| 304 |
I7-05110 010-A |
C |
NUT; BRKT |
2 |
1111- |
|
A |
(B) M10 FLANGE |
| 32 |
I8-98157 878-A |
|
PIPE; DELIVERY,FUEL TANK |
1 |
1301- |
|
A |
( C ) L=300 |
| 174 |
I8-98188 894-A |
A |
PIPE; FUEL,FEED,FRT |
1 |
1111- |
|
A |
|
| 32 |
I0-01508 310-0 |
|
PIPE; DELIVERY,FUEL TANK |
1 |
1111- |
|
A |
(A) L=310 |
| 303 |
I0-28650 840-0 |
|
BOLT; BRKT |
1 |
1111- |
|
A |
(A) M8X40 FLANGE |
| 279 |
I0-91614 710-0 |
|
WASHER |
2 |
1111- |
|
A |
ID=10.5 OD=26 |
| 47 |
I8-98188 895-A |
A |
PIPE; FUEL,RETURN |
1 |
1111- |
|
A |
L=1058 |
| 97 |
I8-98183 587-0 |
|
BRACKET; CLIP |
1 |
1111- |
|
A |
(B) |
| 418 |
I8-98128 254-0 |
|
BRACKET; PRE FUEL FILTER |
1 |
1111- |
|
A |
|
| 83 |
I0-91180 108-0 |
|
NUT; CLIP,FUEL TANK |
3 |
1111- |
|
A |
M8 FLANGE |
| 41 |
I8-98008 098-0 |
C |
CLIP; FUEL PIPE,FUEL TANK |
2 |
1201- |
|
A |
LOCALLY SUPPLIED PARTS<TKH> (D) ID=16 IDN |
| 29 |
I0-01259 300-0 |
|
HOSE; FUEL |
1 |
1111- |
|
A |
(C) L=60 SERVICED BY L=30 00 |
| 32 |
I0-01260 300-0 |
|
PIPE; DELIVERY,FUEL TANK |
1 |
1111- |
|
A |
(B) L=140 SERVICED BY L=30 00 |
| 634 |
I7-00108 114-A |
|
HOSE; RUBBER RETURN |
1 |
1201- |
|
A |
EXC. LOCALLY SUPPLIED PARTS<TKH> IDN |
| 82 |
I8-94169 028-0 |
|
CLIP; FUEL HOSE |
1 |
1111- |
|
A |
ID=13 & 16.5 |
| 39 |
I8-98122 953-A |
A |
PIPE; FUEL |
2 |
1111- |
|
A |
(B) |
| 41 |
I1-09700 606-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
1 |
1111- |
|
A |
(F) ID=15 H=24 L=2 0 |
| 634 |
I7-00108 114-A |
|
HOSE; RUBBER RETURN |
1 |
1111-1112 |
|
A |
IDN |
| 41 |
I8-98008 098-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
4 |
1201- |
|
A |
EXC. LOCALLY SUPPLIED PARTS<TKH> (D) ID=16 IDN |
| 32 |
I7-00110 105-A |
|
PIPE; DELIVERY,FUEL TANK |
1 |
1111- |
|
A |
(D) L=780 IDN |
| 41 |
I8-98008 098-0 |
C |
CLIP; FUEL PIPE,FUEL TANK |
4 |
1111-1112 |
|
A |
(D) ID=16 IDN |
| 634 |
I7-00108 114-A |
C |
HOSE; RUBBER RETURN |
1 |
1201- |
|
A |
EXC. LOCALLY SUPPLIED PARTS<TKH> IDN |
| 304 |
I7-05110 010-A |
C |
NUT; BRKT |
2 |
1111- |
|
A |
(B) M10 FLANGE |
| 97 |
I8-98126 612-0 |
|
BRACKET; CLIP |
1 |
1111- |
|
A |
(A) |
| 29 |
I8-98188 724-A |
|
HOSE; FUEL |
1 |
1301- |
|
A |
(A) |
| 227 |
I8-98179 497-0 |
|
BRACKET; FUEL SEDIMENTER |
1 |
1111- |
|
A |
|
| 32 |
I7-00110 105-A |
C |
PIPE; DELIVERY,FUEL TANK |
1 |
1111- |
|
A |
(D) L=780 IDN |
| 29 |
I8-98188 724-A |
|
HOSE; FUEL |
1 |
1111- |
|
A |
(A) |
| 174 |
I8-98188 894-A |
|
PIPE; FUEL,FEED,FRT |
1 |
1111- |
|
A |
|
| 303 |
I0-28651 035-0 |
|
BOLT; BRKT |
2 |
