| 7 |
I1-09625 005-1 |
|
SEAL; OIL, KING PIN |
2 |
1103- |
|
A |
|
| 30 |
I1-43171 312-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.175 |
| 30 |
I1-43171 321-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.287 |
| 30 |
I1-43171 324-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.325 |
| 1 |
I8-98057 479-2 |
A |
AXLE; FRT |
1 |
1103- |
|
A |
|
| 66 |
I1-09442 021-1 |
C |
NUT; TIE ROD END |
2 |
1103-1109 |
|
A |
M16 SLOTTED |
| 3 |
I1-87831 295-A |
|
KING PIN SET |
1 |
1103- |
R |
A |
|
| 61 |
I1-43150 748-1 |
|
ROD END; TIE ROD |
1 |
1103- |
R |
A |
|
| 30 |
I1-43171 319-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.262 |
| 30 |
I1-43171 278-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.112 |
| 2 |
I8-98172 432-1 |
|
KNUCKLE; FRT AXLE |
1 |
1103- |
L |
A |
|
| 30 |
I1-43171 280-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.137 |
| 30 |
I1-43171 315-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.212 |
| 30 |
I1-43171 274-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.062 |
| 30 |
I1-43171 266-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.962 |
| 30 |
I1-43171 271-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.025 |
| 61 |
I1-43150 749-1 |
|
ROD END; TIE ROD |
1 |
1103- |
L |
A |
|
| 30 |
I1-43171 281-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.150 |
| 3 |
I1-87831 296-A |
A |
KING PIN SET |
1 |
1103- |
L |
A |
|
| 30 |
I1-43171 279-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.125 |
| 30 |
I1-43171 275-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.075 |
| 30 |
I1-43171 314-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.200 |
| 2 |
I8-98172 431-1 |
|
KNUCKLE; FRT AXLE |
1 |
1103- |
R |
A |
|
| 304 |
I9-09164 512-0 |
|
WASHER; PL |
2 |
1110- |
|
A |
IO=12.5 |
| 30 |
I1-43171 316-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.225 |
| 30 |
I1-43171 320-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.275 |
| 3 |
I1-87831 296-A |
|
KING PIN SET |
1 |
1103- |
L |
A |
|
| 30 |
I1-43171 325-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.337 |
| 21 |
I0-90301 510-0 |
|
NIPPLE; GREASE, KING PIN |
2 |
1103- |
|
A |
(B) PT1/8 ELBOW 67.5. |
| 30 |
I1-43171 268-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.987 |
| 47 |
I0-91614 712-0 |
|
WASHER; PL, COVER, KING PIN |
2 |
1103- |
|
A |
ID=12.5 OD-32 |
| 17 |
I8-98065 261-0 |
|
BOLT; STOPPER KNUCKLE |
2 |
1103- |
|
A |
(B) M14X53 |
| 30 |
I1-43171 322-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.300 |
| 36 |
I8-98037 304-1 |
|
ARM; KNUCKLE |
1 |
1103- |
|
A |
|
| 48 |
I1-09009 081-0 |
|
BOLT; COVER |
2 |
1103- |
|
A |
M12X25 |
| 30 |
I1-43171 311-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.162 |
| 46 |
I0-91510 812-0 |
|
WASHER; LK, COVER |
2 |
1103- |
|
A |
ID=12.2 |
| 82 |
I1-51771 123-0 |
|
BAR; STAB,FRT SUSP |
1 |
1408- |
|
A |
|
| 17 |
I1-09009 058-0 |
|
BOLT; STOPPER KNUCKLE |
1 |
1110- |
|
A |
(A) M14X47 |
| 30 |
I1-43171 267-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.975 |
| 304 |
I9-09164 512-0 |
C |
WASHER; PL |
2 |
1103-1109 |
|
A |
IO=12.5 |
| 18 |
I0-91112 814-0 |
|
