| 8 |
I9-00096 243-0 |
|
BEARING; NEEDLE,KING PIN |
2 |
1111- |
|
A |
(B) NTN |
| 304 |
I9-09164 512-0 |
|
WASHER; PL |
4 |
1111- |
|
A |
ID=12.5 |
| 73 |
I1-43159 133-0 |
|
NIPPLE; GREASE,TIE ROD END |
2 |
1111- |
|
A |
|
| 61 |
I8-98236 800-0 |
|
ROD END; TIE ROD |
1 |
1307- |
|
A |
|
| 68 |
I8-98053 922-0 |
|
BOLT; TIE ROD END |
4 |
1111- |
|
A |
M12X65 |
| 17 |
I1-09009 190-0 |
|
BOLT; STOPPER KNUCKLE |
2 |
1111- |
|
A |
M18X43 |
| 30 |
I1-43171 186-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=4.900 -4.925 |
| 2 |
I1-43131 079-1 |
|
KNUCKLE; FRT AXLE |
1 |
1111- |
|
A |
|
| 59 |
I1-09449 084-0 |
|
NUT; TIE ROD ARM |
4 |
1111- |
|
A |
M22 |
| 66 |
I1-09442 032-0 |
|
NUT; TIE ROD END |
2 |
1111- |
|
A |
M2 4 |
| 2 |
I1-43132 079-1 |
|
KNUCKLE; FRT AXLE |
1 |
1111- |
|
A |
|
| 30 |
I1-43171 199-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.225 -5.250 |
| 30 |
I1-43171 187-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=4.925 -4.950 |
| 58 |
I1-43134 042-3 |
|
ARM; TIE ROD |
1 |
1111- |
|
A |
|
| 58 |
I1-43135 042-3 |
|
ARM; TIE ROD |
1 |
1111- |
|
A |
|
| 30 |
I1-43171 190-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.000 -5.025 |
| 30 |
I1-43171 192-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.050 -5.075 |
| 36 |
I1-43133 063-3 |
|
ARM; KNUCKLE |
1 |
1111- |
|
A |
|
| 61 |
I8-98236 801-0 |
|
ROD END; TIE ROD |
1 |
1111- |
|
A |
|
| 48 |
I0-28051 216-0 |
|
BOLT; COVER |
8 |
1111- |
|
A |
M12X16 FLANGE |
| 275 |
I8-98229 116-0 |
|
BOOT; ROD END,TIE |
2 |
1307- |
|
A |
|
| 6 |
I9-09926 024-0 |
|
SEAL; KING PIN |
4 |
1111- |
|
A |
|
| 30 |
I1-43171 196-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.150 -5.175 |
| 18 |
I0-91110 518-0 |
|
NUT; STOPPER BOLT,KNUCKLE |
2 |
1111- |
|
A |
M18 |
| 30 |
I1-43171 197-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.175 -5.200 |
| 37 |
I8-98052 380-1 |
|
BOLT; KNUCKLE ARM |
1 |
1111- |
|
A |
(A) M22X179 |
| 37 |
I8-98052 381-1 |
|
BOLT; KNUCKLE ARM |
1 |
1111- |
|
A |
(B) M22X167 |
| 80 |
I0-81125 035-0 |
|
PIN; SPLIT,ROD END |
2 |
1111- |
|
A |
OD=4.6 L=35 |
| 33 |
I0-91110 510-0 |
|
NUT; KEY BOLT |
2 |
1111- |
|
A |
M10 |
| 22 |
I9-43161 043-3 |
|
PIN; KING,FRT AXLE |
2 |
1111- |
|
A |
|
| 8 |
I9-00096 242-0 |
|
BEARING; NEEDLE,KING PIN |
4 |
1111- |
|
A |
(A) NTN |
| 5 |
I1-09740 072-0 |
|
PIN; KNUCKLE TO DRUM COVER |
2 |
1111- |
|
A |
|
| 30 |
I1-43171 191-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.025 -5.050 |
| 30 |
I1-43171 189-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=4.9 75 -5.000 |
| 61 |
I8-98236 801-0 |
|
ROD END; TIE ROD |
1 |
1307- |
|
A |
|
| 30 |
I1-43171 195-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.125 -5.150 |
| 11 |
I9-09950 204-0 |
|
RING; SNAP,KNUCKLE PLUG |
2 |
1111- |
|
A |
|
| 30 |
I1-43171 194-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.100 -5.125 |
| 74 |
I7-05012 010-A |
|
NUT; TIE ROD END |
4 |
1111- |
|
A |
M12 |
| 3 |
I1-87831 302-3 |
|
KING PIN SET |
2 |
1111- |
|
A |
|
| 21 |
I0-90301 510-0 |
|
NIPPLE; GREASE,KING PIN |
4 |
1111- |
|
A |
PT1/8 ELBOW 67.5fi |
| 30 |
I1-43171 185-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=4.8 75 -4.900 |
| 30 |
I1-43171 198-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.200 -5.225 |
| 60 |
I8-98052 379-1 |
|
BOLT; TIE ROD ARM |
4 |
1111- |
|
A |
M22X193 |
| 74 |
I0-91110 512-0 |
|
NUT; TIE ROD END |
4 |
1111- |
|
A |
M12 |
| 32 |
I1-43116 002-1 |
|
BOLT; KEY,KING PIN |
2 |
1111- |
|
A |
|
| 30 |
I1-43171 188-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=4.950 -4.975 |
| 275 |
I1-43159 131-0 |
|
BOOT; ROD END,TIE |
2 |
1111- |
|
A |
|
| 305 |
I8-98052 291-0 |
|
COVER; KNUCKLE |
2 |
1111- |
|
A |
|
| 40 |
I1-09449 084-0 |
|
NUT; KNUCKLE ARM |
2 |
1111- |
|
A |
M22 |
| 1 |
I1-43111 113-6 |
|
AXLE; FRT |
1 |
1111- |
|
A |
|
| 61 |
I8-98236 800-0 |
|
ROD END; TIE ROD |
1 |
1111- |
|
A |
|
| 30 |
I1-43171 193-0 |
|
WASHER; THRUST,KING PIN |
AR |
1111- |
|
A |
T=5.0 75 -5.100 |
| 34 |
I0-91510 510-0 |
|
WASHER; LK,KEY BOLT |
2 |
1111- |
|
A |
ID=10.2 |
| 81 |
I8-98193 965-0 |
|
ROD; TIE |
1 |
1111- |
|
A |
|
| 44 |
I1-43175 014-1 |
|
COVER; KING PIN |
2 |
1111- |
|
A |
|
| 45 |
I1-42319 044-0 |
|
GASKET; KING PIN COVER |
2 |
1111- |
|
A |
|
| 304 |
I9-09164 512-0 |
|
WASHER; PL |
4 |
1111- |
|
A |
ID=12.5 |
| 25 |
I1-09829 043-2 |
|
BEARING; THRUST,KING PIN |
2 |
1111- |
|
A |
|
