| 26 |
I8-98010 361-2 |
|
DUCT; AIR INT |
1 |
1103- |
|
A |
|
| 5 |
I8-98133 359-0 |
|
CLIP; AIR DUCT |
1 |
1103- |
|
A |
(A) ID=110-130 |
| 564 |
I8-98071 416-0 |
|
GASKET; ADAPTER |
1 |
1103- |
|
A |
|
| 56 |
I0-91610 708-0 |
C |
WASHER; LK, AIR INT DUCT |
2 |
1103-1109 |
|
A |
(B) ID=8.4 OD=22 |
| 5 |
I8-98133 349-0 |
|
CLIP; AIR DUCT |
1 |
1103- |
|
A |
(B) ID=55-75 |
| 357 |
I8-98133 357-0 |
|
CLIP; RUBBER HOSE |
1 |
1103- |
|
A |
(B) I D=75-95 |
| 368 |
I8-98065 377-0 |
|
SENSOR; TEMP |
1 |
1103- |
|
A |
|
| 487 |
I8-98073 592-0 |
|
PIPE; TURBO TO CHARGE AIR |
1 |
1103- |
|
A |
|
| 58 |
I8-98125 944-A |
|
SUP PORT AIR INL DUCT |
1 |
1103- |
|
A |
(B) |
| 225 |
I1-09623 057-0 |
|
GASKET; AIR PIPE |
2 |
1103- |
|
A |
ID=24.4 |
| 242 |
I8-98019 303-1 |
|
BRACKET; AIR DUCT |
1 |
1103- |
|
A |
(A) |
| 320 |
I8-98073 539-3 |
|
HOSE; CONN, ACL |
1 |
1103- |
|
A |
|
| 548 |
I8-98181 972-A |
A |
HOSE; RUBBER, TURBO TO INL |
1 |
1103- |
|
A |
(B) |
| 210 |
I0-28651 025-0 |
|
BOLT; ACL BRKT |
4 |
1103- |
|
A |
M10X25 FLANGE IDN |
| 379 |
I8-98075 713-A |
|
HOSE RUBBER |
1 |
1103- |
|
A |
|
| 357 |
I8-98025 921-0 |
|
CLIP; RUBBER HOSE |
2 |
1103- |
|
A |
(A) ID=24 |
| 488 |
I8-98010 723-A |
A |
HOSE; RUBBER PIPE |
1 |
1103- |
|
A |
|
| 450 |
I1-09707 157-0 |
|
CLAMP; HOSE |
1 |
1110- |
|
A |
|
| 560 |
I8-98061 675-0 |
|
FILTER; VERT ICAL DUCT |
2 |
1103- |
|
A |
|
| 58 |
I8-98125 944-A |
A |
SUP PORT AIR INL DUCT |
1 |
1103- |
|
A |
(B) |
| 245 |
I1-79998 228-0 |
|
PIECE; DIST, AIR DUCT |
2 |
1103- |
|
A |
|
| 530 |
I8-98133 357-0 |
|
CLAMP; AI R DUCT |
1 |
1103- |
|
A |
ID=75-95 |
| 155 |
I8-97233 428-0 |
|
BOLT; BRKT |
2 |
1103- |
|
A |
M10X17,M10X30 L=105 |
| 450 |
I1-09707 157-0 |
C |
CLAMP; HOSE |
1 |
1103-1109 |
|
A |
|
| 488 |
I8-98010 723-A |
|
HOSE; RUBBER PIPE |
1 |
1103- |
|
A |
|
| 49 |
I0-91110 508-0 |
C |
NUT; AIR DUCT |
1 |
1103-1109 |
|
A |
(B) M8 FLANGE |
| 56 |
I1-09985 177-0 |
|
WASHER; LK, AIR INT DUCT |
2 |
1103- |
|
A |
(A) ID=8.2 |
| 215 |
I8-98009 418-0 |
|
SENSOR; MAP |
1 |
1103- |
|
A |
|
| 49 |
I8-94327 073-0 |
C |
NUT; AIR DUCT |
2 |
1103-1109 |
|
A |
(C) M8 FLANGE IDN |
| 56 |
I0-91610 708-0 |
|
WASHER; LK, AIR INT DUCT |
2 |
1110- |
|
A |
(B) ID=8.4 OD=22 |
| 379 |
I8-98075 713-A |
A |
HOSE RUBBER |
1 |
1103- |
|
A |
