| 126 |
I1-09660 876-0 |
|
CONNECTOR; ELBOW |
1 |
1402-1403 |
|
GVZ |
(K) DIN12 & M16 STRAIGHT ; MIXER |
| 037 |
I0-28651 040-0 |
|
BOLT; AIR TANK |
4 |
1310- |
|
ALL |
(A) M10X40 FLANGE |
| 002 |
I8-98195 655-0 |
|
TANK; AIR |
1 |
1310- |
|
FVZ |
(A) |
| 128 |
I1-53319 018-0 |
|
PROTECTOR |
1 |
1104- |
|
ALL |
|
| 003 |
I1-48410 182-3 |
|
VALVE; CHECK,AIR TANK |
2 |
1104- |
|
ALL |
(A) M20 & PT3/4 STRAIGHT |
| 005 |
I1-09660 876-0 |
|
UNION; AIR TANK |
1 |
1104- |
|
ALL |
(B) DIN12 & M16 STRAIGHT |
| 140 |
I0-28651 025-0 |
|
BOLT; OIL TANK TO BRKT |
3 |
1104- |
|
ALL |
M10X25 FLANGE |
| 126 |
I1-09660 877-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(C) DIN12 & M20 STRAIGHT |
| 003 |
I1-48410 134-3 |
|
VALVE; CHECK,AIR TANK |
1 |
1404- |
|
GVZ |
(C) M22 & PT3/4 ELBOW |
| 104 |
I0-91180 108-0 |
|
NUT; BRKT |
4 |
1104- |
|
GVZ |
M8 FLANGE ; MIXER |
| 064 |
I1-53318 293-1 |
|
STAY; AIR TANK,MAIN |
1 |
1104- |
|
ALL |
(B) |
| 054 |
I7-05110 010-A |
|
NUT; STAY |
2 |
1104- |
|
ALL |
M10 FLANGE |
| 178 |
I8-98150 355-0 |
|
CLIP; HOSE |
1 |
1104- |
|
ALL |
ID=21 |
| 126 |
I1-09661 025-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(H) DIN8X2 & PT3/8 DOUBLE ELBOW |
| 037 |
I0-28651 240-0 |
|
BOLT; AIR TANK |
6 |
1104- |
|
ALL |
(B) M12X40 FLANGE |
| 153 |
I0-91110 508-0 |
|
NUT; OIL TANK TO BAND |
2 |
1104- |
|
ALL |
M8 |
| 086 |
I1-47529 019-0 |
|
SEAL; DUST |
1 |
1104- |
|
ALL |
|
| 081 |
I1-47800 795-0 |
|
AIR MASTER ASM; BRK |
1 |
1104- |
|
ALL |
PRIMARY |
| 177 |
I0-03566 300-0 |
|
HOSE; RUBBER,DRAIN |
1 |
1104- |
|
ALL |
L=60 |
| 046 |
I0-91110 508-0 |
|
NUT; U-BOLT |
8 |
1104- |
|
ALL |
M8 |
| 381 |
I0-91110 514-0 |
|
NUT; SUB TANK |
4 |
1104-1303 |
|
GVZ |
(A) M14 ; MIXER |
| 080 |
I0-28651 025-0 |
|
BOLT; BRKT |
4 |
1310- |
|
FVZ |
(B) M10X25 FLANGE |
| 240 |
I1-47529 018-0 |
|
HOLDER; FILTER |
1 |
1104- |
|
ALL |
|
| 213 |
I1-48317 301-A |
|
BOLT; U AIR TANK |
2 |
1104- |
|
ALL |
(A) |
| 080 |
I0-28650 820-0 |
|
BOLT; BRKT |
4 |
1104- |
|
GVZ |
(A) M8X20 FLANGE ; MIXER |
| 126 |
I1-09660 966-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(F) DIN12 & R1/2 STRAIGHT |
| 126 |
I1-09660 959-0 |
|
CONNECTOR; ELBOW |
2 |
