| 195 |
I8-98172 673-1 |
|
RUBBER; CUSHION,TANK CARRIER |
2 |
2203- |
|
GXZ |
|
| 488 |
I0-04750 300-0 |
|
HOSE; RUBBER |
1 |
2203- |
|
GXZ |
L=340 SERVICED BY L=3000 |
| 001 |
I1-87412 051-0 |
|
TANK; FUEL |
1 |
2203- |
|
GXZ |
514X685X625 200L |
| 045 |
I0-28851 445-0 |
|
BOLT; BRKT,FUEL TANK |
8 |
2203- |
|
GXZ |
M14X45 FLANGE |
| 040 |
I8-98240 574-0 |
|
BELT; SUPPORT,FUEL TANK |
2 |
2203- |
|
GXZ |
|
| 011 |
I0-92002 418-0 |
|
PLUG; DRAIN,FUEL TANK |
1 |
2203- |
|
GXZ |
M18X12 |
| 025 |
I1-22440 057-2 |
|
CAP; FILLER,FUEL TANK |
1 |
2203- |
|
GXZ |
(B) |
| 040 |
I8-98240 574-0 |
|
BELT; SUPPORT,FUEL TANK |
2 |
2203- |
|
GXZ |
|
| 049 |
I0-91110 514-0 |
|
NUT; BRKT |
8 |
2203- |
|
GXZ |
M14 |
| 025 |
I1-22440 056-0 |
|
CAP; FILLER,FUEL TANK |
1 |
2203- |
|
GXZ |
(A) |
| 043 |
I8-97499 204-0 |
|
BRACKET; FUEL TANK |
2 |
2203- |
|
GXZ |
|
| 025 |
I1-22440 057-2 |
|
CAP; FILLER,FUEL TANK |
1 |
2203- |
|
GXZ |
(B) |
| 042 |
I0-91110 510-0 |
|
NUT; SUPPORT BELT |
4 |
2203- |
|
GXZ |
M10 |
| 003 |
I8-98217 749-0 |
|
UNIT; FUEL TANK,SUB |
1 |
2203- |
|
GXZ |
|
| 008 |
I8-98030 453-0 |
|
GASKET; DRAIN PLUG,FUEL TANK |
1 |
2203- |
|
GXZ |
ID=18.2 T=1.6 |
| 049 |
I0-91110 514-0 |
|
NUT; BRKT |
8 |
2203- |
|
GXZ |
M14 |
| 045 |
I0-28851 445-0 |
|
BOLT; BRKT,FUEL TANK |
8 |
2203- |
|
GXZ |
M14X45 FLANGE |
| 011 |
I0-92002 418-0 |
|
PLUG; DRAIN,FUEL TANK |
1 |
2203- |
|
GXZ |
M18X12 |
| 195 |
I8-98172 673-1 |
|
RUBBER; CUSHION,TANK CARRIER |
2 |
2203- |
|
GXZ |
|
| 042 |
I0-91110 510-0 |
|
NUT; SUPPORT BELT |
4 |
2203- |
|
GXZ |
M10 |
| 003 |
I8-98217 749-0 |
|
UNIT; FUEL TANK,SUB |
1 |
2203- |
|
GXZ |
|
| 019 |
I8-98299 580-0 |
|
GASKET; FUEL TANK UNIT |
1 |
2203- |
|
GXZ |
ID=54.5 |
| 038 |
I1-22553 039-1 |
|
INSULATION; SUPPORT BELT |
2 |
2203- |
|
GXZ |
L=1156 |
| 038 |
I1-22553 039-1 |
|
INSULATION; SUPPORT BELT |
2 |
2203- |
|
GXZ |
L=1156 |
| 008 |
I8-98030 453-0 |
|
GASKET; DRAIN PLUG,FUEL TANK |
1 |
2203- |
|
GXZ |
ID=18.2 T=1.6 |
| 001 |
I1-87412 051-0 |
|
TANK; FUEL |
1 |
2203- |
|
GXZ |
514X685X625 200L |
| 019 |
I8-98299 580-0 |
|
GASKET; FUEL TANK UNIT |
1 |
2203- |
|
GXZ |
ID=54.5 |
| 025 |
I1-22440 056-0 |
|
CAP; FILLER,FUEL TANK |
1 |
2203- |
|
GXZ |
(A) |
| 043 |
I8-97499 204-0 |
|
BRACKET; FUEL TANK |
2 |
2203- |
|
GXZ |
|
| 488 |
I0-04750 300-0 |
|
HOSE; RUBBER |
1 |
2203- |
|
GXZ |
L=340 SERVICED BY L=3000 |