|
| 48 |
I1-09030 044-1 |
|
BOLT; AIR DUCT |
2 |
1103- |
|
A |
M10X26 |
| 296 |
I0-91180 108-0 |
|
NUT; ACL |
4 |
1103- |
|
A |
M8 FLANGE |
| 49 |
I0-91110 508-0 |
|
NUT; AIR DUCT |
1 |
1110- |
|
A |
(B) M8 FLANGE |
| 252 |
I8-98010 639-1 |
|
DUC T; AIR INT |
1 |
1103- |
|
A |
|
| 353 |
I8-98096 418-0 |
|
CLIP; RUBBER HOSE |
2 |
1103- |
|
A |
(A) ID.-60-65 |
| 353 |
I8-98133 349-0 |
|
CLIP; RUBBER HOSE |
2 |
1103- |
|
A |
(B) ID.-55-75 |
| 480 |
I8-98086 417-0 |
|
ADAPTER |
1 |
1103- |
|
A |
|
| 211 |
I7-05110 010-A |
|
NUT; BRKT |
2 |
1103- |
|
A |
M10 FLANGE |
| 71 |
I8-98133 367-0 |
|
CLIP; AIR DUCT |
1 |
1103- |
|
A |
ID=120-140 |
| 61 |
I8-98074 570-0 |
|
BOLT; BRKT, AIR DUCT |
2 |
1103- |
|
A |
M8X25 FLANGE |
| 411 |
I8-94395 766-0 |
|
RUBBER; CUSHION |
2 |
1103- |
|
A |
(A) |
| 543 |
I0-36220 514-0 |
|
SCREW; SENSOR |
1 |
1103- |
|
A |
(B) M5X14 W/LK WASHER |
| 199 |
I8-97385 293-1 |
|
BRACKET; PIPE |
1 |
1103- |
|
A |
|
| 357 |
I8-98133 349-0 |
|
CLIP; RUBBER HOSE |
2 |
1103- |
|
A |
(C) I D=55-75 |
| 543 |
I0-36230 412-0 |
|
SCREW; SENSOR |
2 |
1103- |
|
A |
(A) M4X12 W/LK&PL WASHER |
| 548 |
I8-98181 971-A |
A |
HOSE; RUBBER, TURBO TO INL |
1 |
1103- |
|
A |
(A) |
| 474 |
I0-28650 840-0 |
|
BOLT; PIPE |
2 |
1103- |
|
A |
M8X40 FLANGE |
| 209 |
I8-98010 343-4 |
|
BRACKET; ACL |
1 |
1103- |
|
A |
|
| 242 |
I8-98019 302-1 |
|
BRACKET; AIR DUCT |
1 |
1103- |
|
A |
(C) |
| 232 |
I8-98067 929-0 |
|
HOSE; CONN |
1 |
1103- |
|
A |
|
| 157 |
I8-98010 719-3 |
|
PIPE; AIR |
1 |
1103- |
|
A |
|
| 316 |
I8-98152 269-0 |
|
RUBBER; CUSHION, DUCT |
1 |
1103- |
|
A |
|
| 242 |
I8-98019 301-2 |
|
BRACKET; AIR DUCT |
1 |
1103- |
|
A |
(B) |
| 49 |
I1-09984 126-0 |
|
NUT; AIR DUCT |
1 |
1103- |
|
A |
(A) M8 FLANGE |
| 49 |
I8-94327 073-0 |
|
NUT; AIR DUCT |
2 |
1110- |
|
A |
(C) M8 FLANGE IDN |
| 548 |
I8-98181 971-A |
|
HOSE; RUBBER, TURBO TO INL |
1 |
1103- |
|
A |
(A) |
| 548 |
I8-98181 972-A |
|
HOSE; RUBBER, TURBO TO INL |
1 |
1103- |
|
A |
(B) |
| 23 |
I1-09707 144-0 |
|
CLIP; HOSE |
1 |
1103- |
|
A |
ID=87-M6 |
| 411 |
I8-97105 689-A |
|
RUBBER; CUSHION |
2 |
1103- |
|
A |
(B) OD=23 |
| 58 |
I1-14119 267-0 |
|
SUP PORT AIR INL DUCT |
4 |
1103- |
|
A |
(A) OD=40 T=18.5 |
| 211 |
I7-05110 010-A |
C |
NUT; BRKT |
2 |
1103- |
|
A |
M10 FLANGE |