1111- |
|
A |
(B) M10X35 FLANGE IDN |
| 304 |
I7-05110 010-A |
|
NUT; BRKT |
2 |
1111- |
|
A |
(B) M10 FLANGE |
| 97 |
I1-47475 427-1 |
|
BRACKET; CLIP |
1 |
1111- |
|
A |
(C) |
| 39 |
I8-98009 438-A |
A |
PIPE; FUEL |
1 |
1111- |
|
A |
(A) IDN |
| 634 |
I7-00108 114-A |
C |
HOSE; RUBBER RETURN |
1 |
1111-1112 |
|
A |
IDN |
| 55 |
I1-09360 677-1 |
|
COVER; PIPE,FUEL TANK |
2 |
1111- |
|
A |
L=150 SERVICED BY L=1300 |
| 41 |
I1-09700 688-0 |
C |
CLIP; FUEL PIPE,FUEL TANK |
3 |
1111- |
|
A |
(B) ID=11 & 9 L=17.5 & 17.5 |
| 634 |
I8-98211 102-0 |
|
HOSE; RUBBER RETURN |
1 |
1201- |
|
A |
LOCALLY SUPPLIED PARTS<TKH> |
| 41 |
I1-09700 688-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
3 |
1111- |
|
A |
(B) ID=11 & 9 L=17.5 & 17.5 |
| 39 |
I8-98122 953-A |
|
PIPE; FUEL |
2 |
1111- |
|
A |
(B) |
| 39 |
I8-98009 438-A |
|
PIPE; FUEL |
1 |
1111- |
|
A |
(A) IDN |
| 41 |
I8-98150 357-0 |
C |
CLIP; FUEL PIPE,FUEL TANK |
6 |
1111- |
|
A |
(A) ID=13 IDN |
| 303 |
I0-28650 835-0 |
|
BOLT; BRKT |
4 |
1111- |
|
A |
(A) M8X35 FLANGE |
| 29 |
I8-98196 274-0 |
|
HOSE; FUEL |
1 |
1111- |
|
A |
(B) |
| 304 |
I7-05110 010-A |
|
NUT; BRKT |
2 |
1111- |
|
A |
(B) M10 FLANGE |
| 228 |
I0-28650 820-0 |
|
BOLT; BRKT,SEDIMENTER |
2 |
1111- |
|
A |
(C) M8X2 0 FLANGE IDN |
| 228 |
I0-28051 050-0 |
|
BOLT; BRKT,SEDIMENTER |
2 |
1111- |
|
A |
(B) M10X50 FLANGE |
| 80 |
I0-28650 820-0 |
|
BOLT; CLIP,FUEL TANK |
2 |
1111- |
|
A |
M8X2 0 FLANGE IDN |
| 41 |
I8-98008 098-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
2 |
1201- |
|
A |
LOCALLY SUPPLIED PARTS<TKH> (D) ID=16 IDN |
| 41 |
I5-09707 030-1 |
|
CLIP; FUEL PIPE,FUEL TANK |
3 |
1111- |
|
A |
(E) L=250 IDN |
| 345 |
I8-97329 623-0 |
|
PLUG |
2 |
1111- |
|
A |
NPTF3/8-18 |
| 41 |
I1-09704 102-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
6 |
1111- |
|
A |
(C) ID=14 IDN |
| 304 |
I0-91180 108-0 |
|
NUT; BRKT |
3 |
1111- |
|
A |
(A) M8 FLANGE |
| 228 |
I0-28050 825-0 |
|
BOLT; BRKT,SEDIMENTER |
2 |
1111- |
|
A |
(A) M8X25 FLANGE |
| 41 |
I8-98150 357-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
6 |
1111- |
|
A |
(A) ID=13 IDN |
| 41 |
I8-98008 098-0 |
|
CLIP; FUEL PIPE,FUEL TANK |
4 |
1111-1112 |
|
A |
(D) ID=16 IDN |
| 41 |
I8-98008 098-0 |
C |
CLIP; FUEL PIPE,FUEL TANK |
4 |
1201- |
|
A |
EXC. LOCALLY SUPPLIED PARTS<TKH> (D) ID=16 IDN |
| 47 |
I8-98188 895-A |
|
PIPE; FUEL,RETURN |
1 |
1111- |
|
A |
L=1058 |
| 32 |
I8-98157 878-A |
|
PIPE; DELIVERY,FUEL TANK |
1 |
1111- |
|
A |
(C) L=300 |
