| 304 |
I8-97313 109-1 |
|
HOSE; RUBBER, FUEL FILLER FILTER TO INJ PUMP |
1 |
0107- |
|
4JA1 |
GRADE TOURING (RBG) |
| 1 |
I8-97956 297-A |
|
TANK; FUEL |
1 |
0008-0209 |
|
4JA1 |
WGN LONG, IND (SS) |
| 78 |
I8-98008 098-0 |
|
CLIP; BREATHER HOSE |
4 |
0008- |
|
4JA1 |
WAGON, ID=16 |
| 81 |
I8-97956 339-A |
|
HOSE; FUEL FILLER |
1 |
0008- |
|
4JA1 |
PICK UP (TB**S*) IND |
| 608 |
I0-01258 300-0 |
|
HOSE; RUBBER, PIPE TO FUEL FILTER |
1 |
0008- |
|
4JA1-T |
NEW SUPER, ROYAL GRADE LS (RBD), L=600 SERVICED BY L=3000 |
| 11 |
I8-94152 613-A |
|
PLUG; DRAIN, FUEL TANK |
1 |
0612- |
|
4JA1-T |
IND, M14X14 |
| 75 |
I8-94238 570-0 |
|
CLIP; RUBBER HOSE |
2 |
0008- |
|
4JA1 |
(B), SHORT, ID=11 |
| 25 |
I8-94450 279-1 |
|
CAP; FILLER, FUEL TANK |
1 |
0008-0202 |
|
4JA1 |
|
| 314 |
I8-97260 487-2 |
|
HOSE; RUBBER, FUEL RETURN |
1 |
0210- |
|
4JA1 |
(A) |
| 11 |
I8-94152 613-A |
|
PLUG; DRAIN, FUEL TANK |
1 |
0008-0611 |
|
4JA1 |
IND, M14X14 |
| 95 |
I8-98022 271-0 |
|
SCREW; FILLER NECK |
3 |
0008- |
|
4JA1 |
M6X16 |
| 312 |
I0-28651 035-0 |
|
BOLT; FUEL FILTER CLAMP |
2 |
0008- |
|
4JA1 |
M10X35 FLANGE |
| 1 |
I8-97956 250-A |
|
TANK; FUEL |
1 |
0008-0106 |
|
4JA1 |
PICK UP (TB**S*) IND |
| 95 |
I8-94381 646-0 |
|
SCREW; FILLER NECK |
3 |
0008- |
|
4JA1 |
M6X16 |
| 78 |
I8-94238 568-0 |
|
CLIP; BREATHER HOSE |
2 |
0008- |
|
4JA1 |
PICK UP, ID=16 |
| 312 |
I0-28681 035-0 |
|
BOLT; FUEL FILTER CLAMP |
2 |
0008- |
|
4JA1 |
M10X35 FLANGE |
| 1 |
I8-97561 098-A |
|
TANK; FUEL |
1 |
0210- |
|
4JA1 |
WGN SHORT, IND (PMD) |
| 75 |
I8-97015 784-0 |
|
CLIP; RUBBER HOSE |
1 |
0008- |
|
4JA1 |
(B), LONG, ID=11 |
| 83 |
I8-97254 803-0 |
|
NECK; FUEL FILLER |
1 |
0008- |
|
4JA1 |
(A), WAGON |
| 75 |
I8-94238 570-0 |
|
CLIP; RUBBER HOSE |
1 |
0008- |
|
4JA1 |
(B), LONG, ID=11 |
| 93 |
I0-01259 300-0 |
|
HOSE; BREATHER, F/TANK |
1 |
0008- |
|
4JA1 |
WAGON (TB**V*) (B) L=680 |
| 75 |
I8-94238 572-0 |
|
CLIP; RUBBER HOSE |
2 |
0008- |
|
4JA1 |
(C) ID=14 |
| 59 |
I8-94328 243-1 |
|
NUT; FUEL TANK |
6 |
0008- |
|
4JA1 |
M8 FLANGE |
| 80 |
I9-09915 265-A |
