| 008 |
I1-47112 011-0 |
|
BUSHING; BRK SHOE |
4 |
1104- |
|
ALL |
|
| 037 |
I1-47169 033-0 |
|
WASHER; ADJ CAM |
4 |
1104- |
|
ALL |
|
| 020 |
I1-47634 006-0 |
|
BOLT; JOINT |
2 |
1104- |
|
ALL |
M12X40.5 EYE BOLT |
| 003 |
I1-47125 812-0 |
|
LINING; FRT BRK SHOE,OVER SIZE |
8 |
1104- |
|
ALL |
|
| 029 |
I1-09583 269-1 |
|
SPRING; RETURN,FRT BRK SHOE |
2 |
1104- |
|
ALL |
|
| 017 |
I1-47619 011-0 |
|
CAP; BLEEDER,FRT WHEEL CYL |
2 |
1104- |
|
ALL |
OD=12 |
| 004 |
I6-88310 495-0 |
|
LINING SET; FRT BRK,STANDARD |
2 |
1104- |
|
ALL |
(IADG) (A) |
| 021 |
I1-09630 020-0 |
|
GASKET; UNION BOLT |
2 |
1104- |
|
ALL |
(B) ID=12.2 |
| 002 |
I1-47125 811-0 |
|
LINING; FRT BRK SHOE,STANDARD |
8 |
1104- |
|
ALL |
|
| 028 |
I1-47116 002-0 |
|
PIN; SHOE ADJ CAM GUIDE |
4 |
1104- |
|
ALL |
|
| 021 |
I1-09630 019-0 |
|
GASKET; UNION BOLT |
2 |
1104- |
|
ALL |
(A) ID=15.2 |
| 022 |
I1-47631 057-1 |
|
JOINT; PIPE |
2 |
1104- |
|
ALL |
|
| 015 |
I1-47600 778-0 |
|
CYLINDER; WHEEL,FRT BRK |
1 |
1104- |
|
ALL |
|
| 030 |
I1-47137 435-0 |
|
BRACKET; ANCHOR,FRT |
2 |
1104- |
|
ALL |
|
| 035 |
I0-50551 235-0 |
|
BOLT; FRT WHEEL CYL |
4 |
1104- |
|
ALL |
M12X35 W/LK WASHER |
| 005 |
I1-88310 496-1 |
|
LINING SET; FRT BRK,OVER SIZE |
2 |
1104- |
|
ALL |
|
| 038 |
I1-47169 046-0 |
|
SPRING; ADJ CAM |
4 |
1104- |
|
ALL |
|
| 015 |
I1-47600 777-0 |
|
CYLINDER; WHEEL,FRT BRK |
1 |
1104- |
|
ALL |
|
| 045 |
I1-47133 011-0 |
|
WASHER; LK |
2 |
1104- |
|
ALL |
|
| 040 |
I1-47169 031-0 |
|
COVER; BOOT,ADJ CAM |
4 |
1104- |
|
ALL |
|
| 039 |
I1-47169 034-0 |
|
BOOT; ADJ CAM |
4 |
1104- |
|
ALL |
|
| 004 |
I1-88310 495-1 |
|
LINING SET; FRT BRK,STANDARD |
2 |
1104- |
|
ALL |
(A) |
| 026 |
I1-87830 521-0 |
|
CUP SET; FRT WHEEL CYL |
2 |
1104- |
|
ALL |
ID=47.5 |
| 044 |
I0-20851 016-0 |
|
BOLT; LOCK,ANCHOR PIN |
2 |
1104- |
|
ALL |
M10X16 |
| 036 |
I1-47165 059-1 |
|
CAM ASM; ADJ |
2 |
1104- |
|
ALL |
(B) |
| 023 |
I9-09940 435-0 |
|
SPRING; COIL |
2 |
1104- |
|
ALL |
|
| 016 |
I1-47615 005-0 |
|
SCREW; BLEEDER,FRT BRK |
2 |
1104- |
|
ALL |
L=66.5 |
| 027 |
I1-47621 009-0 |
|
ROD; PUSH |
4 |
1104- |
|
ALL |
|
| 036 |
I1-47165 058-1 |
|
CAM ASM; ADJ |
2 |
1104- |
|
ALL |
(A) |
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,FRT BRK |
80 |
1104- |
|
ALL |
L=18.5 |
| 046 |
I1-47133 005-0 |
|
PLATE; LOCK |
2 |
1104- |
|
ALL |
|
| 014 |
I1-47119 017-1 |
|
PIN; SHOE RETURN SPR |
4 |
1104- |
|
ALL |
L=73.5 |
| 043 |
I1-47131 038-0 |
|
PIN; ANCHOR |
4 |
1104- |
|
ALL |
L=106.5 |
| 041 |
I1-47169 032-1 |
|
INDICATOR |
4 |
1104- |
|
ALL |
|
| 033 |
I1-47159 080-0 |
|
COVER; WHEEL CYL |
2 |
1104- |
|
ALL |
|
| 042 |
I1-47169 030-0 |
|
PIN; SPINDLE |
4 |
1104- |
|
ALL |
|
| 001 |
I1-47120 706-0 |
|
SHOE; BRK,FRT |
4 |
1104- |
|
ALL |
|
| 024 |
I9-47624 210-0 |
|
PISTON; FRT WHEEL CYL |
4 |
1104- |
|
ALL |
|
| 034 |
I1-47159 094-0 |
|
PLATE; DIRECTION,FRT |
2 |
1104- |
|
ALL |
|
