| 242 |
I8-98019 304-1 |
|
BRACKET; AIR DUCT |
1 |
1108- |
|
A |
(A) |
| 210 |
I0-28651 025-0 |
|
BOLT; ACL BRKT |
4 |
1108- |
|
A |
M10X2 5 FLANGE IDN |
| 49 |
I0-91110 508-0 |
C |
NUT; AIR DUCT |
1 |
1108- |
|
A |
(B) M8 FLANGE |
| 48 |
I1-09030 044-1 |
|
BOLT; AIR DUCT |
2 |
1108- |
|
A |
M10X26 |
| 49 |
I1-09984 126-0 |
|
NUT; AIR DUCT |
1 |
1108- |
|
A |
(A) M8 FLANGE |
| 320 |
I8-98073 259-A |
|
HOSE; CONN,ACL |
1 |
1403- |
|
B |
6HK1-TCS ENG(80L) |
| 49 |
I0-91110 508-0 |
|
NUT; AIR DUCT |
1 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
| 357 |
I8-94342 958-0 |
|
CLIP; RUBBER HOSE |
1 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 480 |
I8-98086 417-0 |
|
ADAPTER |
1 |
1108- |
|
A |
|
| 242 |
I8-98019 301-3 |
|
BRACKET; AIR DUCT |
1 |
1108- |
|
A |
(B) |
| 225 |
I1-09623 057-0 |
|
GASKET; AIR PIPE |
1 |
1108- |
|
A |
ID=24. 4 |
| 58 |
I1-14119 267-0 |
|
SUPPORT; AIR INL DUCT |
4 |
1108- |
|
A |
(A) OD=40 T=18.5 |
| 49 |
I0-91110 508-0 |
|
NUT; AIR DUCT |
1 |
1108- |
|
A |
(B) M8 FLANGE |
| 159 |
I0-28050 616-0 |
|
BOLT; AIR PIPE |
2 |
1108- |
|
A |
M6X16 FLANGE IDN |
| 245 |
I1-79998 228-0 |
|
PIECE; DIST,AIR DUCT |
2 |
1108- |
|
A |
|
| 209 |
I8-98021 995-1 |
|
BRACKET; ACL |
1 |
1108- |
|
A |
|
| 558 |
I5-09707 030-1 |
|
CLIP; AIR FLOW SENSOR |
2 |
1108- |
|
A |
L=250 IDN |
| 5 |
I8-98133 359-0 |
|
CLIP; AIR DUCT |
1 |
1108- |
|
A |
(A) ID=110-130 |
| 450 |
I1-09707 157-0 |
C |
CLAMP; HOSE |
1 |
1108- |
|
A |
|
| 5 |
I8-98133 365-0 |
|
CLIP; AIR DUCT |
1 |
1108- |
|
A |
(B) ID=90-110 |
| 56 |
I1-09985 177-0 |
|
WASHER; LK,AIR INT DUCT |
2 |
1108- |
|
A |
(A) ID=8.2 |
| 379 |
I8-97619 194-A |
|
HOSE; RUBBER |
1 |
1108- |
|
A |
|
| 316 |
I8-98152 269-0 |
|
RUBBER; CUSHION,DUCT |
1 |
1108- |
|
A |
|
| 49 |
I8-94327 073-0 |
|
NUT; AIR DUCT |
2 |
1108- |
|
A |
(C) M8 FLANGE IDN |
| 242 |
I8-98019 301-3 |
|
BRACKET; AIR DUCT |
1 |
1403- |
|
B |
GVR-TH |
| 560 |
I8-98061 675-0 |
|
FILTER; VERTICAL DUCT |
2 |
1108- |
|
A |
|
| 56 |
I0-91610 708-0 |
|
WASHER; LK,AIR INT DUCT |
2 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
| 49 |
I0-91110 508-0 |
|
NUT; AIR DUCT |
1 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 488 |
I7-57240 399-A |
|
HOSE; RUBBER,PIPE |
1 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
| 564 |
I8-98071 416-0 |
|
GASKET; ADAPTER |
1 |
1108- |
|
A |
|
| 368 |
I8-98065 377-0 |
|
SENSOR; TEMP |
1 |
1108- |
|
A |
|
| 26 |
I8-98010 361-2 |
|
DUCT; AIR INT |
1 |
1108- |
|
A |
|
| 543 |
I0-36220 514-0 |
|
SCREW; SENSOR |
1 |
1108- |
|
A |
(B) M5X14 W/LK WASHER |
