| 137 |
I8-94143 209-0 |
|
BRACKET; STAB BAR TO FRAME |
2 |
0008- |
|
4JA1 |
|
| 62 |
I8-97956 186-A |
|
ABSORBER ASM; SHOCK, FRT |
2 |
0008-0106 |
|
4JA1 |
IND, WAGON (SUPER, ROYAL) |
| 84 |
I8-94459 461-2 |
|
ARM; LWR CONT LH |
1 |
0008-0611 |
|
4JA1 |
|
| 112 |
I8-94473 192-4 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
LH |
| 105 |
I8-94237 412-0 |
|
BOLT; STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
(A) M10X35 |
| 129 |
I0-91510 616-0 |
|
WASHER; LK, STRUT BAR |
2 |
0008- |
|
4JA1 |
ID=16 |
| 103 |
I9-99111 512-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
0008-0009 |
|
4JA1 |
M12 |
| 112 |
I8-98098 033-0 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
LH |
| 81 |
I0-81124 030-0 |
|
PIN; SPLIT, LWR LINK TO KNUCKLE |
2 |
0008- |
|
4JA1 |
|
| 45 |
I6-94408 840-0 |
|
BUSHING UPR LINK FRT |
4 |
0008- |
|
4JA1 |
(IADG) |
| 84 |
I8-94459 461-2 |
|
ARM; LWR CONT LH |
1 |
0612- |
|
4JA1-T |
|
| 21 |
I8-94459 453-4 |
|
JOINT ASM; BALL, UPR CONT ARM |
2 |
0612- |
|
4JA1-T |
|
| 104 |
I8-94366 120-0 |
|
BUMPER; RUBBER, STRUT |
2 |
0008- |
|
4JA1 |
|
| 133 |
I9-99110 516-0 |
|
NUT; STRUT BAR |
4 |
0008- |
|
4JA1 |
M16 |
| 41 |
I0-91510 808-0 |
|
WASHER; LK, UPR LINK END |
8 |
0008- |
|
4JA1 |
ID=8 |
| 25 |
I8-97306 865-0 |
|
ARM; UPR CONT LH |
1 |
0107-0611 |
|
4JA1 |
GRADE TOURING |
| 129 |
I9-09150 616-0 |
|
WASHER; LK, STRUT BAR |
2 |
0008- |
|
4JA1 |
ID=16 |
| 105 |
I9-01066 065-0 |
|
BOLT; STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
(B) M10X65 |
| 58 |
I6-94316 903-0 |
|
BUSHING LOWER,TBR541 |
2 |
0908- |
|
4JA1 |
(IADG) ID=16 |
| 134 |
I8-94439 158-1 |
|
WASHER; STRUT BAR |
4 |
0008- |
|
4JA1 |
|
| 112 |
I8-94473 191-4 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
RH |
| 157 |
I8-94407 719-1 |
|
PLATE; UPR LINK TO FRAME |
2 |
0008- |
|
4JA1 |
|
| 53 |
I8-94242 425-0 |
|
NUT; LWR LINK |
2 |
0008- |
|
4JA1 |
M10 |
| 77 |
I0-81123 025-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
0205- |
|
4JA1 |
L=25 |
| 21 |
I8-94459 453-4 |
|
JOINT ASM; BALL, UPR CONT ARM |
2 |
0008-0611 |
|
4JA1 |
|
| 62 |
I8-97956 975-A |
|
ABSORBER ASM; SHOCK, FRT |
2 |
0008-0106 |
|
4JA1 |
IND, PICK UP |
| 77 |
I0-81123 028-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
0008- |
|
4JA1 |
L=28 |
| 80 |
I0-91116 518-0 |
|
NUT; LWR LINK END TO KNUCKLE |
2 |
0008- |
|
4JA1 |
M18 |
| 20 |
I8-94478 727-0 |
|
BOLT; UPR LINK END TO UPR LINK |
8 |
0008- |
|
4JA1 |
|
| 77 |
I9-08113 025-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
0205- |
|
4JA1 |
L=25 |
| 167 |
I0-10856 490-0 |
|
BOLT; LWR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
M14X90 |
| 65 |
I8-97957 654-A |
|
WASHER; S/ABS |
4 |
0008- |
|
4JA1 |
IND |
| 167 |
I0-10806 490-0 |
|
BOLT; LWR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
M14X90 |
| 161 |
I8-94137 483-0 |
|
NUT ASM; UPR LINK TO FRAME |
4 |
0008- |
|
4JA1 |
(A) M14 FLANGE |
| 62 |
I8-97959 201-A |
