| 56 |
I1-47169 033-0 |
|
WASHER; ADJ CAM,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 8 |
I1-47119 017-1 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1111- |
|
A |
L=73.5 |
| 111 |
I1-47159 080-0 |
|
COVER; WHEEL CYL |
2 |
1111- |
|
A |
|
| 6 |
I1-47126 759-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
8 |
1111- |
|
A |
|
| 55 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1111- |
|
A |
|
| 9 |
I1-09583 185-2 |
|
SPRING; RETURN,BRK SHOE |
2 |
1111- |
|
A |
|
| 54 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1111- |
|
A |
|
| 3 |
I1-88311 354-1 |
|
LINING SET; RR BRK,OVER SIZE |
2 |
1111- |
|
A |
|
| 62 |
I1-47169 030-0 |
|
PIN; ADJ CAM SPINDLE,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 94 |
I1-47601 220-0 |
|
CYLINDER; WHEEL,RR BRK |
2 |
1111- |
|
A |
|
| 57 |
I1-47169 046-0 |
|
SPRING; ADJ CAM,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 9 |
I1-47619 011-0 |
|
CAP; BLEEDER,RR WHEEL CYL |
2 |
1111- |
|
A |
OD=12 |
| 51 |
I1-47165 059-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
1111- |
|
A |
(B) |
| 5 |
I1-47126 758-0 |
|
LINING; RR BRK SHOE,STANDARD |
8 |
1111- |
|
A |
|
| 2 |
I1-88311 353-1 |
|
LINING SET; RR BRK,STANDARD |
2 |
1111- |
|
A |
|
| 4 |
I1-47112 011-0 |
|
BUSHING; BRK SHOE,RR WHEEL |
4 |
1111- |
|
A |
|
| 51 |
I1-47165 058-1 |
|
CAM ASM; SHOE ADJ,RR WHEEL BRK |
2 |
1111- |
|
A |
(A) |
| 25 |
I1-47151 458-2 |
|
COVER SET; RR BRK DRUM |
2 |
1111- |
|
A |
|
| 11 |
I1-47131 038-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1111- |
|
A |
L=106.5 |
| 99 |
I1-47624 302-0 |
|
PISTON; RR WHEEL CYL |
4 |
1111- |
|
A |
|
| 100 |
I1-47621 009-0 |
|
ROD; PUSH,RR WHEEL CYL |
4 |
1111- |
|
A |
|
| 7 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
80 |
1111- |
|
A |
L=18.5 |
| 1 |
I1-47170 441-0 |
|
SHOE; BRK,RR |
4 |
1111- |
|
A |
|
| 27 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1111- |
|
A |
|
| 58 |
I1-47169 034-0 |
|
BOOT; ADJ CAM,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 53 |
I0-20851 016-0 |
|
BOLT; LOCK PLATE |
2 |
1111- |
|
A |
M10X16 |
| 60 |
I1-47169 031-0 |
|
COVER; ADJ CAM BOOT,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 112 |
I0-50551 232-0 |
|
BOLT; WHEEL CYL SETTING |
4 |
1111- |
|
A |
M12X32 W/LK WASHER |
| 30 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1111- |
|
A |
M10X12 |
| 15 |
I1-47116 002-0 |
|
PIN; GUIDE,ADJ CAM,RR WHEEL BRK |
4 |
1111- |
|
A |
|
| 61 |
I1-47169 032-1 |
|
INDICATOR; WEAR,RR BRK SHOE |
4 |
1111- |
|
A |
|
| 9 |
I1-09580 019-0 |
|
SPRING; RR WHEEL CYL |
2 |
1111- |
|
A |
|
| 47 |
I1-47137 112-4 |
|
BRACKET; ANCHOR PIN,RR WHEEL BRK |
2 |
1111- |
|
A |
|
| 25 |
I1-47151 458-2 |
|
COVER SET; RR BRK DRUM |
2 |
1111- |
|
A |
|
| 96 |
I1-47615 005-0 |
|
SCREW; BLEEDER,RR BRK |
2 |
1111- |
|
A |
L=66.5 |
| 95 |
I1-87830 886-0 |
|
CUP SET; RR WHEEL CYL |
2 |
1111- |
|
A |
|
