| 22 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
1 |
1108- |
|
ABC |
|
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
ABC |
OD=45.5 T=1.95 BLUE |
| 172 |
I1-37515 127-0 |
|
BRACKET; CENTER BRG |
1 |
1108- |
|
C |
(B) |
| 46 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1108- |
|
ABC |
(A) |
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1108- |
|
ABC |
(A) |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1108- |
|
C |
M10 FLANGE |
| 45 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
1108- |
|
ABC |
ID=10.5 OD=22 |
| 25 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
1108- |
|
ABC |
(A) MT6 STRAIGHT IDN |
| 172 |
I8-98084 679-0 |
|
BRACKET; CENTER BRG |
1 |
1108- |
|
A |
(A) |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1312-1405 |
|
C |
M14 |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1312-1405 |
|
ABC |
M10 FLANGE |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
0 |
1108- |
|
ABC |
(B) |
| 71 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1108- |
|
ABC |
M16 FLANGE |
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1108- |
|
ABC |
OD=45.5 T=2.0 0 WHITE |
| 225 |
I1-37241 099-2 |
|
YOKE; SLEEVE,PROP SHAFT |
1 |
1108- |
|
ABC |
L=2 71 |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1108- |
|
ABC |
M10 FLANGE |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1108- |
|
C |
(B) |
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
ABC |
OD=45.5 T=2.05 YELLOW |
| 51 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
1 |
1108- |
|
ABC |
M3 0 |
| 21 |
I1-09625 161-0 |
|
SEAL; OIL,CENTER BRG |
2 |
1108- |
|
C |
ID=54 |
| 63 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
1108- |
|
ABC |
M10X3 5 FLANGE IDN |
| 63 |
I0-28651 035-0 |
|
BOLT; RET TO BRKT,PROP SHAFT,1ST |
4 |
1108- |
|
C |
M10X3 5 FLANGE IDN |
| 106 |
I0-90301 410-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
1108- |
|
ABC |
PT1/8 STRAIGHT |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1406- |
|
C |
P46 PROP SHAFT<C4Z> M14 |
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1108- |
|
ABC |
OD=45.5 T=1.95 BLUE |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1406- |
|
ABC |
P46 PROP SHAFT<C4Z> (B) M14 |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1312-1405 |
|
C |
M10 FLANGE |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1108- |
|
ABC |
(A) |
| 1 |
I8-98069 584-0 |
|
SHAFT; PROP |
1 |
1112- |
|
A |
(B) L=849 |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1108- |
|
C |
M14 |
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
1108- |
|
ABC |
(B) M14X37 |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1108- |
|
ABC |
M10X2 5 FLANGE IDN |
| 9 |
I1-37300 129-0 |
|
JOURNAL ASM; PROP SHAFT |
0 |
1108- |
|
ABC |
(A) |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
1 |
1108- |
|
C |
(B) |
| 20 |
I6-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1108- |
|
C |
(B) |
| 9 |
I1-37300 129-0 |
|
JOURNAL ASM; PROP SHAFT |
0 |
1108- |
|
ABC |
(A) |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1108- |
|
ABC |
(A) |
| 1 |
I8-98090 948-0 |
|
SHAFT; PROP |
1 |
1112- |
|
C |
(B) L=1219 |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
4 |
1108- |
|
C |
|
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1108- |
|
ABC |
(A) |
| 21 |
I1-09625 161-0 |
|
SEAL; OIL,CENTER BRG |
2 |
1108- |
|
ABC |
ID=54 |
| 20 |
I8-98020 881-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1108- |
|
C |
(B) |
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
8 |
1108- |
|
ABC |
OD=45.5 T=2.05 YELLOW |
| 9 |
I6-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
1 |
1204- |
|
A |
|
| 1 |
I8-98069 590-0 |
|
SHAFT; PROP |
1 |
1108- |
|
C |
(C) L=1234 |
| 74 |
I1-09000 121-0 |
|
BOLT; YOKE,TRANS |
4 |
1108- |
|
C |
(B) M14X37 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1108- |
|
ABC |
(A) IDN |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
8 |
1108- |
|
ABC |
|
| 93 |
I8-98049 689-0 |
|
NUT; HOLDER SET,CTR BRG |
2 |
1406- |
|
C |
P90 PROP SHAFT<C5T> M16 SLOTTED |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1108- |
|
ABC |
M10 FLANGE |
| 349 |
I1-09811 420-0 |
|
BEARING; FRT UJT,PROP SHAFT |
4 |
1108- |
|
ABC |
|
| 104 |
I1-09600 064-0 |
|
PLUG; SLEEVE YOKE |
1 |
1108- |
|
ABC |
|
| 1 |
I1-37124 342-1 |
|
SHAFT; PROP |
1 |
1108- |
|
A |
(A) L=1176 |
| 23 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
1 |
1108- |
|
C |
|
