| 33 |
I1-09556 015-0 |
|
WASHER; EXH MANIF |
2 |
1108- |
|
A |
T=2 . 2 |
| 12 |
I8-97601 632-0 |
|
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF |
1 |
1108- |
|
A |
|
| 155 |
I1-14149 184-0 |
|
RING; SEAL,EXH MANIF |
2 |
1108- |
|
A |
(A) |
| 16 |
I9-04731 025-0 |
|
STUD; EXH PIPE TO MANIF |
2 |
1108- |
|
A |
M10X25 L=40 |
| 118 |
I8-97603 366-0 |
|
BRACKET; HEAT PROTECTOR |
1 |
1108- |
|
A |
|
| 18 |
I0-91370 010-0 |
|
NUT; EXH MANIF |
10 |
1108- |
|
A |
(A) M10 LOCK NUT IDN |
| 2 |
I8-94393 672-4 |
|
GASKET; EXH MANIF TO HD |
6 |
1108- |
|
A |
ALSO INCLUDED IN GASKET SET(ENG. & |
| 155 |
I1-14149 151-0 |
|
RING; SEAL,EXH MANIF |
1 |
1108- |
|
A |
(B) |
| 21 |
I0-28050 816-0 |
|
BOLT; HEAT PROTECTOR |
1 |
1108- |
|
A |
M8X16 FLANGE |
| 5 |
I8-97602 056-0 |
|
MANIFOLD; EXH,FRT |
1 |
1108- |
|
A |
|
| 64 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
2 |
1403- |
|
AB |
6HK1-TCN ENG(82L) |
| 64 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
2 |
1108- |
|
A |
M10 FLANGE |
| 34 |
I8-97250 073-1 |
|
COLLAR; DIST,EXH MANIF |
12 |
1108- |
|
A |
L=2 8 |
| 18 |
I8-94394 991-1 |
|
NUT; EXH MANIF |
2 |
1108- |
|
A |
(B) M10 L=51 |
| 64 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
2 |
1108- |
|
A |
M10 FLANGE |
| 55 |
I0-28050 816-0 |
|
BOLT; BRKT |
2 |
1108- |
|
A |
M8X16 FLANGE |
| 6 |
I8-97600 970-0 |
|
MANIFOLD; EXH,RR |
1 |
1108- |
|
A |
|
| 18 |
I8-98205 394-0 |
|
NUT; EXH MANIF |
2 |
1201- |
|
A |
(B) |
| 64 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
2 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
