I8-98146 167-0 |
|
SHAFT; AXLE,RR |
1 |
2203- |
|
FVZ |
L=1110 |
| 049 |
I8-97532 236-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(A) FORWARD |
| 060 |
I1-09893 011-1 |
|
BREATHER; RR AXLE CASE |
2 |
2203- |
|
FVZ |
|
| 038 |
I1-09625 350-0 |
|
SEAL; OIL,RR HUB,INNER |
2 |
2203- |
|
FVZ |
|
| 009 |
I8-98332 611-0 |
|
PIN; WHEEL,RR AXLE |
20 |
2203- |
|
FVZ |
M22X98 RH THREAD |
| 063 |
I1-09604 022-0 |
|
PLUG; OIL FILLER,AXLE CASE |
1 |
2203- |
|
FVZ |
M24X17 FLANGE |
| 067 |
I0-20951 640-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
2203- |
|
FVZ |
(B) M16X40 |
| 049 |
I8-97656 776-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(D) REARWARD; SPLIT TYPE |
| 059 |
I1-09623 179-0 |
|
GASKET; DRAIN PLUG |
1 |
2203- |
|
FVZ |
ID=26.8 |
| 037 |
I1-09812 233-0 |
|
BEARING; HUB INNER,RR AXLE |
2 |
2203- |
|
FVZ |
|
| 067 |
I0-20951 640-0 |
|
BOLT; FINAL DRIVE SETTING |
7 |
2203- |
|
FVZ |
(B) M16X40 |
| 049 |
I8-97656 776-2 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(D) REARWARD; SPLIT TYPE |
| 025 |
I8-98146 167-0 |
|
SHAFT; AXLE,RR |
1 |
2203- |
|
FVZ |
L=1110 |
| 038 |
I1-09625 350-0 |
|
SEAL; OIL,RR HUB,INNER |
2 |
2203- |
|
FVZ |
|
| 071 |
I0-91510 816-0 |
|
WASHER; LK,FINAL DRIVE SETTING |
12 |
2203- |
|
FVZ |
ID=16.2 |
| 064 |
I1-09623 179-0 |
|
GASKET; OIL FILLER,AXLE CASE |
1 |
2203- |
|
FVZ |
ID=26.8 |
| 064 |
I1-09623 179-0 |
|
GASKET; OIL FILLER,AXLE CASE |
1 |
2203- |
|
FVZ |
ID=26.8 |
| 067 |
I0-20951 640-0 |
|
BOLT; FINAL DRIVE SETTING |
7 |
2203- |
|
FVZ |
(B) M16X40 |
| 024 |
I0-28650 616-0 |
|
BOLT; LK WASHER |
6 |
2203- |
|
FVZ |
M6X16 FLANGE |
| 059 |
I1-09623 179-0 |
|
GASKET; DRAIN PLUG |
1 |
2203- |
|
FVZ |
ID=26.8 |
| 043 |
I1-09587 057-0 |
|
RING; SNAP,HUB SEAL,RR AXLE |
2 |
2203- |
|
FVZ |
OD=179 |
| 020 |
I8-97551 183-0 |
|
NUT; BRG,RR HUB |
2 |
2203- |
|
FVZ |
M88 |
| 049 |
I8-97532 238-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(B) REARWARD |
| 076 |
I8-98149 153-0 |
|
NUT; RR BRK ASM SETTING |
16 |
2203- |
|
FVZ |
M14 FLANGE |
| 049 |
I8-97656 775-1 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(C) FORWARD; SPLIT TYPE |
| 074 |
I8-98353 031-0 |
|
BOLT; RR BRK ASM SETTING |
16 |
2203- |
|
FVZ |
(A) M14X50 FLANGE |
| 015 |
I1-09812 232-A |
|
BEARING; HUB OUTER,RR AXLE |
2 |
2203- |
|
FVZ |
(IADG) |
| 049 |
I8-97532 238-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(B) REARWARD |
| 001 |
I8-98085 728-A |
|
DRUM; BRK,RR |
2 |
2203- |
|
FVZ |
|
| 058 |
I1-09604 023-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
2203- |
|
FVZ |
M24X17 FLANGE |
| 067 |
I0-10956 670-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
2203- |
|
FVZ |
(A) M16X70 |
| 067 |
I0-10956 670-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
2203- |
|
FVZ |
(A) M16X70 |
| 016 |
I1-09625 444-1 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
2203- |
|
FVZ |
|
| 067 |
I0-20951 640-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
2203- |
|
FVZ |
(B) M16X40 |
| 033 |
I0-91510 814-0 |
|
WASHER; AXLE SHAFT |
20 |
2203- |
|
FVZ |
ID=14.2 |
| 020 |
I8-97551 183-0 |
|
NUT; BRG,RR HUB |
2 |
2203- |
|
FVZ |
M88 |
| 033 |
I0-91510 814-0 |
|
WASHER; AXLE SHAFT |
20 |
2203- |
|
FVZ |
ID=14.2 |
| 037 |
I1-09812 233-A |
|
BEARING; HUB INNER,RR AXLE |
2 |
2203- |
|
FVZ |
(IADG) |
| 063 |
I1-09604 022-0 |
|
PLUG; OIL FILLER,AXLE CASE |
1 |
2203- |
|
FVZ |
M24X17 FLANGE |
| 016 |
I1-09625 444-1 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
2203- |
|
FVZ |
|
| 037 |
I1-09812 233-A |
|
BEARING; HUB INNER,RR AXLE |
2 |
2203- |
|
FVZ |
(IADG) |
| 030 |
I1-09000 582-0 |
|
BOLT; HUB TO AXLE SHAFT |
20 |
2203- |
|
FVZ |
M14X58 |
| 015 |
I1-09812 232-0 |
|
BEARING; HUB OUTER,RR AXLE |
2 |
2203- |
|
FVZ |
|
| 074 |
I8-98353 031-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
2203- |
|
FVZ |
(A) M14X50 FLANGE |
| 001 |
I8-98085 728-A |
|
DRUM; BRK,RR |
2 |
2203- |
|
FVZ |
|
| 030 |
I1-09000 582-0 |
|
BOLT; HUB TO AXLE SHAFT |
20 |
2203- |
|
FVZ |
M14X58 |
| 058 |
I1-09604 023-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
2203- |
|
FVZ |
M24X17 FLANGE |
| 060 |
I1-09893 011-1 |
|
BREATHER; RR AXLE CASE |
2 |
2203- |
|
FVZ |
|
| 008 |
I8-98128 135-A |
|
HUB; RR AXLE |
2 |
2203- |
|
FVZ |
|
| 049 |
I8-97532 236-0 |
|
CASE; RR AXLE |
1 |
2203- |
|
FVZ |
(A) FORWARD |