1402- |
|
FVZ |
(L) DIN12 & R3/8 ELBOW ; MIXER |
| 238 |
I1-47529 022-0 |
|
PLATE; BAFFLE |
1 |
1104- |
|
ALL |
|
| 136 |
I1-47477 629-2 |
|
BRACKET; CLIP |
1 |
1402- |
|
FVZ |
(C) L=150 H=30 ; MIXER |
| 064 |
I1-48317 760-0 |
|
STAY; AIR TANK,MAIN |
1 |
1104- |
|
ALL |
(A) |
| 043 |
I0-28651 030-0 |
|
BOLT; STAY,AIR TANK,MAIN |
6 |
1104- |
|
ALL |
(B) M10X30 FLANGE |
| 007 |
I1-09630 145-0 |
|
GASKET; DRAIN COCK |
5 |
1107-1501 |
|
GVZ |
ID=14 ; MIXER |
| 126 |
I1-09656 698-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
FVZ |
(A) DIN6 & PT1/4 & M12 3WAY |
| 125 |
I1-47469 118-A |
|
HOSE; OIL TANK TO AIR MASTER |
1 |
1104- |
|
ALL |
(A) |
| 010 |
I9-99204 513-0 |
|
PLUG; AIR TANK |
1 |
1104- |
|
ALL |
PT1/4 |
| 119 |
I0-28651 025-0 |
|
BOLT; STAY |
2 |
1104- |
|
ALL |
M10X25 FLANGE |
| 080 |
I0-28650 825-0 |
|
BOLT; BRKT |
1 |
1104-1303 |
|
GVZ |
(D) M8X25 FLANGE ; MIXER |
| 126 |
I1-09661 007-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(G) DIN12X2 & R3/8 3WAY |
| 026 |
I9-09204 517-0 |
|
PLUG; SUB AIR TANK |
3 |
1310- |
|
GVZ |
PT3/8 ; MIXER |
| 028 |
I8-98174 720-0 |
|
BRACKET; AIR TANK |
2 |
1104- |
|
GVZ |
|
| 005 |
I1-09660 877-0 |
|
UNION; AIR TANK |
2 |
1104- |
|
ALL |
(C) DIN12 & M20 STRAIGHT |
| 081 |
I1-47800 794-0 |
|
AIR MASTER ASM; BRK |
1 |
1104- |
|
ALL |
SECONDARY |
| 027 |
I1-09660 959-0 |
|
UNION; ELBOW,AIR TANK |
1 |
1104-1303 |
|
GVZ |
(A) DIN12 & R3/8 ELBOW ; MIXER |
| 030 |
I8-97948 143-0 |
|
BRACKET; AIR TANK,SUB |
2 |
1312-1401 |
|
FVZ |
(A) |
| 271 |
I7-05110 010-A |
|
NUT; BRKT,HOSE |
3 |
1104- |
|
ALL |
M10 FLANGE |
| 030 |
I8-98182 085-0 |
|
BRACKET; AIR TANK,SUB |
1 |
1104-1303 |
|
FVZ |
(D) MIXER |
| 058 |
I0-91110 508-0 |
|
NUT; BAND,AIR TANK |
12 |
1104- |
|
ALL |
M8 |
| 005 |
I8-98204 239-0 |
|
UNION; AIR TANK |
1 |
1201- |
|
ALL |
(A) M16 & R3/8 |
| 030 |
I8-98136 697-0 |
|
BRACKET; AIR TANK,SUB |
1 |
1404- |
|
GVZ |
(G) |
| 039 |
I1-48317 087-2 |
|
U-BOLT; AIR TANK |
2 |
1404- |
|
GVZ |
L=303 |
| 013 |
I1-09660 878-0 |
|
ADAPTER; NYLON TUBE |
1 |
1404- |
|
GVZ |
DIN12 & M12 STRAIGHT |
| 136 |
I8-98260 760-0 |
|
BRACKET; CLIP |
2 |
1402- |
|
FVZ |
(B) MIXER |
| 042 |
I1-14319 034-0 |
|
