| 109 |
I0-04010 618-0 |
|
STUD; FAN CLUTCH |
4 |
0612- |
|
4JA1-T |
M6X18 L=27 |
| 96 |
I0-50040 845-0 |
|
BOLT; ADJ PLATE |
1 |
0008-0611 |
|
4JA1 |
(B), M8X45 W/LK WASHER |
| 1 |
I8-97103 469-0 |
|
FAN; COOLING |
1 |
0612- |
|
4JA1-T |
ALL VARIANT |
| 36 |
I8-97957 509-A |
|
BELT; COOLING FAN |
1 |
0008-0611 |
|
4JA1 |
MITSUBOSHI IND |
| 18 |
I1-09985 179-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0107- |
|
4JA1 |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 1 |
I8-97131 736-0 |
|
FAN; COOLING |
1 |
0008-0406 |
|
4JA1 |
M/T MSG 5 SPEED(M75) ALL VARIANT |
| 96 |
I0-50740 845-0 |
|
BOLT; ADJ PLATE |
1 |
0008- |
|
4JA1 |
(B), M8X45 W/LK WASHER |
| 88 |
I0-91614 708-0 |
|
WASHER; PL, ADJ PLATE |
1 |
0612- |
|
4JA1-T |
ID=8 OD=22 |
| 36 |
I8-97957 513-A |
|
BELT; COOLING FAN |
1 |
0008-0611 |
|
4JA1 |
BANDO IND |
| 13 |
I8-98049 362-0 |
|
NUT; COOLING FAN |
4 |
0008- |
|
4JA1 |
M6 FLANGE |
| 230 |
I8-97049 499-1 |
|
FAN; COOLING |
1 |
0107- |
|
4JA1 |
(B), A/T AISIN (RMD) LM, LV, LS, TOURING OD=450 8-BLADE |
| 109 |
I0-41010 618-0 |
|
STUD; FAN CLUTCH |
4 |
0008- |
|
4JA1 |
M6X18 L=27 |
| 96 |
I0-50040 825-0 |
|
BOLT; ADJ PLATE |
1 |
0008-0611 |
|
4JA1 |
(A), M8X25 W/LK WASHER |
| 18 |
I1-09985 179-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0008- |
|
4JA1 |
ID=6 |
| 13 |
I5-09440 004-0 |
|
NUT; COOLING FAN |
4 |
0008-0611 |
|
4JA1 |
M6 FLANGE |
| 230 |
I8-94117 866-0 |
|
FAN; COOLING |
1 |
0612- |
|
4JA1-T |
(A), M/T MSG 5 SPEED(M75) LM, LV, LS, TOURING OD=410 7-BLADE |
| 96 |
I0-50540 825-0 |
|
BOLT; ADJ PLATE |
1 |
0008- |
|
4JA1 |
(A), M8X25 W/LK WASHER |
| 13 |
I5-09440 004-0 |
|
NUT; COOLING FAN |
4 |
0612- |
|
4JA1-T |
M6 FLANGE |
| 18 |
I1-09985 179-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0612- |
|
4JA1-T |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 18 |
I9-09150 506-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0612- |
|
4JA1-T |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 88 |
I9-09164 708-0 |
|
WASHER; PL, ADJ PLATE |
1 |
0612- |
|
4JA1-T |
ID=8 OD=22 |
| 8 |
I8-97145 322-0 |
|
CLUTCH; COOLING FAN |
1 |
0008-0405 |
|
4JA1 |
(A), M/T MSG 5 SPEED(M75) GRADE SUPER, ROYAL, H-GRADE GRADE TOURING (RBG) |
| 14 |
I8-98049 362-0 |
|
NUT; FAN TO CLUTCH |
4 |
0107- |
|
4JA1 |