| 61 |
I8-98074 570-0 |
|
BOLT; BRKT,AIR DUCT |
2 |
1108- |
|
A |
M8X25 FLANGE |
| 56 |
I0-91610 708-0 |
|
WASHER; LK,AIR INT DUCT |
2 |
1108- |
|
A |
(B) ID=8.4 OD=22 |
| 49 |
I8-94327 073-0 |
C |
NUT; AIR DUCT |
2 |
1108- |
|
A |
(C) M8 FLANGE IDN |
| 548 |
I8-98181 974-A |
A |
HOSE; RUBBER,TURBO TO INL PIPE |
1 |
1108- |
|
A |
|
| 543 |
I0-36230 412-0 |
|
SCREW; SENSOR |
2 |
1108- |
|
A |
(A) M4X12 W/LK&PL WASHER |
| 320 |
I8-98073 257-A |
A |
HOSE; CONN,ACL |
1 |
1108- |
|
A |
|
| 56 |
I0-91610 708-0 |
|
WASHER; LK,AIR INT DUCT |
2 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 242 |
I8-98019 302-1 |
|
BRACKET; AIR DUCT |
1 |
1108- |
|
A |
(C) |
| 558 |
I1-09707 107-1 |
|
CLIP; AIR FLOW SENSOR |
1 |
1108- |
|
A |
L=600 |
| 488 |
I7-57240 399-A |
|
HOSE; RUBBER,PIPE |
1 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 296 |
I0-91180 108-0 |
|
NUT; ACL |
4 |
1108- |
|
A |
M8 FLANGE |
| 379 |
I8-97639 463-A |
|
HOSE; RUBBER |
1 |
1403- |
|
B |
6HK1-TCS ENG(80L) |
| 56 |
I0-91610 708-0 |
C |
WASHER; LK,AIR INT DUCT |
2 |
1108- |
|
A |
(B) ID=8.4 OD=22 |
| 252 |
I8-98012 861-1 |
|
DUCT; AIR INT |
1 |
1108- |
|
A |
|
| 424 |
I8-98081 834-0 |
|
PIPE; AIR,INL |
1 |
1108- |
|
A |
|
| 379 |
I8-97619 194-A |
C |
HOSE; RUBBER |
1 |
1108- |
|
A |
|
| 58 |
I8-98125 944-A |
|
SUPPORT; AIR INL DUCT |
1 |
1108- |
|
A |
(B) |
| 548 |
I8-98181 974-A |
|
HOSE; RUBBER,TURBO TO INL PIPE |
1 |
1108- |
|
A |
|
| 353 |
I8-98133 349-0 |
|
CLIP; RUBBER HOSE |
8 |
1108- |
|
A |
ID=55-75 |
| 450 |
I1-09707 157-0 |
|
CLAMP; HOSE |
1 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 450 |
I1-09707 157-0 |
|
CLAMP; HOSE |
1 |
1108- |
|
A |
|
| 488 |
I8-98012 936-1 |
|
HOSE; RUBBER,PIPE |
1 |
1108- |
|
A |
|
| 58 |
I8-98125 944-A |
|
SUPPORT; AIR INL DUCT |
1 |
1403- |
|
B |
GVR-TH |
| 357 |
I8-94342 958-0 |
|
CLIP; RUBBER HOSE |
1 |
1108- |
|
A |
(A) ID=26 |
| 357 |
I8-97354 979-0 |
|
CLIP; RUBBER HOSE |
1 |
1108- |
|
A |
(B) ID=29.5 |
| 357 |
I8-94342 958-0 |
C |
CLIP; RUBBER HOSE |
1 |
1108- |
|
A |
(A) ID=26 |
| 320 |
I8-98073 257-A |
|
HOSE; CONN,ACL |
1 |
1108- |
|
A |
|
| 49 |
I8-94327 073-0 |
|
NUT; AIR DUCT |
2 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
| 450 |
I1-09707 157-0 |
|
CLAMP; HOSE |
1 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
| 49 |
I8-94327 073-0 |
|
NUT; AIR DUCT |
2 |
1403- |
|
AB |
6HK1-TCN ENG(82L) & 6HK1-TCS ENG(80L) |
| 71 |
I8-98133 367-0 |
|
CLIP; AIR DUCT |
1 |
1108- |
|
A |
ID=120-140 |
| 357 |
I8-94342 958-0 |
|
CLIP; RUBBER HOSE |
1 |
1312-1402 |
|
A |
6HK1-TCN ENG(82L) |