WASHER; PL |
4 |
1104- |
|
ALL |
ID=8.4 OD=18 |
| 039 |
I1-48317 289-0 |
|
U-BOLT; AIR TANK |
2 |
1310- |
|
FVZ |
|
| 366 |
I1-09660 959-0 |
|
CONNECTOR; NYLON TUBE |
1 |
1310- |
|
FVZ |
DIN12 & R3/8 ELBOW |
| 172 |
I7-05110 010-A |
|
NUT; STAY,AIR TANK,MAIN |
6 |
1104- |
|
ALL |
M10 FLANGE |
| 136 |
I8-98119 184-1 |
|
BRACKET; CLIP |
2 |
1104- |
|
GVZ |
(B) |
| 126 |
I1-09656 586-1 |
|
CONNECTOR; ELBOW |
1 |
1402-1403 |
|
GVZ |
(I) M12 & PT1/4 3WAY ; MIXER |
| 079 |
I1-53318 348-0 |
|
STAY; AIR MASTER TO BRKT |
1 |
1104- |
|
ALL |
(A) |
| 213 |
I1-48317 302-A |
|
BOLT; U AIR TANK |
1 |
1104- |
|
ALL |
(B) |
| 037 |
I0-28651 230-0 |
|
BOLT; AIR TANK |
4 |
1402-1403 |
|
ALL |
(B) M12X30 FLANGE |
| 009 |
I8-97609 249-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
1104- |
|
ALL |
STAMP 5.5 |
| 028 |
I8-98250 640-1 |
|
BRACKET; AIR TANK |
2 |
1402- |
|
FVZ |
MIXER |
| 001 |
I8-98269 244-0 |
|
TANK ASM; AIR |
1 |
1502- |
|
ALL |
(A) |
| 030 |
I1-48316 026-0 |
|
BRACKET; AIR TANK,SUB |
1 |
1404- |
|
GVZ |
(F) |
| 030 |
I1-48317 994-2 |
|
BRACKET; AIR TANK,SUB |
1 |
1104-1303 |
|
GVZ |
(E) MIXER |
| 136 |
I1-47477 646-3 |
|
BRACKET; CLIP |
1 |
1404- |
|
GVZ |
(D) L=225 H=30 |
| 037 |
I0-20851 450-0 |
|
BOLT; AIR TANK |
4 |
1104-1303 |
|
ALL |
(A) M14X50 |
| 030 |
I1-48316 024-3 |
|
BRACKET; AIR TANK,SUB |
1 |
1402-1403 |
|
GVZ |
(H) MIXER |
| 039 |
I1-48317 248-A |
|
U-BOLT; AIR TANK |
2 |
1104-1303 |
|
FVZ |
L=253 ; MIXER |
| 079 |
I8-98120 254-0 |
|
STAY; AIR MASTER TO BRKT |
1 |
1104- |
|
ALL |
(B) |
| 126 |
I1-09660 965-0 |
|
CONNECTOR; ELBOW |
2 |
1104- |
|
GVZ |
(E) DIN12 & R3/8 STRAIGHT |
| 237 |
I1-47525 030-0 |
|
CAP; OIL TANK |
1 |
1104- |
|
ALL |
|
| 001 |
I1-48370 493-0 |
|
TANK ASM; AIR |
1 |
1104-1501 |
|
ALL |
(A) |
| 152 |
I0-28650 820-0 |
|
BOLT; OIL TANK TO BAND |
2 |
1104- |
|
ALL |
M8X20 FLANGE |
| 126 |
I1-09660 960-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(D) DIN12 & R1/2 ELBOW |
| 003 |
I1-48410 412-0 |
|
VALVE; CHECK,AIR TANK |
1 |
1104- |
|
ALL |
(B) M20 & PT3/4 ELBOW |
| 103 |
I0-28650 820-0 |
|
BOLT; BRKT |
1 |
1404- |
|
GVZ |
M8X20 FLANGE |
| 030 |
I8-98182 821-A |
|
BRACKET; AIR TANK,SUB |
1 |
1104-1303 |
