| 20 |
I6-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1103- |
|
A |
|
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1103- |
|
A |
M10 FLANGE |
| 19 |
I1-09587 088-1 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
12 |
1103- |
|
A |
OD=45.5 T=2.05 YELLOW |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG, 1ST |
1 |
1103- |
|
A A |
|
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1103- |
|
A A |
M10 FLANGE |
| 46 |
I8-98020 815-0 |
|
FLANGE; SPL INED, PROP SHAFT, 1ST |
1 |
1103- |
|
A A |
|
| 19 |
I1-09587 086-0 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
4 |
1103- |
|
A |
OD=45.5 T=1.95 BLUE |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1103-1109 |
|
A |
M14 |
| 25 |
I8-98020 889-0 |
|
NIPPLE; GREASE, CENTER BRG |
1 |
1103- |
|
A |
|
| 21 |
I1-09625 161-0 |
|
SEAL; OIL, CENTER BRG |
2 |
1103- |
|
A A |
ID=54 |
| 52 |
I0-91510 814-0 |
|
WASHER; LK, YOKE |
4 |
1103- |
|
A |
ID=14.2 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST, SPIDER |
4 |
1103- |
|
A |
|
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
3 |
1103- |
|
A |
|
| 19 |
I1-09587 087-2 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
12 |
1103- |
|
A |
OD=45.5 T=2.00 WHITE |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
1 |
1103- |
|
A |
|
| 22 |
I1-37516 059-0 |
|
RUBBER; CUSHION, CENTER BRG, 1ST |
1 |
1103- |
|
A A |
|
| 14 |
I8-98020 800-0 |
|
COVER; DUST, SPIDER |
12 |
1103- |
|
A |
|
| 104 |
I1-09600 064-0 |
|
PLUG; SLEEVE YOKE |
1 |
1103- |
|
A |
|
| 9 |
I6-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
3 |
1103- |
|
A |
|
| 19 |
I1-09587 087-2 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
4 |
1103- |
|
A |
OD=45.5 T=2.00 WHITE |
| 1 |
I8-98069 657-0 |
|
SHAFT; PROP |
1 |
1103- |
|
A |
(A) L=1271 |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1110- |
|
A A |
M14 |
| 71 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1103-1109 |
|
A |
M14 |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1103- |
|
A |
M10 FLANGE |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1103- |
|
A A |
M10 FLANGE |
| 1 |
I8-98069 609-0 |
|
SHAFT; PROP |
1 |
1103- |
|
A |
(C) L=629 |
| 172 |
I1-37515 121-0 |
|
BRACKET; CENTER BRG |
1 |
1103- |
|
A |
(B) |
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE, PROP SHAFT |
1 |
1103- |
|
A |
|
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1103-1109 |
|
A A |
M14 |
| 19 |
I1-09587 088-1 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
4 |
1103- |
|
A |
OD=45.5 T=2.05 YELLOW |
| 23 |
I9-00090 071-0 |
|
BEARING; CENTER, PROP SHAFT |
1 |
1103- |
|
A A |
|
| 63 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT, PROP SHAFT, 1ST |
4 |
1103- |
|
A A |
M10X35 FLANGE IDN |
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE, TRANS |
4 |
1103- |
|
A |
M14X37 |
| 51 |
I8-97160 857-0 |
|
NUT; FLANGE, SPL INED |
1 |
1103- |
|
A A |
M30 |
| 1 |
I8-98105 706-0 |
|
SHAFT; PROP |
1 |
1103- |
|
A |
(B) L=1264 |
| 19 |
I1-09587 086-0 |
|
RING; SNAP, JOURNAL, PROP SHAFT, 1ST |
12 |
1103- |
|
A |
OD=45.5 T=1.95 BLUE |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE, PROP SHAFT |
3 |
1103- |
|
A |
PT1/8 ELBOW |
| 60 |
I0-91614 610-0 |
|
WASHER; PL, RET TO BRKT |
4 |
1103- |
|
A |
1D=10.5 OD=22 |
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE, PROP SHAFT |
3 |
1103- |
|
A |
|
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1110- |
|
A |
M14 |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1103- |
|
A |
M10 FLANGE |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1103- |
|
A |
M10 FLANGE |
| 57 |
I0-91510 814-0 |
|
WASHER; LK, YOKE |
4 |
1103- |
|
A A |
ID=14.2 |
| 72 |
I0-91510 814-0 |
|
WASHER; LK, YOKE |
4 |
1103- |
|
A |
ID=14.2 |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1103- |
|
A A |
M10X25 FLANGE 1DN |
| 106 |
I0-90301 406-0 |
|
NIPPLE; GREASE, YOKE, PROP SHAFT |
1 |
1103- |
|
A |
M6 STRAIGHT IDN |
| 128 |
I1-37247 024-0 |
|
SEAL; SLEEVE |
1 |
1103- |
|
A |
|
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE, PROP SHAFT |
1 |
1103- |
|
A |
PT1/8 ELBOW |
| 71 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1110- |
|
A |
M14 |
| 225 |
I8-98020 885-0 |
|
YOKE; SLEEVE PROP SHAFT |
1 |
1103- |
|
A |
L=254 |
| 45 |
I0-91614 610-0 |
|
WASHER; PL, RET TO BRKT |
4 |
1103- |
|
A |
ID=10.5 OD=22 |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR, PROP SHAFT |
1 |
1103- |
|
A A |
|
| 172 |
I1-37515 119-0 |
|
BRACKET; CENTER BRG |
1 |
1103- |
|
A |
( A) |
