| 40 |
I1-41229 265-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.59 |
| 63 |
I1-09810 015-0 |
|
BEARING; PINION PILOT |
1 |
1111- |
|
AB |
NSK |
| 25 |
I1-41552 012-0 |
|
WASHER; THRUST,PINION |
4 |
1111- |
|
AB |
|
| 21 |
I1-41561 159-1 |
|
GEAR; SIDE,DIFF |
2 |
1111- |
|
AB |
Z=16 |
| 49 |
I9-41154 013-0 |
|
SHIM; FINAL PINION CAGE |
AR |
1111- |
|
AB |
T=1.00 |
| 89 |
I0-20850 816-0 |
|
BOLT; LK PLATE |
4 |
1111- |
|
AB |
M8X16 |
| 48 |
I0-91510 514-0 |
|
WASHER; LK,FINAL PINION |
8 |
1111- |
|
AB |
ID=14.2 |
| 42 |
I1-41229 268-0 |
|
COLLAR; DIST,COLLAPSIBLE |
AR |
1111- |
|
AB |
T=7.60 |
| 20 |
I1-41562 147-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.15 |
| 64 |
I0-91117 508-0 |
|
NUT; RET |
2 |
1111- |
|
AB |
M8 SLOTTED |
| 20 |
I1-41562 142-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=2.90 |
| 60 |
I1-41210 275-3 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1111- |
|
A |
41/6 |
| 60 |
I1-41210 276-3 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1111- |
|
B |
39/6 |
| 20 |
I1-41562 145-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.05 |
| 40 |
I1-41229 263-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.57 |
| 70 |
I1-09812 151-0 |
|
BEARING; DIFF CAGE |
2 |
1111- |
|
AB |
NSK |
| 63 |
I1-09810 229-2 |
|
BEARING; PINION PILOT |
1 |
1111- |
|
AB |
KOYO |
| 40 |
I1-41229 261-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.55 |
| 69 |
I1-41121 006-0 |
|
NUT; ADJ,DIFF CAGE |
1 |
1111- |
|
AB |
M143 H=2 9 |
| 37 |
I1-09449 067-0 |
|
NUT; DRIVING PINION |
1 |
1111- |
|
AB |
M3 6 FLANGE |
| 40 |
I1-41229 264-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.58 |
| 55 |
I1-41110 052-0 |
|
CARRIER; DIFF |
1 |
1111- |
|
AB |
|
| 40 |
I1-41229 258-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.52 |
| 50 |
I1-09812 042-1 |
|
BEARING; FINAL PINION |
1 |
1111- |
|
AB |
|
| 69 |
I1-41121 005-0 |
|
NUT; ADJ,DIFF CAGE |
1 |
1111- |
|
AB |
M143 H=2 4 |
| 20 |
I1-41562 149-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.25 |
| 56 |
I1-09050 002-1 |
|
BOLT; BRG CAP |
4 |
1111- |
|
AB |
M18X107 |
| 50 |
I1-09812 042-A |
|
BEARING; FINAL PINION |
1 |
1111- |
|
AB |
(IADG) |
| 45 |
I0-16806 450-0 |
|
BOLT; FINAL PINION CAGE |
8 |
1111- |
|
AB |
M14X50 |
| 49 |
I1-41154 064-0 |
|
SHIM; FINAL PINION CAGE |
AR |
1111- |
|
AB |
T=0.40 |
| 88 |
I1-41124 002-0 |
|
PLATE; LK,ADJ NUT |
2 |
1111- |
|
AB |
(B) T=2.3 |
| 84 |
I1-09020 167-0 |
|
BOLT; FINAL DRIVE GEAR |
16 |
1111- |
|
AB |
M16X3 7.5 FLANGE |
| 88 |
I9-41124 005-0 |
|
PLATE; LK,ADJ NUT |
2 |
1111- |
|
AB |
(A) T=1.0 |
| 40 |
I1-41229 259-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.53 |
| 40 |
I1-41229 262-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.56 |
| 42 |
I1-41229 271-0 |
|
COLLAR; DIST,COLLAPSIBLE |
AR |
1111- |
|
AB |
T=8.20 |
| 21 |
I1-41561 159-1 |
|
GEAR; SIDE,DIFF FTR90 |
2 |
1111- |
|
A |
Z=16 |
| 1 |
I1-41001 130-0 |
|
DRIVE ASM; FINAL,RR |
1 |
1111- |
|
B |
39/6 |
| 40 |
I1-41229 266-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.60 |
