| 290 |
I1-09811 002-1 |
|
BEARING; NEEDLE NTN |
2 |
1103- |
|
A |
|
| 1 |
I6-31240 949-0 |
|
DISC; CLUTCH |
1 |
1103- |
|
A |
|
| 92 |
I1-31214 060-0 |
|
SPRING; CLU |
8 |
1103-1209 |
|
A |
|
| 137 |
I0-28151 020-0 |
|
BOLT; CLU COVER |
12 |
1103- |
|
A |
M10X20 FLANGE |
| 131 |
I0-91510 508-0 |
|
WASHER; LK, SHIFT FORK |
1 |
1103- |
|
A |
ID=8.2 |
| 2 |
I1-31220 407-A |
|
PLATE ASM; PRESSURE, CLU |
1 |
1103- |
|
A |
|
| 161 |
I0-91180 208-0 |
|
NUT; BRKT |
4 |
1103- |
|
A |
(A) M8 FLANGE |
| 148 |
I1-09583 291-1 |
|
SPRING; CLU RETURN |
1 |
1103- |
|
A |
L=206.4 |
| 244 |
I1-09625 002-0 |
|
SEAL; DUST |
2 |
1103- |
|
A |
ALSO INCLUDED IN GASKET SET(M/T) . |
| 165 |
I1-47471 291-0 |
|
BRACKET; SPR EYE, MINI PACK, FLEX TUBE |
1 |
1103- |
|
A |
|
| 157 |
I0-28051 025-0 |
|
BOLT; BRKT |
1 |
1103- |
|
A |
(B) M10X25 FLANGE |
| 96 |
I1-31232 014-0 |
|
PIN; RELEASE LEVER |
4 |
1103- |
|
A |
(B) L=57.0 |
| 130 |
I0-61200 814-0 |
|
SCREW; SHIFT FORK |
1 |
1103- |
|
A |
M8X14 |
| 57 |
I1-31341 031-0 |
|
FORK; SHIFT, CLU |
1 |
1103- |
|
A |
|
| 84 |
I1-31221 136-0 |
|
PLATE; PRESSURE |
1 |
1210- |
|
A |
14 INCHI |
| 222 |
I1-31239 059-0 |
|
BOLT; STRAP |
4 |
1103- |
|
A |
IDN |
| 92 |
I1-31214 088-0 |
|
SPRING; CLU |
8 |
1210- |
|
A |
|
| 1 |
I1-31240 949-3 |
|
DISC; CLUTCH |
1 |
1103- |
|
A |
14" |
| 125 |
I1-31342 331-0 |
|
SHAFT; CLU |
1 |
1103- |
|
A |
|
| 155 |
I1-31429 464-0 |
|
BRACKET; MINIPACK |
1 |
1103- |
|
A |
(A) |
| 96 |
I1-31232 005-0 |
|
PIN; RELEASE LEVER |
4 |
1103- |
|
A |
(A) L-49.0 |
| 106 |
I1-31235 008-0 |
|
PLATE; LK, LEVER SUPPORT |
4 |
1103- |
|
A |
(B) |
| 89 |
I1-31229 001-0 |
|
PLATE; STRAP |
8 |
1103- |
|
A |
|
| 88 |
I1-31211 038-0 |
|
COVER SUB ASM; CLU |
1 |
1103- |
|
A |
|
| 154 |
I1-31424 007-0 |
|
PIN; JAW JOINT |
1 |
1103- |
|
A |
W/O PIN SNAP (1-09747 016-0) |
| 2 |
I6-31220 407-0 |
|
PLATE ASM; PRESSURE, CLU |
1 |
1103- |
|
A |
|
| 118 |
I1-31310 012-0 |
|
BEARING; CLU RELEASE |
1 |
1103- |
|
A |
|
| 128 |
I9-09867 008-1 |
|
KEY; FEATHER CLU SHAFT |
2 |
1103- |
|
A |
|
| 220 |
I8-98177 654-2 |
|
BOOSTER ASM; CLU |
1 |
1103- |
|
A |
SEE FIG-NO 2-07 FOR COMPONENT. |
| 91 |
I1-31219 012-0 |
|
SEAT; SPR |
8 |
1103- |
|
A |
(A) ID=37 H=25 |
| 1 |
I1-31240 949-3 |
|
DISC; CLUTCH |
1 |
1103- |
|
A |
14" |
| 155 |
I1-31429 465-1 |
|
BRACKET; MINIPACK |
1 |
1103- |
|
A |
(B) |
| 101 |
I1-31239 058-0 |
|
WASHER; RELEASE LEVER |
8 |
1103- |
|
A |
IDN |
| 140 |
I8-94410 361-0 |
|
PIN; STRAIGHT |
2 |
1103- |
|
A |
L=25 |
| 102 |
I9-08113 022-0 |
|
PIN; SPLIT, RELEASE LEVER |
8 |
1103- |
|
A |
OD=2.7 L=22 |
| 157 |
I0-28151 020-0 |
|
BOLT; BRKT |
2 |
1103- |
|
A |
(A) M10X20 FLANGE |
| 107 |
I1-31239 061-0 |
|
BOLT; LK PLATE |
8 |
1103- |
|
A |
IDN |
| 172 |
I1-87831 173-1 |
|
LEVER KIT; RELEASE, CLU |
1 |
1103- |
|
A |
|
| 84 |
I1-31221 129-0 |
|
PLATE; PRESSURE |
1 |
1103-1209 |
|
A |
|
| 91 |
I1-31219 013-0 |
|
SEAT; SPR |
8 |
1103- |
|
A |
(B) ID=37 H=15 |
| 106 |
I1-31239 019-0 |
|
PLATE; LK, LEVER SUPPORT |
4 |
1103- |
|
A |
(A) |
| 109 |
I0-91510 510-0 |
|
WASHER; LK, STRAP |
4 |
1103- |
|
A |
ID=10.2 |
| 164 |
I1-31426 019-1 |
|
EYE; SPRING |
1 |
1103- |
|
A |
|
| 1 |
I6-31240 949-0 |
|
DISC; CLUTCH |
1 |
1103- |
|
A |
14" |
| 105 |
I1-31235 014-0 |
|
NUT; SUPPORT |
4 |
1103- |
|
A |
IDN |
| 85 |
I9-31239 116-0 |
|
BUSHING; RELEASE LEVER |
1 |
1103- |
|
A |
|
| 161 |
I0-91180 108-0 |
|
NUT; BRKT |
1 |
1103- |
|
A |
(B) M8 FLANGE |
| 98 |
I1-31233 003-0 |
|
SPRING; RETURN |
4 |
1103- |
|
A |
|
| 119 |
I1-31329 024-0 |
|
SPRING; SHIFT FORK |
2 |
1103- |
|
A |
|
| 2 |
I1-31220 407-A |
|
PLATE ASM; PRESSURE, CLU |
1 |
1103- |
|
A |
|
