| 79 |
I8-98010 297-A |
|
GUIDE; FAN, RAD |
1 |
1103- |
|
A |
|
| 427 |
I1-09470 009-A |
|
CLIP; FAN GUIDE |
1 |
1103- |
|
A |
|
| 16 |
I8-97239 187-0 |
|
CAP; RAD |
1 |
1103- |
|
A |
|
| 64 |
I0-91610 510-0 |
|
WASHER; STAY TO RAD |
2 |
1103- |
|
A |
ID=10.5 |
| 117 |
I1-09337 027-0 |
|
RUBBER; MTG, FAN GUIDE |
6 |
1103- |
|
A |
|
| 75 |
I1-21466 007-3 |
|
BOLT; CUSHION RUBBER, RAD |
2 |
1103- |
|
A |
M12X26.5,k110X19 L=86.5 |
| 2 |
I8-97350 995-0 |
|
GUIDE; FAN |
1 |
1103- |
|
A |
|
| 1 |
I8-98139 320-B |
|
RADIATOR ASM |
1 |
1402- |
|
A |
|
| 80 |
I1-21559 481-0 |
|
BOLT; FAN GUIDE |
4 |
1103- |
|
A |
(A) M6X16 |
| 70 |
I8-98018 941-0 |
|
STAY; RAD |
1 |
1103- |
|
A |
(A) |
| 59 |
I8-97359 052-0 |
|
PIN; SNAP, STAY |
2 |
1103- |
|
A |
L=32.6 |
| 70 |
I8-98010 657-0 |
|
STAY; RAD |
1 |
1103- |
|
A |
(B) |
| 80 |
I1-21559 481-0 |
|
BOLT; FAN GUIDE |
4 |
1103- |
|
A |
(A) M6X16 |
| 260 |
I0-28650 820-0 |
|
BOLT; BRKT 2 A |
2 |
1103- |
|
A |
N8X20 FLANGE IDN |
| 80 |
I0-28650 830-0 |
|
BOLT; FAN GUIDE |
3 |
1103- |
|
A |
(B) M8X30 FLANGE |
| 74 |
I1-09503 154-2 |
|
WASHER; PL, CUSHION RUBBER |
2 |
1103- |
|
A |
ID=8.4 OD=22 |
| 70 |
I8-98018 941-0 |
|
STAY; RAD |
1 |
1103- |
|
A |
(A) |
| 211 |
I8-98046 972-A |
|
HOSE; RAD TO PIPE |
1 |
1103- |
|
A |
|
| 89 |
I1-21469 153-0 |
|
BOLT |
2 |
1103- |
|
A |
(B) M8X25 |
| 232 |
I8-98141 232-A |
|
COLLAR; DIST CUSHION |
NULL |
1103- |
|
A |
|
| 89 |
I0-28050 812-A |
|
BOLT |
2 |
1103- |
|
A |
(A) M8X12 FLANGE |
| 78 |
I7-05110 010-A |
|
NUT; CUSHION RUBBER |
2 |
1103- |
|
A |
(A) M10 FLANGE |
| 78 |
I0-91180 212-0 |
|
NUT; CUSHION RUBBER |
2 |
1103- |
|
A |
(B) M12 FLANGE |
| 80 |
I1-21559 481-A |
|
BOLT; FAN GUIDE |
4 |
1103- |
|
A |
(A) M6X16 |
| 1 |
I8-98139 320-B |
|
RADIATOR ASM |
1 |
1110- |
|
A |
|
| 92 |
I8-97350 997-0 |
|
BRACKET; FAN GUIDE |
1 |
1103- |
|
A |
(A) |
| 96 |
I0-28151 020-0 |
|
BOLT; STAY FIX |
2 |
1103- |
|
A |
M10X20 FLANGE |
| 70 |
I8-98018 941-A |
|
STAY; RAD |
1 |
1103- |
|
A |
(A) |
| 267 |
I1-21467 023-A |
|
RUBBER; CUSHION |
2 |
1103- |
|
A |
|
| 51 |
I8-97171 437-0 |
|
PLUG; DRAIN |
1 |
1103- |
|
A |
VI/GASKET |
| 78 |
I7-05110 010-A |
|
NUT; CUSHION RUBBER |
2 |
1103- |
|
A |
(A) M10 FLANGE |
| 82 |
I8-98006 478-0 |
|
COVER; FAN, RAD |
1 |
1103- |
|
A |
|
| 73 |
I1-21467 011-1 |
|
RUBBER; CASHION , RAD MTG |
2 |
1103- |
|
A |
(B) T-24 |
| 427 |
I1-09470 009-0 |
|
CLIP; FAN GUIDE |
1 |
1103- |
|
A |
|
| 259 |
I8-98063 603-0 |
|
BRACKET; RAD STAY |
1 |
1103- |
|
A |
|
| 79 |
I8-98010 297-A |
|
GUIDE; FAN, RAD |
1 |
1103- |
|
A |
|
| 62 |
I0-28050 812-A |
|
BOLT; STAY |
2 |
1103- |
|
A |
M8X12 FLANGE |
| 82 |
I8-98006 478-A |
|
COVER; FAN, RAD |
1 |
1103- |
|
A |
|
| 79 |
I8-98010 297-A |
|
GUIDE; FAN, RAD |
1 |
1103- |
|
A |
|
| 267 |
I1-21467 023-0 |
|
RUBBER; CUSHION |
2 |
1103- |
|
A |
|
| 232 |
I8-98141 232-0 |
|
COLLAR; DIST CUSHION |
NULL |
1103- |
|
A |
|
| 211 |
I8-98046 972-A |
|
HOSE; RAD TO PIPE |
1 |
1103- |
|
A |
|
| 1 |
I8-98139 320-B |
|
RADIATOR ASM |
1 |
1103-1109 |
|
A |
|
| 427 |
I1-09470 009-0 |
|
CLIP; FAN GUIDE |
1 |
1103- |
|
A |
|
| 82 |
I8-98006 478-0 |
|
COVER; FAN, RAD |
1 |
1103- |
|
A |
|
| 261 |
I0-91180 108-0 |
|
NUT; BRKT |
2 |
1103- |
|
A |
H8 FLANGE |
| 73 |
I1-21467 004-0 |
|
RUBBER; CASHION , RAD MTG |
2 |
1103- |
|
A |
(A) T=14 |
| 232 |
I8-98141 232-0 |
|
COLLAR; DISt CUSHION |
NULL |
1103- |
|
NULL |
|
| 92 |
I8-97382 827-2 |
|
BRACKET; FAN GUIDE |
1 |
1103- |
|
A |
(C) |
| 267 |
I1-21467 023-0 |
|
RUBBER; CUSHION |
2 |
1103- |
|
A |
|
| 92 |
I8-97386 233-0 |
|
BRACKET; FAN GUIDE |
1 |
1103- |
|
A |
(B) |
