| 3 |
I8-97077 638-0 |
|
BOLT; CYL HD TO BLOCK |
26 |
1312-1407 |
|
AB |
|
| 58 |
I8-98004 187-0 |
|
GASKET; SLEEVE,NOZZLE HOLDER |
6 |
1108- |
|
A |
(B) ID=26.2 |
| 250 |
I8-94393 196-0 |
|
CAP |
2 |
1310- |
|
AB |
|
| 103 |
I8-94152 613-A |
|
PLUG; HD |
1 |
1108- |
|
A |
(B) M14X14 IDN |
| 7 |
I8-97096 826-A |
|
CUP; SEALING,CYL HEAD |
1 |
1108- |
|
A |
OD=51 |
| 4 |
I8-97376 719-2 |
|
GUIDE; VLV |
24 |
1108- |
|
A |
|
| 250 |
I8-94393 196-0 |
|
CAP |
2 |
1108- |
|
A |
|
| 201 |
I1-09639 034-0 |
|
GASKET; SLEEVE,INJ PUMP |
6 |
1108- |
|
A |
|
| 41 |
I0-28751 225-0 |
|
BOLT; ENG HANGER |
2 |
1108- |
|
A |
(C) M12X25 FLANGE |
| 1 |
I8-98243 824-0 |
|
HEAD ASM; CYL |
1 |
1108- |
|
A |
|
| 59 |
I8-97381 603-1 |
|
GUIDE; BRIDGE |
12 |
1108- |
|
A |
|
| 5 |
I8-98028 875-0 |
|
SEAT; VLV INSERT |
12 |
1108- |
|
A |
(B) ID=31 OD=38 |
| 270 |
I8-94395 626-2 |
|
BRACKET; CAM,FRONT |
1 |
1310- |
|
AB |
|
| 104 |
I1-09630 085-0 |
|
GASKET; PLUG |
1 |
1108- |
|
A |
ID=14.2 OD=19.2 ALSO INCLUDED IN GASKET SET(ENGINE). |
| 71 |
I0-28050 835-0 |
|
BOLT; CAM BRKT |
2 |
1108- |
|
A |
M8X35 FLANGE |
| 98 |
I8-94322 512-2 |
|
STUD; CAM BRKT |
2 |
1108- |
|
A |
(A) M8X54 L=79 |
| 138 |
I8-97606 929-0 |
|
GEAR; IDLE |
1 |
1108- |
|
A |
Z=41 |
| 120 |
I8-94399 555-0 |
|
BOLT; CYL HD TO HSG |
1 |
1108- |
|
A |
(B) M10X43 |
| 120 |
I8-94399 554-0 |
|
BOLT; CYL HD TO HSG |
1 |
1108- |
|
A |
(A) M10X73 |
| 103 |
I8-98003 416-0 |
|
PLUG; HD |
1 |
1108- |
|
A |
(A) M8X10 |
| 103 |
I8-94152 613-A |
|
PLUG; HD |
1 |
1108- |
|
A |
(B) M14X14 IDN |
| 8 |
I5-11129 006-0 |
|
CUP; SEALING,WATER JACKET |
7 |
1108- |
|
A |
(C) OD=16 |
| 57 |
I8-97606 661-0 |
|
SLEEVE; NOZZLE HOLDER |
6 |
1108- |
|
A |
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) |
| 272 |
I8-94395 627-1 |
|
BRACKET; CAM,RR |
1 |
1310- |
|
AB |
|
| 139 |
I8-97186 398-1 |
|
SHAFT; IDLE GEAR |
1 |
1108- |
|
A |
|
| 8 |
I1-09600 012-2 |
|
CUP; SEALING,WATER JACKET |
6 |
1310- |
|
AB |
(A) OD=32 |
| 12 |
I8-94392 081-1 |
|
HANGER; ENG,RR |
1 |
1108- |
|
A |
|
| 106 |
I8-94392 236-0 |
|
PLUG; GLOW PLUG HOLE |
6 |
1108- |
|
A |
|
| 2 |
I8-97601 819-5 |
|
GASKET; CYL HD |
1 |
1108- |
|
A |
|
| 58 |
I8-97604 916-0 |
|
GASKET; SLEEVE,NOZZLE HOLDER |
6 |
1108- |
|
A |
(A) ID=26.4 |
| 14 |
I8-94397 286-0 |
|
STUD; EXH MANIF |
12 |
1108- |
|
A |
M10X60 L=75 |
| 41 |
I0-28151 020-0 |
|
BOLT; ENG HANGER |
2 |
1108- |
|
A |
(A) M10X2 0 FLANGE |
| 8 |
I1-09600 016-0 |
|
CUP; SEALING,WATER JACKET |
6 |
1108- |
|
A |
(B) OD=25 |
| 8 |
I9-11129 128-0 |
|
CUP; SEALING,WATER JACKET |
11 |
1108- |
|
A |
(D) OD=20 |
| 272 |
I8-94395 627-1 |
|
BRACKET; CAM,RR |
1 |
1108- |
|
A |
|
| 1 |
I8-98243 824-0 |
|
HEAD ASM. CYL |
1 |
1306- |
|
A |
|
| 141 |
I8-98163 813-0 |
|
PLUG; RUBBER,CYL HD |
2 |
1108- |
|
A |
|
| 98 |
I8-94322 513-2 |
|
STUD; CAM BRKT |
6 |
1108- |
|
A |
(B) M8X41 L=66 |
| 41 |
I0-28751 025-0 |
|
BOLT; ENG HANGER |
2 |
1108- |
|
A |
(B) M10X25 FLANGE |
| 23 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
8 |
1108- |
|
A |
M8 FLANGE |
| 1 |
I8-98243 823-0 |
|
HEAD ASM. CYL |
1 |
1310- |
|
B |
|
| 3 |
I8-98260 005-0 |
|
BOLT; CYL HD TO BLOCK |
26 |
1408- |
|
AB |
|
| 270 |
I8-94395 626-2 |
|
BRACKET; CAM,FRONT |
1 |
1108- |
|
A |
|
| 5 |
I8-98028 874-0 |
|
SEAT; VLV INSERT |
12 |
1108- |
|
A |
(A) ID=32 OD=38 |
| 168 |
I8-94394 398-1 |
|
HANGER; ENG,FRT |
1 |
1108- |
|
A |
(B) |
| 168 |
I8-94394 071-2 |
|
HANGER; ENG,FRT |
1 |
1108- |
|
A |
(A) |
| 8 |
I1-09600 012-2 |
|
CUP; SEALING,WATER JACKET |
7 |
1108- |
|
A |
(A) OD=32 |
