| 080 |
I0-28650 820-0 |
|
BOLT; BRKT |
5 |
1108- |
|
ALL |
(A) M8X20 FLANGE |
| 072 |
I8-98120 254-0 |
|
BRACKET; AIR MASTER |
2 |
1108- |
|
ALL |
|
| 028 |
I1-53318 338-6 |
|
BRACKET; AIR TANK |
2 |
1403- |
|
GVR |
|
| 042 |
I1-14319 034-0 |
|
WASHER; PL |
4 |
1108- |
|
ALL |
ID=8.4 OD=18 |
| 138 |
I1-47530 185-1 |
|
TANK ASM; OIL,AIR MASTER |
1 |
1108- |
|
ALL |
|
| 092 |
I8-98177 521-1 |
|
BRACKET; CHECK VLV |
1 |
1403- |
|
GVR |
|
| 139 |
I1-47537 081-2 |
|
BRACKET; OIL TANK |
1 |
1108- |
|
ALL |
|
| 126 |
I1-09656 669-0 |
|
CONNECTOR; ELBOW |
1 |
1403- |
|
GVR |
(H) M16 & PT1/4X2 3WAY |
| 271 |
I7-05110 010-A |
|
NUT; BRKT,HOSE |
2 |
1108- |
|
ALL |
M10 FLANGE |
| 046 |
I0-91110 508-0 |
|
NUT; U-BOLT |
8 |
1403- |
|
GVR |
(A) M8 |
| 238 |
I1-47529 022-0 |
|
PLATE; BAFFLE |
1 |
1108- |
|
ALL |
|
| 086 |
I1-47529 019-0 |
|
SEAL; DUST |
1 |
1108- |
|
ALL |
|
| 209 |
I0-91180 108-0 |
|
NUT; CLIP |
1 |
1108- |
|
ALL |
M8 FLANGE |
| 125 |
I1-09360 320-0 |
|
HOSE; OIL TANK TO AIR MASTER |
1 |
1108- |
|
ALL |
(A) L=270 SERVICED BY L=1800 |
| 172 |
I0-91180 108-0 |
|
NUT; STAY,AIR TANK,MAIN |
2 |
1108- |
|
ALL |
(A) M8 FLANGE |
| 111 |
I1-09660 957-0 |
|
CONNECTOR; CHECK VLV |
1 |
1403- |
|
GVR |
(A) DIN8 & R3/8 ELBOW |
| 037 |
I0-28651 240-0 |
|
BOLT; AIR TANK |
6 |
1108- |
|
ALL |
(A) M12X40 FLANGE |
| 009 |
I8-97609 249-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
1108- |
|
ALL |
STAMP 5.5 |
| 126 |
I1-09660 963-0 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(G) DIN8 R1/4 STRAIGHT |
| 030 |
I8-98250 267-0 |
|
BRACKET; AIR TANK,SUB |
1 |
1403- |
|
GVR |
(B) |
| 222 |
I1-48410 531-1 |
|
VALVE; DOUBLE CHECK |
1 |
1403- |
|
GVR |
CHECK VALVE |
| 366 |
I1-09660 965-0 |
|
CONNECTOR; NYLON TUBE |
1 |
1403- |
|
GVR |
(B) DIN12 & R3/8 STRAIGHT |
| 007 |
I1-09630 145-0 |
|
GASKET; DRAIN COCK |
3 |
1108- |
|
FVR |
ID=14 |
| 237 |
I1-47525 030-0 |
|
CAP; OIL TANK |
1 |
1108- |
|
ALL |
|
| 046 |
I7-05110 010-A |
|
NUT; U-BOLT |
4 |
1403- |
|
GVR |
(B) M10 FLANGE |
| 030 |
I1-48317 430-0 |
|
BRACKET; AIR TANK,SUB |
2 |
1403- |
|
GVR |
(A) |
| 125 |
I8-98098 558-A |
|
HOSE; OIL TANK TO AIR MASTER |
1 |
1108- |
|
FVR |
(B) |
| 140 |
I0-28651 025-0 |
|
BOLT; OIL TANK TO BRKT |
2 |
1108- |
|
ALL |
M10X25 FLANGE |
| 178 |
I8-98150 355-0 |
|
CLIP; HOSE |
1 |
1108- |
|
ALL |
(A) ID=21 |
| 177 |
I0-03566 300-0 |
|
HOSE; RUBBER,DRAIN |
1 |
1108- |
|
ALL |
L=60 SERVICED BY L=3000 |
| 094 |
I7-05110 010-A |
|
