| 45 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
1111- |
|
ABC |
ID=10.5 OD=22 |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1111-1111 |
|
ABC |
1ST |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1111- |
|
BC |
M10 FLANGE |
| 106 |
I0-90301 406-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
1111- |
|
ABC |
M6 STRAIGHT IDN |
| 22 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
1 |
1111- |
|
BC |
|
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
1111- |
|
BC |
M14X37 |
| 1 |
I8-98069 590-0 |
|
SHAFT; PROP |
1 |
1111- |
|
C |
(C) L=1234 |
| 46 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1111-1111 |
|
ABC |
1ST |
| 57 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
1203- |
|
ABC |
ID=14.2 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1112- |
|
ABC |
|
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
8 |
1111- |
|
ABC |
END |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1111-1111 |
|
ABC |
1ST |
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1111-1111 |
|
A |
(A) |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
BC |
M14 |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
BC |
M14 |
| 128 |
I1-37247 024-0 |
|
SEAL; SLEEVE |
1 |
1111- |
|
ABC |
|
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
1 |
1111- |
|
BC |
PT1/8 ELBOW |
| 63 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
1111- |
|
ABC |
M10X3 5 FLANGE IDN |
| 1 |
I8-98090 992-0 |
|
SHAFT; PROP |
1 |
1111- |
|
C |
(A) L=1351 |
| 21 |
I1-09625 161-0 |
|
SEAL; OIL,CENTER BRG |
2 |
1111- |
|
BC |
ID=54 |
| 22 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
1 |
1111- |
|
ABC |
|
| 25 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
1111- |
|
ABC |
|
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
ABC |
M14 |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1112- |
|
ABC |
|
| 57 |
I0-91510 814-0 |
|
WASHER; LK,YOKE |
4 |
1111-1202 |
|
ABC |
ID=14.2 |
| 21 |
I1-09625 161-0 |
|
SEAL; OIL,CENTER BRG |
2 |
1111- |
|
ABC |
ID=54 |
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1111- |
|
ABC |
OD=45.5 T=2.05 YELLOW |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
AR |
1111- |
|
ABC |
|
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1111- |
|
ABC |
M10 FLANGE |
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1111- |
|
ABC |
OD=45.5 T=1.95 BLUE |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1111-1111 |
|
BC |
2ND |
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
1111- |
|
ABC |
M14X37 |
| 23 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
1 |
1111- |
|
BC |
|
| 25 |
I8-98020 889-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
1111- |
|
BC |
2ND |
| 46 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1111-1111 |
|
BC |
2ND |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
1 |
1111- |
|
ABC |
PT1/8 ELBOW |
| 1 |
I8-98083 013-0 |
|
SHAFT; PROP |
1 |
1112- |
|
AB |
(B) L=1084 |
| 1 |
I8-98083 013-0 |
|
SHAFT; PROP |
1 |
1111-1111 |
|
B |
(B) L=1084 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1111-1111 |
|
ABC |
1ST IDN |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1112- |
|
BC |
|
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1111- |
|
ABC |
OD=45.5 T=2.0 0 WHITE |
| 46 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1112- |
|
ABC |
|
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1111-1111 |
|
BC |
(A) |
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1112- |
|
ABC |
(A) |
| 172 |
I1-37515 134-0 |
|
BRACKET; CENTER BRG |
1 |
1512- |
|
E |
(A) WB 6500MM |
| 23 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
1 |
1111- |
|
ABC |
|
| 1 |
I8-98180 201-0 |
|
SHAFT; PROP |
1 |
1111- |
|
B |
(C) L=584 |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1111- |
|
BC |
M10X2 5 FLANGE IDN |
| 46 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1112- |
|
BC |
|
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
ABC |
OD=45.5 T=2.05 YELLOW |
| 172 |
I1-37515 135-0 |
|
BRACKET; CENTER BRG |
1 |
1111- |
