| 3 |
I8-97920 417-1 |
|
PROTECTOR; HEAT, EXH MANIF |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> EURO 2 |
| 16 |
I5-09302 008-1 |
|
STUD; EXH PIPE TO MANIF |
2 |
0008- |
|
4JA1 |
EXC. TURBOCHARGER<K51> M10X45 L=60 PLATING |
| 14 |
I8-97257 914-0 |
|
WASHER; PL, EXH MANIF |
2 |
0612- |
|
4JA1-T |
ID=8.5 OD=15 T=4 EURO 2 |
| 15 |
I8-97131 597-1 |
|
BOLT; EXH MANIF |
6 |
0612- |
|
4JA1-T |
M8X35 W/PL WASHER&FLANGE EURO 2 |
| 18 |
I0-91150 208-0 |
|
NUT; EXH MANIF |
2 |
0612- |
|
4JA1-T |
M8 FLANGE |
| 21 |
I0-28080 812-0 |
|
BOLT; HEAT PROTECTOR |
2 |
0008-0611 |
|
4JA1 |
(A) M8X12 FLANGE |
| 21 |
I0-28050 612-0 |
|
BOLT; HEAT PROTECTOR |
1 |
0612- |
|
4JA1-T |
(B), TURBOCHARGER<K51> M6X12 FLANGE IND |
| 16 |
I8-97032 977-1 |
|
STUD; EXH PIPE TO MANIF |
2 |
0008- |
|
4JA1 |
EXC. TURBOCHARGER<K51> M10X45 L=60 PLATING |
| 21 |
I0-28450 816-0 |
|
BOLT; HEAT PROTECTOR |
1 |
0612- |
|
4JA1-T |
(C), TURBOCHARGER<K51> M8X12 FLANGE IND |
| 2 |
I8-97920 200-3 |
|
GASKET; EXH MANIF TO HD |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> EURO 2 |
| 1 |
I8-97065 960-1 |
|
MANIFOLD; EXHAUST |
1 |
0008-0211 |
|
4JA1 |
EXC. TURBOCHARGER<K51> |
| 15 |
I8-97131 597-1 |
|
BOLT; EXH MANIF |
6 |
0008-0611 |
|
4JA1 |
M8X35 W/PL WASHER&FLANGE |
| 1 |
I8-97183 453-A |
|
MANIFOLD; EXHAUST |
1 |
0008- |
|
4JA1 |
TURBOCHARGER<K51> |
| 21 |
I0-28050 812-0 |
|
BOLT; HEAT PROTECTOR |
2 |
0612- |
|
4JA1-T |
(A) M8X12 FLANGE, EURO 2 |
| 23 |
I9-09164 608-0 |
|
WASHER; PL EXH MANIF BRKT |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER, ID=8 |
| 1 |
I8-97183 453-0 |
|
MANIFOLD; EXHAUST |
1 |
0008-0611 |
|
4JA1 |
TURBOCHARGER<K51> |
| 24 |
I8-94312 699-1 |
|
BOLT; BRKT, EXH MANIF |
1 |
0008-0611 |
|
4JA1 |
TURBOCHARGER<K51> M8X14 FLANGE |
| 23 |
I9-09164 608-0 |
|
WASHER; PL EXH MANIF BRKT |
1 |
0008-0611 |
|
4JA1 |
TURBOCHARGER, ID=8 |
| 1 |
I8-97977 309-0 |
|
MANIFOLD; EXHAUST |
1 |
0212- |
|
4JA1 |
EXC. TURBOCHARGER<K51> |
| 24 |
I8-97378 075-0 |
|
BOLT; BRKT, EXH MANIF |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> M8X14 FLANGE |
| 14 |
I8-97257 914-0 |
|
WASHER; PL, EXH MANIF |
2 |
0008-0611 |
|
4JA1 |
ID=8.5 OD=15 T=4 |
| 2 |
I8-97912 609-2 |
|
GASKET; EXH MANIF TO HD |
1 |
0008- |
|
4JA1 |
ALSO INCLUDED IN GASKET SET (ENG & HEAD) |
| 45 |
I8-97131 704-0 |
|
PROTECTOR; HEAT, MANIF RR |
1 |
0008- |
|
4JA1 |
EXC.TURBOCHARGER<K51> |
| 45 |
I8-97920 418-1 |
|
PROTECTOR; HEAT, MANIF RR |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> EURO 2 |
| 1 |
I8-97241 494-0 |
|
MANIFOLD; EXHAUST |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> EURO 2 |
| 19 |
I8-97378 065-0 |
|
STUD; MANIF TO CYL HD |
2 |
0612- |
|
4JA1-T |
EURO 2 |
| 45 |
I8-97038 107-2 |
|
PROTECTOR; HEAT, MANIF RR |
1 |
0008-0611 |
|
4JA1 |
TURBOCHARGER<K51> |
| 3 |
I8-97912 766-0 |
|
PROTECTOR; HEAT, EXH MANIF |
1 |
0310-0611 |
|
4JA1 |
TURBOCHARGER<K51> |
| 21 |
I0-28080 812-0 |
|
BOLT; HEAT PROTECTOR |
1 |
0008-0611 |
|
4JA1 |
(C), TURBOCHARGER<K51> M8X12 FLANGE IND |
| 19 |
I8-97378 065-0 |
|
STUD; MANIF TO CYL HD |
2 |
0411-0611 |
|
4JA1 |
|
| 25 |
I8-97188 185-1 |
|
BRACKET; EXH MANIF |
1 |
0008-0611 |
|
4JA1 |
TURBOCHARGER<K51> |
| 25 |
I8-97188 185-1 |
|
BRACKET; EXH MANIF |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER<K51> |
| 3 |
I8-97133 936-1 |
|
PROTECTOR; HEAT, EXH MANIF |
1 |
0008-0309 |
|
4JA1 |
TURBOCHARGER<K51> |
| 18 |
I0-91150 208-0 |
|
NUT; EXH MANIF |
2 |
0008-0611 |
|
4JA1 |
M8 FLANGE |
| 23 |
I0-91614 608-0 |
|
WASHER; PL EXH MANIF BRKT |
1 |
0008- |
|
4JA1 |
TURBOCHARGER, ID=8 |
| 21 |
I0-28080 612-0 |
|
BOLT; HEAT PROTECTOR |
1 |
0008-0611 |
|
4JA1 |
(B), TURBOCHARGER<K51> M6X12 FLANGE IND |
| 1 |
I8-97124 873-0 |
|
MANIFOLD; EXHAUST |
1 |
0008- |
|
4JA1 |
EXC. TURBOCHARGER<K51> |
| 19 |
I8-97048 055-1 |
|
STUD; MANIF TO CYL HD |
2 |
0008-0410 |
|
4JA1 |
M8X35 L=46 |
| 23 |
I0-91614 608-0 |
|
WASHER; PL EXH MANIF BRKT |
1 |
0612- |
|
4JA1-T |
TURBOCHARGER, ID=8 |