NUT; BRKT FIX |
4 |
1108- |
|
ALL |
M10 FLANGE |
| 213 |
I1-48317 367-A |
|
BOLT; U AIR TANK |
2 |
1108- |
|
ALL |
(B) L=195 |
| 240 |
I1-47529 018-0 |
|
HOLDER; FILTER |
1 |
1108- |
|
ALL |
|
| 104 |
I0-91180 108-0 |
|
NUT; BRKT |
5 |
1108- |
|
ALL |
M8 FLANGE |
| 125 |
I8-98197 596-0 |
|
HOSE; OIL TANK TO AIR MASTER |
1 |
1403- |
|
GVR |
(B) |
| 081 |
I1-47800 663-1 |
|
AIR MASTER ASM; BRK |
2 |
1108- |
|
ALL |
SEE FIG-NO 3-33 FOR COMPONENT. |
| 003 |
I1-48410 134-3 |
|
VALVE; CHECK,AIR TANK |
1 |
1108- |
|
FVR |
(A) M22 & PT3/4 ELBOW |
| 080 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1403- |
|
GVR |
(C) M10X25 FLANGE |
| 005 |
I1-09660 965-0 |
|
UNION; AIR TANK |
1 |
1108- |
|
ALL |
(B) DIN12 & R3/8 STRAIGHT |
| 002 |
I1-48370 464-0 |
|
TANK; AIR |
1 |
1403- |
|
GVR |
|
| 152 |
I0-28650 820-0 |
|
BOLT; OIL TANK TO BAND |
2 |
1108- |
|
ALL |
M8X20 FLANGE |
| 241 |
I0-28051 020-0 |
|
BOLT; SET,CONT VLV |
2 |
1403- |
|
GVR |
M10X20 FLANGE |
| 006 |
I1-48312 015-0 |
|
COCK; DRAIN,AIR TANK |
4 |
1403- |
|
GVR |
|
| 145 |
I1-09704 102-0 |
|
CLIP; OIL TANK TO AIR MASTER HOSE |
4 |
1108- |
|
ALL |
ID=14 |
| 178 |
I1-09709 280-1 |
|
CLIP; HOSE |
1 |
1108- |
|
ALL |
(B) ID=12 & 12 |
| 153 |
I0-91110 508-0 |
|
NUT; OIL TANK TO BAND |
2 |
1108- |
|
ALL |
M8 |
| 007 |
I1-09630 145-0 |
|
GASKET; DRAIN COCK |
4 |
1403- |
|
GVR |
ID=14 |
| 001 |
I1-48370 541-0 |
|
TANK ASM; AIR |
1 |
1108- |
|
ALL |
(B) |
| 083 |
I7-05110 010-A |
|
NUT; AIR MASTER |
10 |
1108- |
|
ALL |
M10 FLANGE |
| 172 |
I7-05110 010-A |
|
NUT; STAY,AIR TANK,MAIN |
4 |
1108- |
|
ALL |
(B) M10 FLANGE |
| 003 |
I1-48410 182-3 |
|
VALVE; CHECK,AIR TANK |
2 |
1108- |
|
ALL |
(B) M20 & PT3/4 STRAIGHT |
| 054 |
I0-91180 108-0 |
|
NUT; STAY |
2 |
1108- |
|
ALL |
M8 FLANGE |
| 013 |
I1-09660 878-0 |
|
ADAPTER; NYLON TUBE |
1 |
1403- |
|
GVR |
DIN12 & M12 STRAIGHT |
| 010 |
I9-99204 513-0 |
|
PLUG; AIR TANK |
4 |
1108- |
|
ALL |
PT1/4 |
| 026 |
I9-09204 517-0 |
|
PLUG; SUB AIR TANK |
1 |
1403- |
|
GVR |
PT3/8 |
| 043 |
I0-28650 820-0 |
|
BOLT; STAY,AIR TANK,MAIN |
2 |
1108- |
|
ALL |
(A) M8X20 FLANGE |
| 213 |
I1-48317 323-A |
|
BOLT; U AIR TANK |
2 |
1108- |
|
ALL |
(A) L=97.5 |
| 126 |
I1-09660 876-0 |
|
CONNECTOR; ELBOW |
1 |
1403- |
|
GVR |
(F) DIN12 & M16 STRAIGHT |
| 136 |
I1-47475 694-1 |
|
BRACKET; CLIP |
1 |
1108- |
|
ALL |
(A) L=112 |
| 136 |
I1-47476 712-0 |
|
BRACKET; CLIP |
1 |
1108- |
|
ALL |
(B) |
| 003 |
I1-48410 134-3 |
|
VALVE; CHECK,AIR TANK |
