3-25 | BRAKE LOCK CONTROL
GIGA
GIGA FVZ
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 032 | I1-09661 007-0 | UNION; DOUBLE CHECK VLV | 1 | 1402- | FVZ | (A) DIN12X2 & R3/8 3WAY ; MIXER | ||
| 026 | I1-09660 958-0 | UNION; CONT VLV | 1 | 1402- | FVZ | (C) DIN12 & R1/4 ELBOW ; MIXER | ||
| 025 | I1-82563 871-2 | VALVE; CONT,BRK LOCK | 1 | 1104- | FVZ | (A) MIXER | ||
| 032 | I1-09660 959-0 | UNION; DOUBLE CHECK VLV | 3 | 1402- | FVZ | (C) DIN12 & R3/8 ELBOW ; MIXER | ||
| 035 | I0-91180 108-0 | NUT; BRKT | 2 | 1104- | ALL | (A) M8 FLANGE | ||
| 029 | I0-28651 030-0 | BOLT; BRKT,CONT VLV | 6 | 1402- | FVZ | (C) M10X30 FLANGE ; MIXER | ||
| 026 | I1-09660 967-0 | UNION; CONT VLV | 1 | 1402- | FVZ | (E) DIN12 & R1/4 STRAIGHT ; MIXER | ||
| 025 | I1-46362 112-0 | VALVE; CONT,BRK LOCK | 1 | 1402- | FVZ | (B) MIXER | ||
| 032 | I1-09660 965-0 | UNION; DOUBLE CHECK VLV | 2 | 1402- | FVZ | (B) DIN12 & R3/8 STRAIGHT ; MIXER | ||
| 035 | I7-05110 010-A | NUT; BRKT | 6 | 1402- | FVZ | (B) M10 FLANGE ; MIXER | ||
| 026 | I1-09660 693-0 | UNION; CONT VLV | 2 | 1402- | FVZ | (D) PT1/4 & PT1/4 2WAY ; MIXER | ||
| 034 | I0-28050 812-A | BOLT; BRKT | 4 | 1402- | FVZ | M8X12 FLANGE ; MIXER | ||
| 028 | I8-98250 617-0 | BRACKET; CONT VLV | 1 | 1402- | FVZ | (B) MIXER | ||
| 028 | I8-98273 570-0 | BRACKET; CONT VLV | 1 | 1104-1405 | ALL | (A) | ||
| 026 | I1-09650 430-0 | UNION; CONT VLV | 1 | 1104- | ALL | (A) M12 & PT1/4 ELBOW | ||
| 050 | I9-99204 513-0 | PLUG | 1 | 1104- | ALL | PT1/4 | ||
| 029 | I0-28650 825-0 | BOLT; BRKT,CONT VLV | 2 | 1104- | ALL | (B) M8X25 FLANGE | ||
| 033 | I8-98250 622-0 | BRACKET; DBL CHECK VLV | 2 | 1402- | FVZ | MIXER | ||
| 026 | I1-09660 956-0 | UNION; CONT VLV | 1 | 1104- | ALL | (B) DIN8 & R1/4 ELBOW | ||
| 029 | I0-36220 514-0 | BOLT; BRKT,CONT VLV | 3 | 1402- | FVZ | (D) M5X14 W/LK WASHER ; MIXER | ||
| 029 | I0-28650 820-0 | BOLT; BRKT,CONT VLV | 2 | 1104- | ALL | (A) M8X20 FLANGE | ||
| 027 | I8-97609 251-0 | SWITCH; PRESS | 1 | 1402- | FVZ | STAMP 2.8 ; MIXER | ||
| 025 | I8-97948 152-0 | VALVE; CONT,BRK LOCK | 1 | 1312-1401 | FVZ | (A) | ||
| 031 | I1-48410 531-1 | VALVE; DOUBLE CHECK | 2 | 1402- | FVZ | CHECK VALVE ; MIXER |