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1108- |
|
C |
M10 FLANGE |
| 1 |
I8-98106 153-0 |
|
SHAFT; PROP |
1 |
1108- |
|
C |
(B) L=1219 |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1108- |
|
ABC |
(A) |
| 173 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1108- |
|
C |
M10X2 5 FLANGE IDN |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1312- |
|
ABC |
M10 FLANGE |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1108- |
|
C |
M10 FLANGE |
| 19 |
I1-09587 088-1 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
C |
OD=45.5 T=2.05 YELLOW |
| 1 |
I1-37124 079-0 |
|
SHAFT ASM;RR PROP |
1 |
1403- |
|
B |
GVR-TH |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1406- |
|
C |
P46 PROP SHAFT<C4Z> M10 FLANGE |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1108- |
|
ABC |
(B) M14 |
| 177 |
I7-05110 010-A |
|
NUT |
4 |
1406- |
|
C |
P46 PROP SHAFT<C4Z> M10 FLANGE |
| 24 |
I8-98020 882-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1108- |
|
C |
(B) |
| 46 |
I8-98020 815-0 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1108- |
|
C |
(B) |
| 74 |
I1-09000 383-0 |
|
BOLT; YOKE,TRANS |
4 |
1108- |
|
ABC |
(A) M16X48 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
4 |
1108- |
|
ABC |
(A) IDN |
| 60 |
I0-91614 610-0 |
|
WASHER; PL,RET TO BRKT |
4 |
1108- |
|
C |
ID=10.5 OD=22 |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1406- |
|
ABC |
P46 PROP SHAFT<C4Z> M10 FLANGE |
| 1 |
I8-98090 933-0 |
|
SHAFT; PROP |
1 |
1112- |
|
B |
(B) L=1504 |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
1 |
1108- |
|
C |
(B) |
| 56 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1108- |
|
ABC |
(A) M16 FLANGE |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
1 |
1108- |
|
ABC |
PT1/8 ELBOW |
| 1 |
I8-98095 877-0 |
|
SHAFT; PROP |
1 |
1108- |
|
B |
(B) L=1504 |
| 46 |
I1-37245 071-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1108- |
|
ABC |
(A) |
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1108- |
|
C |
(B) |
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
C |
OD=45.5 T=2.0 0 WHITE |
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1108- |
|
ABC |
M10 FLANGE |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
2 |
1108- |
|
ABC |
PT1/8 ELBOW |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1108- |
|
ABC |
(B) M14 |
| 8 |
I8-98178 052-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1108- |
|
ABC |
(C) |
| 49 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1108- |
|
C |
M14 |
| 128 |
I1-37247 024-0 |
|
SEAL; SLEEVE |
1 |
1108- |
|
ABC |
|
| 52 |
I0-91510 814-0 |
|
WASHER; LK,YOKE |
4 |
1108- |
|
C |
ID=14.2 |
| 51 |
I8-97160 857-0 |
|
NUT; FLANGE,SPLINED |
1 |
1108- |
|
C |
M3 0 |
| 19 |
I1-09587 086-0 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
C |
OD=45.5 T=1.95 BLUE |
| 56 |
I7-05014 012-A |
|
NUT; YOKE |
4 |
1312-1405 |
|
ABC |
(B) M14 |
| 174 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1108- |
|
ABC |
M10 FLANGE |
| 1 |
I8-98095 876-0 |
|
SHAFT; PROP |
1 |
1108- |
|
A |
(B) L=849 |
| 23 |
I9-00090 071-0 |
|
BEARING; CENTER,PROP SHAFT |
1 |
1108- |
|
ABC |
|
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1312-1405 |
|
ABC |
M10 FLANGE |
| 1 |
I1-37124 081-0 |
|
SHAFT; PROP |
1 |
1403- |
|
B |
GVR-TH |
| 25 |
I8-98020 889-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
1108- |
|
C |
(B) |
| 19 |
I1-09587 087-2 |
|
RING; SNAP,JOURNAL,PROP SHAFT,1ST |
4 |
1108- |
|
ABC |
OD=45.5 T=2.0 0 WHITE |
| 57 |
I0-91510 814-0 |
|
WASHER; LK,YOKE |
4 |
1108- |
|
ABC |
ID=14.2 |
| 14 |
I8-98020 800-0 |
|
COVER; DUST,SPIDER |
8 |
1108- |
|
ABC |
(B) |
| 172 |
I1-37515 136-0 |
|
BRACKET; CENTER BRG |
1 |
1108- |
|
B |
(A) |
| 17 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
1 |
1108- |
|
C |
PT1/8 ELBOW |
| 107 |
I1-37249 060-1 |
|
COVER; RET,SLEEVE |
1 |
1108- |
|
ABC |
|
| 64 |
I7-05110 010-A |
|
NUT; RET TO BRKT |
4 |
1108- |
|
C |
M10 FLANGE |
| 9 |
I8-98048 925-0 |
|
JOURNAL ASM; PROP SHAFT |
0 |
1108- |
|
ABC |
(B) |
| 172 |
I1-37515 102-0 |
|
BRACKET; CENTER BRG |
1 |
1108- |
|
C |
(A) |
| 8 |
I1-37211 056-3 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
1108- |
|
ABC |
(B) |
| 22 |
I1-37516 059-0 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
1 |
1108- |
|
C |
|
| 80 |
I8-98049 689-0 |
|
NUT; HOLDER SET,CENTER BRG,1ST PROP |
4 |
1406- |
|
BC |
P90 PROP SHAFT<C5T> M16 SLOTTED |
| 1 |
I1-37124 249-1 |
|
SHAFT; PROP |
1 |
1108- |
|
BC |
(A) L=1281 |
