| 48 |
I8-94248 002-0 |
|
SHAFT; GOV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 20 |
I8-94428 882-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.00 |
| 132 |
I8-97166 973-0 |
|
BRACKET; ADJ SCREW, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 20 |
I8-94408 534-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.90 |
| 55 |
I8-94239 373-0 |
|
GASKET; MAG VLV, INJ PUM |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 64 |
I8-97119 200-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) STAMP 118 |
| 20 |
I8-94408 530-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.10 |
| 45 |
I8-97211 762-0 |
|
LEVER ASM; GOV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) |
| 93 |
I8-94426 047-1 |
|
NUT; ADJ SCREW LK, INJ PUMP GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
4 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) (A) |
| 140 |
I8-97132 899-0 |
|
BOLT; BRKT, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (B) |
| 90 |
I8-94426 049-0 |
|
SCREW; FULL LOAD ADJ, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (A) |
| 20 |
I8-94408 535-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.10 |
| 20 |
I8-94408 525-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.10 |
| 90 |
I8-94316 275-0 |
|
SCREW; FULL LOAD ADJ, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=55.0 |
| 20 |
I8-94428 869-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.40 |
| 51 |
I8-97119 180-0 |
|
SHAFT; LOAD CONT LEVER GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 860-1) |
| 90 |
I8-94316 276-0 |
|
SCREW; FULL LOAD ADJ, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=57.0 |
| 20 |
I8-94408 533-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.70 |
| 51 |
I8-94174 807-0 |
|
SHAFT; LOAD CONT LEVER GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97259 883-0) |
| 47 |
I8-97223 413-0 |
|
PIN; RET |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) |
| 20 |
I8-94428 868-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 15 |
I8-94227 614-0 |
|
WASHER; LK, FLYWEIGHT FIX, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) (B) |
| 104 |
I8-94316 266-0 |
|
CAP; LOCK NUT, ADJ SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=27.0 |
| 282 |
I8-97173 771-0 |
|
SCREW; POTENTIO METER |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (B) |
| 20 |
I8-94428 877-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.00 |
| 20 |
I8-94408 523-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.70 |
| 45 |
I8-97211 768-0 |
|
LEVER ASM; GOV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
3 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 93 |
I8-94426 047-0 |
|
NUT; ADJ SCREW LK, INJ PUMP GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) |
| 52 |
I8-94227 590-0 |
|
WASHER; CONT SHAFT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 54 |
I8-94239 372-0 |
|
VALVE; MAG, ENG STOP, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 133 |
I8-94313 267-0 |
|
BOLT; BRKT FIX, GOV |
3 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) M6X12 |
| 53 |
I8-94227 585-0 |
|
GASKET; CONT SHAFT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 56 |
I8-94470 582-0 |
|
WIRE; LEAD, MAG VLV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 17 |
I8-94227 609-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.45 |
| 17 |
I8-94227 608-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.25 |
| 104 |
I8-94316 264-0 |
|
CAP; LOCK NUT, ADJ SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=21.0 |
| 57 |
I8-94473 135-0 |
|
NUT; VLV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-98022 003-0) |
| 17 |
I8-94227 607-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.05 |
| 11 |
I8-97136 413-0 |
|
GASKET; COVER TO HSG GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 20 |
I8-94428 871-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.00 |
| 17 |
I8-94231 123-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.15 |
| 64 |
I8-97328 707-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) STAMP 280 |
| 134 |
I8-97126 371-0 |
|
BRACKET; CONT CABLE, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 351 |
I8-97173 772-0 |
|
NUT; SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 282 |
I8-97148 143-0 |
|
SCREW; POTENTIO METER |
2 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (A) |
| 7 |
I8-94316 269-0 |
|
COVER; GOV HSG, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97259 883-0) |
| 64 |
I8-97166 957-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) STAMP 126 |
| 17 |
I8-94231 125-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.55 |
| 18 |
I8-97214 475-0 |
|
SLEEVE; GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 97 |
I8-94227 601-0 |
|
BOLT; PIVOT, GOV LEVER |
2 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 80 |
I1-09985 179-0 |
|
WASHER; LK, CONT LEVER GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) ID=6 |
| 17 |
I8-94227 611-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.85 |
| 140 |
I8-94313 203-0 |
|
BOLT; BRKT, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (A) |
| 14 |
I8-94227 613-0 |
|
HOLDER; GOV FLYWEIGHT INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 20 |
I8-97163 167-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.60 |
| 80 |
I9-09150 506-0 |
|
WASHER; LK, CONT LEVER GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) ID=6 |
| 20 |
I8-94428 878-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.20 |
| 20 |
I8-94428 872-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.00 |
| 47 |
I8-97096 706-0 |
|
PIN; RET |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 93 |
I1-15729 006-1 |
|
NUT; ADJ SCREW LK, INJ PUMP GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (C) |
| 139 |
I8-94313 665-0 |
|
BRACKET; INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) |
| 101 |
I8-94227 598-0 |
|
GASKET; ADJ SPR CAPSULE GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 20 |
I8-94408 527-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.50 |
| 71 |
I8-94313 218-0 |
|
SPRING; CONT LEVER, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 20 |
I8-94408 524-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.90 |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
4 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 856-2) |
| 20 |
I8-97163 168-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-98022 003-0) L=5.70 |
| 20 |
I8-94408 520-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.10 |
| 20 |
I8-94428 879-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.40 |
| 15 |
I8-94227 612-0 |
|
WASHER; LK, FLYWEIGHT FIX, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) (A) |