|
FVZ |
(C) MIXER |
| 381 |
I0-91180 212-0 |
|
NUT; SUB TANK |
1 |
1402-1403 |
|
GVZ |
(B) M12 FLANGE ; MIXER |
| 145 |
I1-09704 102-0 |
|
CLIP; OIL TANK TO AIR MASTER HOSE |
4 |
1104- |
|
ALL |
ID=14 |
| 006 |
I1-48312 015-0 |
|
COCK; DRAIN,AIR TANK |
5 |
1107-1501 |
|
GVZ |
MIXER |
| 080 |
I0-28651 030-0 |
|
BOLT; BRKT |
4 |
1104- |
|
ALL |
(C) M10X30 FLANGE |
| 125 |
I1-47469 119-A |
|
HOSE; OIL TANK TO AIR MASTER |
1 |
1104- |
|
ALL |
(B) |
| 030 |
I8-98245 717-0 |
|
BRACKET; AIR TANK,SUB |
1 |
1312-1401 |
|
FVZ |
(B) |
| 139 |
I8-98174 721-A |
|
BRACKET; OIL TANK |
1 |
1104- |
|
ALL |
|
| 067 |
I1-48317 321-2 |
|
STAY; SUB TANK |
1 |
1104- |
|
ALL |
|
| 043 |
I0-28651 025-0 |
|
BOLT; STAY,AIR TANK,MAIN |
2 |
1104- |
|
ALL |
(A) M10X25 FLANGE |
| 151 |
I1-47537 056-2 |
|
BAND; OIL TANK,AIR MASTER |
2 |
1104- |
|
ALL |
|
| 005 |
I1-09661 026-0 |
|
UNION; AIR TANK |
2 |
1104- |
|
ALL |
(D) DIN12X2 & PT3/8 DOUBLE ELBOW |
| 001 |
I8-98179 212-0 |
|
TANK ASM; AIR |
1 |
1104- |
|
ALL |
(B) |
| 117 |
I0-91510 514-0 |
|
WASHER; LK,BRKT |
4 |
1402-1403 |
|
GVZ |
ID=14.2 ; MIXER |
| 082 |
I7-05110 010-A |
|
NUT; STAY,AIR MASTER BRKT |
4 |
1104- |
|
ALL |
M10 FLANGE |
| 129 |
I0-28650 830-0 |
|
BOLT; PROTECTOR FIX |
2 |
1104- |
|
ALL |
M8X30 FLANGE |
| 126 |
I1-09656 677-0 |
|
CONNECTOR; ELBOW |
1 |
1402-1403 |
|
GVZ |
(J) M16 & PT1/4 & PT3/8 3WAY ; MIXER |
| 241 |
I0-28051 020-0 |
|
BOLT; SET,CONT VLV |
2 |
1404- |
|
GVZ |
M10X20 FLANGE |
| 130 |
I0-91180 108-0 |
|
NUT; PROTECTOR FIX |
2 |
1104- |
|
ALL |
M8 FLANGE |
| 239 |
I1-47529 017-0 |
|
FILTER; DUST |
1 |
1104- |
|
ALL |
|
| 002 |
I8-98179 213-0 |
|
TANK; AIR |
1 |
1104-1303 |
|
FVZ |
(B) MIXER |
| 027 |
I1-09661 026-0 |
|
UNION; ELBOW,AIR TANK |
1 |
1404- |
|
GVZ |
(B) DIN12X2 & PT3/8 DOUBLE ELBOW |
| 138 |
I1-47530 185-1 |
|
TANK ASM; OIL,AIR MASTER |
1 |
1104- |
|
ALL |
|
| 136 |
I1-47475 530-0 |
|
BRACKET; CLIP |
1 |
1104- |
|
ALL |
(A) L=90 B=25 |
| 083 |
I7-05110 010-A |
|
NUT; AIR MASTER |
10 |
1104- |
|
ALL |
M10 FLANGE |
| 126 |
I1-09660 873-0 |
|
CONNECTOR; ELBOW |
1 |
1104- |
|
ALL |
(B) DIN8 & M12 STRAIGHT |
| 002 |
I8-98257 340-0 |
|
TANK; AIR |
1 |
1404- |
|
GVZ |
(C) |