|
C |
(B) |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1111-1111 |
|
BC |
2ND |
| 60 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
1111- |
|
BC |
ID=10.5 OD=22 |
| 51 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
1 |
1111- |
|
ABC |
M3 0 |
| 46 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1111-1111 |
|
ABC |
1ST |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
4 |
1111- |
|
ABC |
|
| 225 |
I8-98020 885-0 |
|
YOKE; SLEEVE,PROP SHAFT |
1 |
1111- |
|
ABC |
L=254 |
| 52 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
1203- |
|
BC |
ID=14.2 |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
2 |
1111- |
|
ABC |
PT1/8 ELBOW |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1112- |
|
BC |
|
| 57 |
I0-91510 614-0 |
|
WASHER; LK,YOKE |
4 |
1203- |
|
ABC |
ID=14 . 2 |
| 1 |
I8-98090 989-0 |
|
SHAFT; PROP |
1 |
1111- |
|
A |
(A) L=1226 |
| 1 |
I8-98116 103-0 |
|
SHAFT; PROP |
1 |
1111- |
|
C |
(B) L=1454 |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
AR |
1111- |
|
ABC |
|
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
2 |
1111- |
|
ABC |
(B) |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1111- |
|
ABC |
M10X2 5 FLANGE IDN |
| 71 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1111- |
|
ABC |
M16 FLANGE |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
ABC |
M14 |
| 57 |
I0-91510 814-0 |
|
WASHER; LK,YOKE |
4 |
1111-1202 |
|
ABC |
ID=14.2 |
| 52 |
I0-91510 814-0 |
|
WASHER; LK,YOKE |
4 |
1111-1202 |
|
BC |
ID=14.2 |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1112- |
|
ABC |
|
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1111- |
|
BC |
M10 FLANGE |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
ABC |
M14 |
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
ABC |
OD=45.5 T=2.0 0 WHITE |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1111- |
|
ABC |
M10 FLANGE |
| 20 |
I6-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1111- |
|
BC |
2ND |
| 1 |
I1-37151 640-1 |
|
SHAFT; PROP |
1 |
1111-1111 |
|
A |
(B) L=1091 |
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
1111- |
|
ABC |
M14X37 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1111-1111 |
|
ABC |
1ST IDN |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
8 |
1111- |
|
ABC |
|
| 172 |
I1-37515 102-0 |
|
BRACKET; CENTER BRG |
1 |
1111- |
|
ABC |
(A) |
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
ABC |
OD=45.5 T=1.95 BLUE |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1111- |
|
ABC |
M10 FLANGE |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1111- |
|
ABC |
M10 FLANGE |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1111-1111 |
|
BC |
2ND |
| 51 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
1 |
1111- |
|
BC |
M3 0 |
| 1 |
I8-98069 684-0 |
|
SHAFT; PROP |
1 |
1111- |
|
B |
(A) L=1366 |
| 9 |
I1-37300 129-0 |
|
JOURNAL ASM; PROP SHAFT |
AR |
1111- |
|
A |
1ST (WB4200MM) |
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
BC |
OD=45.5 T=1.95 BLUE |
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
BC |
OD=45.5 T=2.0 0 WHITE |
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1111-1111 |
|
A |
(A) |
| 104 |
I1-09600 064-0 |
|
PLUG; SLEEVE YOKE |
1 |
1111- |
|
ABC |
|
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1111- |
|
ABC |
M14 |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1112- |
|
BC |
|
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1111- |
|
BC |
M10 FLANGE |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
4 |
1111- |
|
BC |
|
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1111- |
|
BC |
M10 FLANGE |
| 63 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
1111- |
|
BC |
M10X3 5 FLANGE IDN |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1111-1111 |
|
ABC |
1ST |
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1111- |
|
BC |
OD=45.5 T=2.05 YELLOW |
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1111- |
|
BC |
(B) |
| 172 |
I1-37515 074-1 |
|
BRACKET; CENTER BRG |
1 |
1111- |
|
B |
(B) |
