| 17 |
I8-97364 386-0 |
|
GASKET; OIL PAN |
1 |
1103- |
|
A |
|
| 3 |
I8-97912 531-0 |
|
GASKET; DRAIN PLUG |
1 |
1110- |
|
A |
ID =14.2 OD=24 |
| 3 |
I8-97912 531-0 |
|
GASKET; DRAIN PLUG |
1 |
1103-1109 |
|
A |
ID =14.2 OD=24 |
| 123 |
I8-97187 000-0 |
|
RUBBER; SEAL OIL |
1 |
1103- |
|
A |
(D) |
| 379 |
I8-94323 068-0 |
|
CLIP; PIPE TO HOSE |
1 |
1103- |
|
A |
ID=18 & 18 |
| 380 |
I8-98070 445-0 |
|
PROTECTOR; PIPE |
1 |
1103- |
|
A |
|
| 192 |
I1-09360 978-A |
|
HOSE; GUIDE TUBE |
1 |
1103- |
|
A |
L=300 |
| 25 |
I8-97190 392-0 |
|
STUD; OIL PAN . |
9 |
1103- |
|
A |
(B) M8X16,M8X19 L=39 W/PL WASHER,RUBBER TUBE |
| 24 |
I0-91180 108-0 |
|
NUT; OIL PAN |
13 |
1103- |
|
A |
M18 FLANGE |
| 123 |
I8-97186 994-0 |
|
RUBBER; SEAL OIL |
1 |
1103- |
|
A |
(B) |
| 4 |
I8-94152 613-A |
|
PLUG; DRAIN, OIL |
1 |
1110- |
|
A |
M14X14 IDN |
| 123 |
I8-97186 988-0 |
|
RUBBER; SEAL OIL |
1 |
1103- |
|
A |
(A) |
| 193 |
I1-09707 158-0 |
|
CLIP; HOSE, GUIDE |
2 |
1103- |
|
A |
ID=17 |
| 23 |
I8-97190 390-0 |
|
BOLT; OIL PAN |
13 |
1103- |
|
A |
H8X12.8 W/PL WASHER, RUBBER TUBE |
| 192 |
I1-09360 978-A |
|
HOSE; GUIDE TUBE |
1 |
1103- |
|
A |
L=300 |
| 9 |
I5-09623 002-0 |
|
GASKET; GUIDE TUBE, OIL LEVEL GAUGE |
2 |
1103-1109 |
|
A |
ID =11 |
| 10 |
I0-28050 612-0 |
|
BOLT; GUIDE TUBE |
1 |
1103- |
|
A |
(A) H6X12 FLANGE |
| 1 |
I8-98124 513-0 |
|
PAN ASM; OIL |
1 |
1103- |
|
A |
|
| 8 |
I8-98010 328-1 |
|
TUBE; GUIDE, OIL LEVEL GAUGE |
1 |
1103- |
|
A |
(B) |
| 25 |
I8-97190 391-0 |
|
STUD; OIL PAN . |
1 |
1103- |
|
A |
(A) M8X16,M8X17 L=37 W/PL WASHER,RUBBER TUBE |
| 8 |
I8-98009 115-1 |
|
TUBE; GUIDE, OIL LEVEL GAUGE |
1 |
1103- |
|
A |
(A) |
| 10 |
I0-28650 820-0 |
|
BOLT; GUIDE TUBE |
2 |
1103- |
|
A |
(B) 1l8X20 FLANGE IDN |
| 9 |
I5-09623 002-0 |
|
GASKET; GUIDE TUBE, OIL LEVEL GAUGE |
2 |
1110- |
|
A |
ID =11 |
| 123 |
I8-97186 998-0 |
|
RUBBER; SEAL OIL |
1 |
1103- |
|
A |
(C) |
| 2 |
I8-97519 308-0 |
|
GAUGE; OIL LEVEL |
1 |
1902- |
|
A |
|
| 4 |
I8-94152 613-A |
|
PLUG; DRAIN, OIL |
1 |
1103-1109 |
|
A |
M14X14 IDN |
| 2 |
I8-98085 153-0 |
|
GAUGE; OIL LEVEL |
1 |
1103-1901 |
|
A |
|