|
ABSORBER ASM; SHOCK, FRT |
2 |
0107-0611 |
|
4JA1 |
IND, WAGON (HG, TOURING) |
| 25 |
I8-97306 865-0 |
|
ARM; UPR CONT LH |
1 |
0612- |
|
4JA1-T |
LV UP, TOUR, GTOUR |
| 25 |
I8-97306 864-0 |
|
ARM; UPR CONT RH |
1 |
0107-0611 |
|
4JA1 |
GRADE TOURING |
| 60 |
I0-10856 250-0 |
|
BOLT; S/ABS TO LWR LINK |
2 |
0008- |
|
4JA1 |
M12X50 |
| 48 |
I6-94459 464-0 |
|
JOINT ASM;BALL.LWR,P160 |
2 |
0908- |
|
4JA1-T |
(IADG) NULL |
| 106 |
I8-94259 086-A |
|
RUBBER; REBOUND, STRUT |
2 |
0008-0009 |
|
4JA1 |
IND |
| 96 |
I9-02061 020-0 |
|
BOLT; LWR LINK |
2 |
0008- |
|
4JA1 |
(B) M10X20 |
| 45 |
I8-94408 840-3 |
|
BUSHING; UPR LINK, FRT |
4 |
0008- |
|
4JA1 |
|
| 128 |
I0-91614 710-0 |
|
WASHER; PL, STRUT |
2 |
0008- |
|
4JA1 |
ID=10.5 T=2.6 |
| 106 |
I8-97959 156-A |
|
RUBBER; REBOUND, STRUT |
2 |
0010- |
|
4JA1 |
IND |
| 17 |
I8-97957 655-A |
|
BUSHING; RUBBER, S/ABS |
4 |
0008- |
|
4JA1 |
IND |
| 76 |
I0-91510 512-0 |
|
WASHER; LK, S/ABS TO LWR LINK |
2 |
0008- |
|
4JA1 |
ID=12 |
| 103 |
I0-91150 212-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
0010- |
|
4JA1 |
M12 |
| 48 |
I8-94459 464-3 |
|
JOINT ASM; BALL, LWR CONT ARM |
2 |
0612- |
|
4JA1-T |
|
| 77 |
I9-08113 028-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
0008-0204 |
|
4JA1 |
L=28 |
| 152 |
I7-05014 012-A |
|
NUT; LWR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
M14 |
| 84 |
I8-94459 460-2 |
|
ARM; LWR CONT RH |
1 |
0612- |
|
4JA1-T |
|
| 96 |
I0-10956 050-0 |
|
BOLT; LWR LINK |
2 |
0008- |
|
4JA1 |
(A) M10X50 |
| 161 |
I8-94478 731-0 |
|
NUT ASM; UPR LINK TO FRAME |
2 |
0008-0209 |
|
4JA1 |
(B) M14 |
| 155 |
I9-09150 514-0 |
|
WASHER; LK, UPR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
ID=14 |
| 48 |
I6-94459 464-0 |
|
JOINT ASM; BALL LWR |
2 |
0008-0611 |
|
4JA1 |
(IADG) |
| 14 |
I9-09110 410-A |
|
NUT; S/ABS, UPR |
2 |
0008- |
|
4JA1 |
M10 IND |
| 84 |
I8-94459 460-2 |
|
ARM; LWR CONT RH |
1 |
0008-0611 |
|
4JA1 |
|
| 13 |
I1-09985 185-0 |
|
WASHER; LK, LWR LINK |
2 |
0008- |
|
4JA1 |
ID=10, 2 |
| 53 |
I8-97065 439-0 |
|
NUT; LWR LINK |
2 |
0008- |
|
4JA1 |
M10 |
| 21 |
I6-94459 453-4 |
|
JOINT ASM; BALL UPR |
2 |
0008-0611 |
|
4JA1 |
(IADG) |
| 25 |
I8-94445 551-3 |
|
ARM; UPR CONT LH |
1 |
0008-0611 |
|
4JA1 |
N SUPER, ROYAL, HI GRADE |
| 131 |
I6-94433 672-0 |
|
RUBR; CUSH STRUT BAR |
4 |
0008- |
|
4JA1 |
(IADG) |
| 58 |
I8-94316 903-0 |
|
BUSHING; LWR LINK |
2 |
0008- |
|
4JA1 |
ID=16 |
| 18 |
I8-97957 656-A |
|
WASHER; CENTERING, S/ABS |
2 |
0008- |
|
4JA1 |
IND |
| 7 |
I8-94173 352-3 |
|
PN; FULCRUM, UPR LINK |
2 |
0008- |
|
4JA1 |
|
| 104 |
I8-94433 673-0 |
|
BUMPER; RUBBER, STRUT |
2 |
0008- |
|
4JA1 |
|
| 62 |
I8-97959 201-A |
|
ABSORBER ASM; SHOCK, FRT |
2 |
0612- |
|
4JA1-T |
IND, WAGON (ALL VARIANT) |
| 112 |
I8-98098 032-0 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
RH |
| 133 |
I0-91110 516-0 |
|
NUT; STRUT BAR |
4 |
0008- |
|
4JA1 |
M16 |
| 13 |