NUT; STOPPER BOLT, KNUCKLE |
3 |
1103- |
|
A |
M14 |
| 30 |
I1-43171 269-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.000 |
| 9 |
I8-97329 621-0 |
|
PLUG; KNUCKLE |
1 |
1103- |
|
A |
M14X14 |
| 30 |
I1-43171 264-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.937 |
| 30 |
I1-43171 263-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.925 |
| 30 |
I1-43171 270-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.012 |
| 30 |
I1-43171 276-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.087 |
| 33 |
I0-91110 510-0 |
|
NUT; KEY BOLT |
2 |
1103- |
|
A |
M10 |
| 8 |
I1-09811 339-0 |
|
BEARING; NEEDLE, KING PIN |
8 |
1103- |
|
A |
NSK |
| 30 |
I1-43171 323-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.312 |
| 30 |
I1-43171 318-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.250 |
| 30 |
I1-43171 313-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.187 |
| 59 |
I1-09449 082-0 |
|
NUT; TIE ROD ARM |
2 |
1103- |
|
A |
M27 FLANGE |
| 17 |
I1-09009 058-0 |
C |
BOLT; STOPPER KNUCKLE |
1 |
1103-1109 |
|
A |
(A) M14X47 |
| 305 |
I1-43175 030-0 |
|
COVER; KNUCKLE |
2 |
1103- |
|
A |
|
| 44 |
I1-43175 031-0 |
|
COVER; KING PIN |
2 |
1103- |
|
A |
|
| 21 |
I0-90301 410-0 |
|
NIPPLE; GREASE, KING PIN |
2 |
1103- |
|
A |
( A) PT1/8 STRAIGHT |
| 30 |
I1-43171 261-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.900 |
| 25 |
I1-09829 031-0 |
|
BEARING; THRUST, KING PIN |
1 |
1103- |
R |
A |
NSK |
| 1 |
I8-98057 479-2 |
|
AXLE; FRT |
1 |
1103- |
|
A |
|
| 30 |
I1-43171 277-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.100 KING PIN |
| 30 |
I1-43171 317-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.237 |
| 81 |
I8-98038 703-1 |
|
ROD; TIE |
1 |
1103- |
|
A |
|
| 275 |
I1-85574 063-0 |
|
BOOT; ROD END, TIE |
2 |
1110- |
|
A |
|
| 30 |
I1-43171 265-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=3.950 |
| 34 |
I0-91510 510-0 |
|
WASHER; LK, KEY |
2 |
1103- |
|
A |
ID=10.2 |
| 30 |
I1-43171 272-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.037 |
| 66 |
I1-09442 021-1 |
|
NUT; TIE ROD END |
2 |
1110- |
|
A |
M16 SLOTTED |
| 11 |
I1-09589 017-1 |
|
RING; SNAP, KNUCKLE PLUG |
2 |
1103- |
|
A |
|
| 30 |
I1-43171 326-0 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.350 |
| 30 |
I1-43171 262-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T-3.912 |
| 74 |
I7-05012 010-A |
|
NUT; TIE ROD END |
2 |
1110- |
|
A |
M12 |
| 32 |
I1-43116 013-0 |
|
BOLT; KEY, K ING PIN |
2 |
1103- |
|
A |
|
| 80 |
I0-81124 022-0 |
|
PIN; SPLIT, ROD |
2 |
1103- |
|
A |
OD=3.7 L=22 |
| 3 |
I1-87831 295-A |
A |
KING PIN SET |
1 |
1103- |
R |
A |
|
| 68 |
I0-28061 245-0 |
|
BOLT; TIE ROD END |
2 |
1103- |
|
A |
M12X45 FLANGE |
| 25 |
I1-09829 033-1 |
|
BEARING; THRUST, KING PIN |
1 |
1103- |
L |
A |
NSK |
| 275 |
I1-85574 063-0 |
C |
BOOT; ROD END, TIE |
2 |
1103-1109 |
|
A |
|
| 58 |
I8-98037 296-2 |
|
ARM; TIE ROD |
1 |
1110- |
|
A |
|
| 30 |
I1-43171 273-1 |
|
WASHER; THRUST, KING PIN |
NULL |
1103- |
|
A |
T=4.050 |
| 74 |
I0-91110 512-0 |
C |
NUT; TIE ROD END |
2 |
1103-1109 |
|
A |
M12 |
| 58 |
I8-98037 296-2 |
C |
ARM; TIE ROD |
1 |
1103-1109 |
|
A |
|