| 64 |
I8-97166 958-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) STAMP 127 |
| 19 |
I8-94408 519-0 |
|
CAP; GOV SLEEVE, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 12 |
I8-94228 403-0 |
|
FLYWEIGHT ASM; GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 54 |
I8-94242 275-0 |
|
VALVE; MAG, ENG STOP, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 20 |
I8-94408 528-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.70 |
| 20 |
I8-94428 876-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.80 |
| 20 |
I8-97163 168-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.70 |
| 20 |
I8-94408 521-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.30 |
| 20 |
I8-94372 500-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.30 |
| 463 |
I8-97173 775-0 |
|
BOLT; POTENTIO METER |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 50 |
I8-94473 129-0 |
|
NUT; GOV SHAFT, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 46 |
I8-97077 837-0 |
|
SPRING; GOV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) (A) |
| 64 |
I8-97119 201-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) STAMP 119 |
| 464 |
I8-97173 773-0 |
|
JOINT; POTENTIO METER |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 64 |
I8-98050 935-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) STAMP 279 |
| 7 |
I8-97328 704-0 |
|
COVER; GOV HSG, INJ PUMP |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 475 |
I8-97214 483-0 |
|
DAMPER; GOVERNOR |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 8 |
I8-94242 298-0 |
|
BOLT; GOV COVER, INJPUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (B) |
| 20 |
I8-94408 529-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.90 |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
4 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) |
| 64 |
I8-97139 479-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) STAMP 126 |
| 139 |
I8-94457 164-0 |
|
BRACKET; INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (A) |
| 20 |
I8-94428 875-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.60 |
| 20 |
I8-94372 499-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.20 |
| 51 |
I8-98050 923-0 |
|
SHAFT; LOAD CONT LEVER GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-98022 003-0) |
| 46 |
I8-94473 128-0 |
|
SPRING; GOV, INJ PUMP |
2 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) (B) |
| 20 |
I8-94428 880-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 20 |
I8-97163 169-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.80 |
| 104 |
I8-94316 265-0 |
|
CAP; LOCK NUT, ADJ SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=24.0 |
| 64 |
I8-97139 480-0 |
|
LEVER; LOAD CONT, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) STAMP 127 |
| 17 |
I8-94227 610-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.65 |
| 49 |
I8-94227 606-0 |
|
GASKET; GOV SHAFT, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) |
| 45 |
I8-97173 748-0 |
|
LEVER ASM; GOV, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 860-1) |
| 135 |
I8-97119 175-0 |
|
BRACKET; POTENTIO MTR |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 20 |
I8-94372 502-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.50 |
| 20 |
I8-94428 881-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.80 |
| 20 |
I8-94408 522-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.50 |
| 98 |
I8-94227 602-0 |
|
GASKET; PIVOT BOLT, GOV LEVER |
2 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 20 |
I8-94428 874-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.40 |
| 104 |
I8-94316 263-0 |
|
CAP; LOCK NUT, ADJ SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=18.0 |
| 11 |
I8-97136 413-0 |
|
GASKET; COVER TO HSG GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 82 |
I8-97086 138-0 |
|
NUT; CONT LEVER FIX, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 141 |
I8-94174 822-0 |
|
PLATE ASM; PIPE BRKT |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (A) |
| 20 |
I8-94408 531-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.30 |
| 415 |
I1-09054 038-0 |
|
BOLT; BRKT TO HOUSING |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 141 |
I8-94454 254-0 |
|
PLATE ASM; PIPE BRKT |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) |
| 93 |
I8-94316 277-0 |
|
NUT; ADJ SCREW LK, INJ PUMP GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (A) |
| 138 |
I8-97173 749-0 |
|
POTENTIO METER |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) |
| 17 |
I8-94231 126-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.75 |
| 20 |
I8-94428 870-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=2.60 |
| 20 |
I8-94408 526-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.50 |
| 17 |
I8-94231 124-0 |
|
SHIM; FLYWEIGHT SLEEVE, GOV |
AR |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) T=1.35 |
| 20 |
I8-94428 873-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=3.20 |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
4 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 860-1) |
| 90 |
I8-94316 274-0 |
|
SCREW; FULL LOAD ADJ, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (B) L=53.0 |
| 7 |
I8-97119 171-0 |
|
COVER; GOV HSG, INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 860-1) |
| 104 |
I8-94316 262-0 |
|
CAP; LOCK NUT, ADJ SCREW |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (A) L=16.5 |
| 102 |
I8-94227 593-0 |
|
WASHER; FULL LOAD ADJ SCREW, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) |
| 20 |
I8-94408 532-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=4.50 |
| 8 |
I8-94227 636-0 |
|
BOLT; GOV COVER, INJPUMP |
4 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 858-2) |
| 20 |
I8-94372 501-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.40 |
| 139 |
I8-97182 234-0 |
|
BRACKET; INJ PUMP |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97259 883-0) (A) |
| 14 |
I8-94227 613-0 |
|
HOLDER; GOV FLYWEIGHT INJ PUMP |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 12 |
I8-97328 711-0 |
|
FLYWEIGHT ASM; GOV |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 45 |
I8-97332 036-0 |
|
LEVER ASM; GOV, INJ PUMP |
1 |
0612- |
|
4JA1-T |
(FOR ASSY 8-98022 003-0) |
| 82 |
I1-15729 006-0 |
|
NUT; CONT LEVER FIX, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-98022 003-0) |
| 20 |
I8-97163 170-0 |
|
PLUG; CLOSING, GOV SLEEVE |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) (FOR ASSY 8-97259 883-0) (FOR ASSY 8-98022 003-0) L=5.90 |
| 132 |
I8-94457 165-0 |
|
BRACKET; ADJ SCREW, GOV |
1 |
0008- |
|
4JA1 |
(FOR ASSY 8-97191 854-2) (FOR ASSY 8-97191 856-2) (FOR ASSY 8-97191 858-2) (FOR ASSY 8-97191 860-1) |