I9-09150 610-0 |
|
WASHER; LK, LWR LINK |
2 |
0008- |
|
4JA1 |
ID=10, 2 |
| 127 |
I9-09150 610-0 |
|
WASHER; LK, STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
ID=10.2 |
| 58 |
I6-94316 903-1 |
|
BUSHING; LOWER LINK |
2 |
0008- |
|
4JA1 |
(IADG) ID=16 |
| 161 |
I8-97327 724-0 |
|
NUT ASM; UPR LINK TO FRAME |
2 |
0210- |
|
4JA1 |
(B) M14 |
| 127 |
I1-09985 185-0 |
|
WASHER; LK, STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
ID=10.2 |
| 76 |
I9-09150 512-0 |
|
WASHER; LK, S/ABS TO LWR LINK |
2 |
0008- |
|
4JA1 |
ID=12 |
| 130 |
I8-97065 439-0 |
|
NUT; STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
M10 |
| 79 |
I8-94124 556-0 |
|
NUT; UPR LINK END TO KNUCKLE |
8 |
0008- |
|
4JA1 |
(B) M14 SLOTTED |
| 80 |
I9-99116 418-0 |
|
NUT; LWR LINK END TO KNUCKLE |
2 |
0008- |
|
4JA1 |
M18 |
| 48 |
I8-94459 464-3 |
|
JOINT ASM; BALL, LWR CONT ARM |
2 |
0008-0611 |
|
4JA1 |
|
| 25 |
I8-97306 864-0 |
|
ARM; UPR CONT RH |
1 |
0612- |
|
4JA1-T |
LV UP, TOUR, GTOUR |
| 112 |
I6-98098 032-0 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
(IADG) RH |
| 158 |
I8-94478 730-0 |
|
BOLT; UPR LINK TO FRAME |
4 |
0008- |
|
4JA1 |
M14X65 |
| 81 |
I9-08114 030-0 |
|
PIN; SPLIT, LWR LINK TO KNUCKLE |
2 |
0008- |
|
4JA1 |
|
| 25 |
I8-94445 550-3 |
|
ARM; UPR CONT RH |
1 |
0612- |
|
4JA1-T |
LM, SMART, SMAR FF, RYL, RYL FF, LS TURBO |
| 163 |
I8-94407 707-0 |
|
PLATE; FULCRUM PIN, UPR LINK |
4 |
0008- |
|
4JA1 |
|
| 112 |
I6-98098 033-0 |
|
BAR; STRUT |
1 |
0008- |
|
4JA1 |
(IADG) LH |
| 48 |
I6-94459 464-A |
|
JOINT ASM;BALL.LWR,P160 |
2 |
0908- |
|
4JA1-T |
(IADG) NULL |
| 103 |
I0-91180 212-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
0010- |
|
4JA1 |
M12 |
| 152 |
I9-99110 514-0 |
|
NUT; LWR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
M14 |
| 96 |
I9-01066 050-0 |
|
BOLT; LWR LINK |
2 |
0008- |
|
4JA1 |
(A) M10X50 |
| 130 |
I8-94242 425-0 |
|
NUT; STRUT BAR TO LWR LINK |
2 |
0008- |
|
4JA1 |
M10 |
| 131 |
I8-94433 672-0 |
|
RUBBER; CUSHION, STRUT BAR |
4 |
0008- |
|
4JA1 |
|
| 41 |
I9-09150 808-0 |
|
WASHER; LK, UPR LINK END |
8 |
0008- |
|
4JA1 |
ID=8 |
| 79 |
I5-09440 010-0 |
|
NUT; UPR LINK END TO KNUCKLE |
8 |
0008- |
|
4JA1 |
(A) M8 FLANGE |
| 161 |
I8-97360 124-0 |
|
NUT ASM; UPR LINK TO FRAME |
4 |
0008- |
|
4JA1 |
(A) M14 FLANGE |
| 128 |
I9-09164 710-0 |
|
WASHER; PL, STRUT |
2 |
0008- |
|
4JA1 |
ID=10.5 T=2.6 |
| 25 |
I8-94445 550-3 |
|
ARM; UPR CONT RH |
1 |
0008-0611 |
|
4JA1 |
N SUPER, ROYAL, HI GRADE |
| 25 |
I8-94445 551-3 |
|
ARM; UPR CONT LH |
1 |
0612- |
|
4JA1-T |
LM, SMART, SMAR FF, RYL, RYL FF, LS TURBO |
| 96 |
I0-20951 020-0 |
|
BOLT; LWR LINK |
2 |
0008- |
|
4JA1 |
(B) M10X20 |
| 60 |
I0-10811 250-0 |
|
BOLT; S/ABS TO LWR LINK |
2 |
0008- |
|
4JA1 |
M12X50 |
| 155 |
I0-91510 514-0 |
|
WASHER; LK, UPR LINK TO FRT C/MBR |
2 |
0008- |
|
4JA1 |
ID=14 |
| 109 |
I8-94439 157-0 |
|
TUBE; DIST, STRUT BAR |
2 |
0008- |
|
4JA1 |
|