|
CLIP; FILLER HOSE |
1 |
0008- |
|
4JA1 |
(B), WAGON, ID=60, IND |
| 467 |
I8-97091 076-0 |
|
BOLT |
2 |
0008- |
|
4JA1 |
WAGON (TB**V*), M8X25 |
| 1 |
I8-97957 581-A |
|
TANK; FUEL |
1 |
0008-0209 |
|
4JA1 |
WGN SHORT, IND (SS) |
| 304 |
I8-97254 197-0 |
|
HOSE; RUBBER, FUEL FILLER FILTER TO INJ PUMP |
1 |
0008- |
|
4JA1 |
GRADE NEW SUPER, ROYAL HI GRADE |
| 314 |
I8-97260 487-1 |
|
HOSE; RUBBER, FUEL RETURN |
1 |
0008-0209 |
|
4JA1 |
(A) |
| 6 |
I8-97024 319-0 |
|
SCREW; TANK UNIT |
5 |
0008- |
|
4JA1 |
M5X10 W/LK WASHER |
| 83 |
I8-97956 838-A |
|
NECK; FUEL FILLER |
1 |
0008- |
|
4JA1 |
(B), WAGON IND |
| 78 |
I8-98008 098-0 |
|
CLIP; BREATHER HOSE |
2 |
0008- |
|
4JA1 |
PICK UP, ID=16 |
| 3 |
I8-97957 611-A |
|
UNIT; FUEL TANK, SUB |
1 |
0008- |
|
4JA1 |
SHORT (TB***C) IND |
| 75 |
I8-98150 357-0 |
|
CLIP; RUBBER HOSE |
1 |
0008- |
|
4JA1 |
(B), LONG, ID=13 |
| 8 |
I9-09920 624-A |
|
GASKET; DRAIN PLUG, F/TANK |
1 |
0612- |
|
4JA1-T |
IND |
| 6 |
I9-03910 510-0 |
|
SCREW; TANK UNIT |
5 |
0008-0611 |
|
4JA1 |
M5X10 W/LK WASHER |
| 86 |
I8-94128 826-0 |
|
HOSE; EVAP |
1 |
0008- |
|
4JA1 |
L=60 SERVICED BY L=3000 |
| 1 |
I8-97561 100-A |
|
TANK; FUEL |
1 |
0210-0611 |
|
4JA1 |
WGN LONG, IND (PMD) |
| 3 |
I8-98232 857-0 |
|
UNIT; FUEL TANK, SUB |
1 |
0612- |
|
4JA1-T |
LONG (TB***F) IND |
| 314 |
I8-94363 222-0 |
|
HOSE; RUBBER, FUEL RETURN |
1 |
0008-0209 |
|
4JA1 |
(B) LONG (TB***F), L=230 |
| 240 |
I0-91614 708-0 |
|
WASHER; PL, FUEL TANK |
3 |
0008- |
|
4JA1 |
ID=8 OD=22 |
| 6 |
I9-03910 510-0 |
|
SCREW; TANK UNIT |
5 |
0612- |
|
4JA1-T |
M5X10 W/LK WASHER |
| 6 |
I8-97024 319-0 |
|
SCREW; TANK UNIT |
5 |
0612- |
|
4JA1-T |
M5X10 W/LK WASHER |
| 93 |
I8-97314 006-0 |
|
HOSE; BREATHER, F/TANK |
1 |
0107- |
|
4JA1 |
GRADE TOURING (RBG) (A), L=340 |
| 383 |
I8-97178 373-0 |
|
VALVE; 2 WAY |
1 |
0008- |
|
4JA1 |
|
| 86 |
I8-94128 826-0 |
|
HOSE; EVAP |
1 |
0008- |
|
4JA1 |
(A) L=300 SERVICED BY L=3000 |
| 8 |
I9-09920 624-A |
|
GASKET; DRAIN PLUG, F/TANK |
1 |
0008-0611 |
|
4JA1 |
IND |
| 314 |
I0-01254 300-0 |
|
