2-25 | SPEEDOMETER DRIVEN GEAR
GIGA
GIGA FVZ
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 018 | I1-31119 057-0 | BOLT; CLU HSG TO TRANS | 10 | 1104- | FVZ | M18X85 | ||
| 034 | IE-88746 990-0 | STUD; CLU HSG | 2 | 1310- | GVZ | (B) | ||
| 027 | IE-91204 000-0 | NUT; CLU HSG TO TRANS | 12 | 1310- | GVZ | |||
| 001 | I1-33372 181-0 | GEAR; DRIVEN,SPD | 1 | 1310- | GVZ | Z=14 | ||
| 032 | I0-28151 090-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 2 | 1104- | FVZ | (B) M10X90 FLANGE | ||
| 032 | I8-94399 669-1 | BOLT; CLU HSG TO FLYWHEEL HSG | 9 | 1104- | FVZ | (A) M10X75 FLANGE | ||
| 019 | I1-31119 012-0 | WASHER; PL,CLU HSG TO TRANS | 10 | 1104- | FVZ | |||
| 002 | I1-33379 020-0 | BUSHING; DRIVEN GEAR,SPEEDOMETER | 1 | 1310- | GVZ | (A) | ||
| 032 | I0-28051 045-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 2 | 1310- | GVZ | (B) M10X45 FLANGE | ||
| 002 | I1-33379 017-0 | BUSHING; DRIVEN GEAR,SPEEDOMETER | 1 | 1310- | GVZ | (B) | ||
| 032 | I0-28051 035-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 10 | 1310- | GVZ | (A) M10X35 FLANGE | ||
| 034 | I1-33119 581-0 | STUD; CLU HSG | 10 | 1310- | GVZ | (A) | ||
| 003 | I1-33379 014-0 | GASKET; BUSHING | 1 | 1310- | GVZ |