2 |
1403- |
|
GVR |
(A) M22 & PT3/4 ELBOW |
| 151 |
I1-47537 056-2 |
|
BAND; OIL TANK,AIR MASTER |
2 |
1108- |
|
ALL |
|
| 121 |
I0-28050 812-A |
|
BOLT; DOUBLE CHECK VLV |
2 |
1403- |
|
GVR |
M8X12 FLANGE |
| 239 |
I1-47529 017-0 |
|
FILTER; DUST |
1 |
1108- |
|
ALL |
|
| 060 |
I7-05110 010-A |
|
NUT; AIR TANK FIX |
4 |
1403- |
|
GVR |
M10 FLANGE |
| 005 |
I1-09660 959-0 |
|
UNION; AIR TANK |
1 |
1108- |
|
ALL |
(A) DIN12 & R3/8 ELBOW |
| 028 |
I8-97913 537-3 |
|
BRACKET; AIR TANK |
2 |
1108- |
|
FVR |
|
| 037 |
I0-28651 025-0 |
|
BOLT; AIR TANK |
4 |
1403- |
|
GVR |
(B) M10X25 FLANGE |
| 126 |
I1-09660 693-0 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(C) PT1/4 & PT1/4 2WAY |
| 126 |
I1-09660 956-0 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(E) DIN8 & R1/4 ELBOW |
| 111 |
I1-09660 959-0 |
|
CONNECTOR; CHECK VLV |
1 |
1403- |
|
GVR |
(B) DIN12 & R3/8 ELBOW |
| 111 |
I1-09661 026-0 |
|
CONNECTOR; CHECK VLV |
1 |
1403- |
|
GVR |
(C) DIN12X2 & PT3/8 DOUBLE ELBOW |
| 006 |
I1-48312 015-0 |
|
COCK; DRAIN,AIR TANK |
3 |
1108- |
|
FVR |
|
| 043 |
I0-28651 025-0 |
|
BOLT; STAY,AIR TANK,MAIN |
4 |
1108- |
|
ALL |
(B) M10X25 FLANGE |
| 001 |
I8-98269 245-0 |
|
TANK ASM; AIR |
1 |
1108- |
|
ALL |
(A) |
| 136 |
I1-47479 693-0 |
|
BRACKET; CLIP |
2 |
1108- |
|
ALL |
(D) |
| 064 |
I8-94301 490-0 |
|
STAY; AIR TANK,MAIN |
1 |
1108- |
|
ALL |
(B) |
| 039 |
I1-48317 308-0 |
|
U-BOLT; AIR TANK |
2 |
1403- |
|
GVR |
L=250 |
| 126 |
I1-09656 340-1 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(B) M20X2 & PT3/8 3WAY |
| 126 |
I1-09660 878-0 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(D) DIN12 & M12 STRAIGHT |
| 126 |
I1-09650 430-0 |
|
CONNECTOR; ELBOW |
1 |
1108- |
|
ALL |
(A) M12 & PT1/4 ELBOW |
| 064 |
I1-53318 293-1 |
|
STAY; AIR TANK,MAIN |
1 |
1108- |
|
ALL |
(A) |
| 208 |
I0-28650 820-0 |
|
BOLT; CLIP |
1 |
1108- |
|
ALL |
M8X20 FLANGE |
| 366 |
I1-09660 959-0 |
|
CONNECTOR; NYLON TUBE |
1 |
1403- |
|
GVR |
(A) DIN12 & R3/8 ELBOW |
| 080 |
I0-28651 030-0 |
|
BOLT; BRKT |
4 |
1108- |
|
ALL |
(B) M10X30 FLANGE |
| 136 |
I1-47477 629-2 |
|
BRACKET; CLIP |
1 |
1108- |
|
ALL |
(C) L=150 H=30 |
| 178 |
I9-09917 171-0 |
|
CLIP; HOSE |
1 |
1108- |
|
ALL |
(C) DIN15X2 |
| 119 |
I0-28650 820-0 |
|
BOLT; STAY |
2 |
1108- |
|
ALL |
M8X20 FLANGE |
| 067 |
I1-48317 349-0 |
|
STAY; SUB TANK |
1 |
1108- |
|
ALL |
|
| 058 |
I0-91110 508-0 |
|
NUT; BAND,AIR TANK |
16 |
1108- |
|
ALL |
M8 |