| 20 |
I1-41562 148-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.20 |
| 65 |
I0-81122 012-0 |
|
PIN; SPLIT,RET |
2 |
1111- |
|
AB |
|
| 85 |
I1-09400 077-1 |
|
NUT; DIFF CAGE SETTING |
12 |
1111- |
|
AB |
M14 |
| 62 |
I1-09042 035-0 |
|
BOLT; RET |
2 |
1111- |
|
AB |
M8X36 W/PIN HOLE |
| 20 |
I1-41562 143-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=2.95 |
| 70 |
I1-09812 151-0 |
|
BEARING; DIFF CAGE |
2 |
1111- |
|
AB |
NACHI |
| 49 |
I1-41154 063-0 |
|
SHIM; FINAL PINION CAGE |
AR |
1111- |
|
AB |
T=0.30 |
| 42 |
I1-41229 267-0 |
|
COLLAR; DIST,COLLAPSIBLE |
AR |
1111- |
|
AB |
T=7.40 |
| 39 |
I1-09812 218-0 |
|
BEARING; FINAL PINION |
1 |
1111- |
|
AB |
KOYO |
| 20 |
I1-41562 139-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=2.80 |
| 61 |
I1-41227 015-0 |
|
RETAINER; PILOT BRG,PINION |
2 |
1111- |
|
AB |
T=2 . 3 |
| 40 |
I1-41229 257-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.51 |
| 66 |
I9-09950 179-0 |
|
RING; SNAP,PILOT BRG |
1 |
1111- |
|
AB |
OD=42 |
| 24 |
I1-41551 051-0 |
|
GEAR; PINION,DIFF |
4 |
1111- |
|
AB |
Z=10 |
| 126 |
I1-37245 388-0 |
|
COUPLING; DRIVING PINION |
1 |
1111- |
|
AB |
|
| 42 |
I1-41229 270-0 |
|
COLLAR; DIST,COLLAPSIBLE |
AR |
1111- |
|
AB |
T=8.00 |
| 20 |
I1-41562 146-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.10 |
| 63 |
I1-09810 015-0 |
|
BEARING; PINION PILOT |
1 |
1111- |
|
AB |
NSK |
| 4 |
I9-09921 116-0 |
|
GASKET; FLANGE,FINAL PINION |
1 |
1111- |
|
AB |
ID=42 |
| 1 |
I1-41001 131-0 |
|
DRIVE ASM; FINAL,RR |
1 |
1111- |
|
A |
41/6 |
| 40 |
I1-41229 260-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.54 |
| 42 |
I1-41229 269-0 |
|
COLLAR; DIST,COLLAPSIBLE |
AR |
1111- |
|
AB |
T=7.80 |
| 100 |
I1-09625 017-0 |
|
SEAL; OIL,FINAL PINION |
1 |
1111- |
|
AB |
NOK |
| 134 |
I0-91510 518-0 |
|
WASHER; LK,BRG CAP |
4 |
1111- |
|
AB |
ID=18.2 |
| 20 |
I1-41562 151-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.35 |
| 40 |
I1-41229 256-0 |
|
SHIM; FINAL PINION |
AR |
1111- |
|
AB |
T=3.50 |
| 20 |
I1-41562 150-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.30 |
| 20 |
I1-41562 141-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=2.85 |
| 49 |
I9-41154 014-0 |
|
SHIM; FINAL PINION CAGE |
AR |
1111- |
|
AB |
T=0.50 |
| 71 |
I1-41510 127-0 |
|
CAGE ASM; DIFF,FINAL DRIVE |
1 |
1111- |
|
AB |
|
| 22 |
I1-41521 061-0 |
|
PIN; CROSS,DIFF PINION |
1 |
1111- |
|
AB |
|
| 61 |
I1-41227 015-0 |
|
RETAINER; PILOT BRG,PINION |
2 |
1111- |
|
AB |
T=2 . 3 |
| 70 |
I1-09812 151-0 |
|
BEARING; DIFF CAGE |
2 |
1111- |
|
AB |
NSK |
| 20 |
I1-41562 144-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.00 |
| 20 |
I1-41562 153-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.45 |
| 43 |
I1-41151 028-1 |
|
CAGE; FINAL PINION |
1 |
1111- |
|
AB |
|
| 20 |
I1-41562 140-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
|
| 20 |
I1-41562 152-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
1111- |
|
AB |
T=3.40 |
| 17 |
I1-09044 007-0 |
|
BOLT; DIFF CAGE SETTING |
12 |
1111- |
|
AB |
M14X95 FLANGE |