A/T AISIN (RMD) GRADE TOURING (RBG), M6 M6 FLANGE |
| 96 |
I0-50040 825-0 |
|
BOLT; ADJ PLATE |
1 |
0612- |
|
4JA1-T |
(A), M8X45 W/LK WASHER |
| 96 |
I0-50540 825-0 |
|
BOLT; ADJ PLATE |
1 |
0612- |
|
4JA1-T |
(A), M8X45 W/LK WASHER |
| 14 |
I5-09440 004-0 |
|
NUT; FAN TO CLUTCH |
4 |
0107- |
|
4JA1 |
A/T AISIN (RMD) GRADE TOURING (RBG), M6 M6 FLANGE |
| 8 |
I8-94244 409-0 |
|
CLUTCH; COOLING FAN |
1 |
0612- |
|
4JA1-T |
(A), M/T MSG 5 SPEED(M75) GRADE SUPER, ROYAL, H-GRADE GRADE TOURING (RBG) |
| 18 |
I9-09150 506-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0107-0611 |
|
4JA1 |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 36 |
I8-97957 513-A |
|
BELT; COOLING FAN |
1 |
0612- |
|
4JA1-T |
BANDO IND |
| 8 |
I8-97039 034-0 |
|
CLUTCH; COOLING FAN |
1 |
0107- |
|
4JA1 |
(B), A/T AISIN (RMD) GRADE TOURING (RBG) |
| 109 |
I0-04010 618-0 |
|
STUD; FAN CLUTCH |
4 |
0008-0611 |
|
4JA1 |
M6X18 L=27 |
| 230 |
I8-94117 866-0 |
|
FAN; COOLING |
1 |
0008-0611 |
|
4JA1 |
(A), M/T MSG 5 SPEED(M75) LM, LV, LS, TOURING |
| 80 |
I8-97192 461-A |
|
PLATE; ADJUSTER |
1 |
0612- |
|
4JA1-T |
IND |
| 14 |
I9-09110 506-0 |
|
NUT; FAN TO CLUTCH |
4 |
0107-0611 |
|
4JA1 |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 80 |
I8-97192 461-A |
|
PLATE; ADJUSTER |
1 |
0008-0611 |
|
4JA1 |
IND |
| 36 |
I8-97957 509-A |
|
BELT; COOLING FAN |
1 |
0612- |
|
4JA1-T |
MITSUBOSHI IND |
| 109 |
I9-04110 618-0 |
|
STUD; FAN CLUTCH |
4 |
0008- |
|
4JA1 |
M6X18 L=27 |
| 18 |
I9-09150 506-0 |
|
WASHER; FAN TO CLUTCH |
4 |
0008-0106 |
|
4JA1 |
ID=6 |
| 14 |
I9-09110 506-0 |
|
NUT; FAN TO CLUTCH |
4 |
0612- |
|
4JA1-T |
M/T MSG 5 SPEED(M75) GRADE TOURING (RBG), M6 |
| 96 |
I0-50540 845-0 |
|
BOLT; ADJ PLATE |
1 |
0612- |
|
4JA1-T |
(B), M8X45 W/LK WASHER |
| 88 |
I9-09164 708-0 |
|
WASHER; PL, ADJ PLATE |
1 |
0008-0611 |
|
4JA1 |
ID=8 OD=22 |
| 88 |
I0-91614 708-0 |
|
WASHER; PL, ADJ PLATE |
1 |
0008- |
|
4JA1 |
ID=8 OD=22 |
| 13 |
I8-98049 362-0 |
|
NUT; COOLING FAN |
4 |
0612- |
|
4JA1-T |
M6 FLANGE |
| 14 |
I9-09110 506-0 |
|
NUT; FAN TO CLUTCH |
4 |
0008-0106 |
|
4JA1 |
M6 |
| 8 |
I8-94244 409-0 |
|
CLUTCH; COOLING FAN |
1 |
0406-0611 |
|
4JA1 |
(A), M/T MSG 5 SPEED(M75) GRADE SUPER, ROYAL, H-GRADE GRADE TOURING (RBG) |
| 1 |
I8-97103 469-0 |
|
FAN; COOLING |
1 |
0407-0611 |
|
4JA1 |
ALL VARIANT |