HOSE; RUBBER, FUEL RETURN |
1 |
0008- |
|
4JA1 |
(B) SHORT (TB***C), L=180 SERVICED BY L=3000 |
| 83 |
I8-97254 802-0 |
|
NECK; FUEL FILLER |
1 |
0008- |
|
4JA1 |
(C), PICK UP |
| 75 |
I8-97015 784-0 |
|
CLIP; RUBBER HOSE |
2 |
0008- |
|
4JA1 |
(B), SHORT, ID=11 |
| 240 |
I9-09164 708-0 |
|
WASHER; PL, FUEL TANK |
3 |
0008- |
|
4JA1 |
ID=8 OD=22 |
| 75 |
I8-94238 571-0 |
|
CLIP; RUBBER HOSE |
1 |
0008- |
|
4JA1 |
(B), LONG, ID=13 |
| 1 |
I8-97562 652-A |
|
TANK; FUEL |
1 |
0612- |
|
4JA1-T |
WGN LONG, IND |
| 314 |
I8-94363 222-1 |
|
HOSE; RUBBER, FUEL RETURN |
1 |
0210- |
|
4JA1 |
(B) LONG (TB***F), L=230 |
| 25 |
I8-94310 199-4 |
|
CAP; FILLER, FUEL TANK |
1 |
0612- |
|
4JA1-T |
|
| 299 |
I8-97956 644-A |
|
BRACKET; FUEL FILLER |
1 |
0008- |
|
4JA1 |
IND |
| 3 |
I8-97956 834-A |
|
UNIT; FUEL TANK, SUB |
1 |
0008-0611 |
|
4JA1 |
LONG (TB***F) IND |
| 78 |
I8-94238 568-0 |
|
CLIP; BREATHER HOSE |
4 |
0008- |
|
4JA1 |
WAGON, ID=16 |
| 75 |
I8-94430 297-0 |
|
CLIP; RUBBER HOSE |
1 |
0008- |
|
4JA1 |
(A) ID=8 & 4.8 |
| 3 |
I8-97956 834-A |
|
UNIT; FUEL TANK, SUB |
1 |
0612- |
|
4JA1-T |
LONG (TB***F) IND |
| 80 |
I9-09915 265-A |
|
CLIP; FILLER HOSE |
2 |
0008- |
|
4JA1 |
PICK UP, ID=60 |
| 93 |
I0-01259 300-0 |
|
HOSE; BREATHER, FUEL TANK |
1 |
0008- |
|
4JA1 |
WAGON (TB**V*) GRADE NEW SUPER (RBA) GRADE ROYAL (RBB) WAGON LONG (TB**VF) GRADE LS (RBD) (A) L=320 SERVICED BY L=3000 |
| 80 |
I9-09915 042-A |
|
CLIP; FILLER HOSE |
3 |
0008- |
|
4JA1 |
(A), WAGON, ID=42, IND |
| 261 |
I0-28680 820-0 |
|
BOLT; PROTECTOR |
2 |
0008- |
|
4JA1 |
M8X20 FLANGE |
| 108 |
I8-97956 729-A |
|
PROTECTOR; FUEL TANK |
1 |
0008- |
|
4JA1 |
IND |
| 64 |
I8-97034 130-1 |
|
BOLT; FUEL TANK |
6 |
0008- |
|
4JA1 |
M8X24 |
| 93 |
I0-01259 300-0 |
|
HOSE; BREATHER, FUEL TANK |
1 |
0008- |
|
4JA1 |
PICK UP (TB**S*) L=460 SERVICED BY L=3000 |
| 75 |
I1-09704 102-0 |
|
CLIP; RUBBER HOSE |
2 |
0008- |
|
4JA1 |
(C) ID=14 |
| 25 |
I8-94310 199-4 |
|
CAP; FILLER, FUEL TANK |
1 |
0203-0611 |
|
4JA1 |
|
| 400 |
I8-94166 071-0 |
|
CLIP; HOSE, EVAP |
3 |
0008- |
|
4JA1 |
ID=8.5 |
