| 081 |
I0-81124 025-0 |
|
PIN; SPLIT,HOLDER SET,CENTER BRG |
2 |
1310- |
|
FVZ |
OD=3.7 L=25 ; LWB |
| 091 |
I1-09042 030-0 |
|
BOLT; HOLDER SET,CTR BRG |
2 |
1310- |
|
FVZ |
M16X45 ; LWB |
| 013 |
I1-37355 020-0 |
|
COVER; FRT UJT,PROP SHAFT |
4 |
1104-1309 |
|
ALL |
|
| 080 |
I8-98049 689-0 |
|
NUT; HOLDER SET,CENTER BRG,1ST PROP |
2 |
1310- |
|
FVZ |
M16 SLOTTED ; LWB |
| 014 |
I1-37249 131-0 |
|
COVER; DUST,SPIDER |
8 |
1310- |
|
FVZ |
(A) DUMP ; LWB ; MIXER |
| 128 |
I8-97603 618-0 |
|
SEAL; SLEEVE |
1 |
1104- |
|
ALL |
(B) EXC. MIXER |
| 010 |
I0-20951 020-0 |
|
BOLT; UJT |
16 |
1310- |
|
FVZ |
(A) M10X20 ; DUMP ; LWB ; MIXER |
| 079 |
I1-09503 241-1 |
|
WASHER; PL,HOLDER SET,CENTER BRG |
2 |
1310- |
|
FVZ |
ID=17 ; LWB |
| 009 |
I1-37300 100-1 |
|
JOURNAL ASM; PROP SHAFT |
1 |
1104- |
|
ALL |
(B) EXC. MIXER |
| 225 |
I1-37241 103-1 |
|
YOKE; SLEEVE,PROP SHAFT |
1 |
1104-1309 |
|
ALL |
L=332 ; EXC. MIXER |
| 104 |
I1-09600 067-0 |
|
PLUG; SLEEVE YOKE |
1 |
1104-1309 |
|
ALL |
(A) EXC. MIXER |
| 092 |
I1-09503 241-1 |
|
WASHER; LK,HOLDER SET,CTR BRG |
2 |
1310- |
|
FVZ |
ID=17 ; LWB |
| 046 |
I1-37245 271-1 |
|
FLANGE; SPLINED,PROP SHAFT,1ST |
1 |
1310- |
|
FVZ |
LWB |
| 096 |
I8-98036 382-0 |
|
BOLT; PROP SHAFT |
8 |
1104- |
|
ALL |
M12X45 ; EXC. MIXER |
| 024 |
I1-37529 041-0 |
|
RETAINER; CENTER BRG,1ST |
1 |
1310- |
|
FVZ |
LWB |
| 170 |
I0-91510 612-0 |
|
WASHER; LK,YOKE,SLEEVE |
4 |
1104- |
|
ALL |
ID=12.2 ; EXC. MIXER |
| 058 |
I1-37245 317-0 |
|
FLANGE; SPLINED |
1 |
1104- |
|
ALL |
L=265 ; EXC. MIXER |
| 071 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1104- |
|
FVZ |
M16 FLANGE ; LWB |
| 093 |
I8-98049 689-0 |
|
NUT; HOLDER SET,CTR BRG |
2 |
1310- |
|
FVZ |
M16 SLOTTED ; LWB |
| 051 |
I1-09440 046-0 |
|
NUT; FLANGE,SPLINED |
1 |
1310- |
|
FVZ |
M39 FLANGE ; LWB |
| 011 |
I0-91510 612-0 |
|
WASHER; LK,UNIVERSAL,PROP SHAFT |
4 |
1104- |
|
ALL |
ID=12.2 ; EXC. MIXER |
| 057 |
I0-91510 612-0 |
|
WASHER; LK,YOKE |
8 |
1104- |
|
ALL |
ID=12.2 ; EXC. MIXER |
| 001 |
I8-98239 156-0 |
|
SHAFT; PROP |
1 |
1310- |
|
FVZ |
(C) L=1002 ; LWB |
| 084 |
I1-37355 020-0 |
|
COVER; UJT,PROP SHAFT |
4 |
1104-1309 |
|
ALL |
|
| 010 |
I8-98036 382-0 |
|
BOLT; UJT |
4 |
1104- |
|
ALL |
(B) M12X45 ; EXC. MIXER |
| 025 |
I1-09380 006-0 |
|
NIPPLE; GREASE,CENTER BRG |
1 |
1310- |
|
FVZ |
MT6 STRAIGHT ; LWB |
| 001 |
I8-98239 158-0 |
|
SHAFT; PROP |
1 |
1310- |
|
FVZ |
(D) L=902 ; LWB |
| 106 |
I0-90301 410-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
1104-1309 |
|
ALL |
PT1/8 STRAIGHT ; EXC. MIXER |
| 009 |
I1-37300 091-1 |
|
JOURNAL ASM; PROP SHAFT |
AR |
1104-1309 |
|
ALL |
(A) EXC. MIXER |
| 014 |
I1-37319 004-0 |
|
COVER; DUST,SPIDER |
8 |
1104- |
|
ALL |
(B) EXC. MIXER |
| 008 |
I1-37211 066-1 |
|
YOKE; FLANGE,PROP SHAFT |
2 |
1310- |
|
FVZ |
DUMP ; LWB ; MIXER |
| 020 |
I1-37510 094-3 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
1310- |
|
FVZ |
LWB |
| 169 |
I8-98036 382-0 |
|
BOLT; YOKE,SLEEVE |
4 |
1104- |
|
ALL |
M12X45 ; EXC. MIXER |
| 012 |
I1-37356 008-0 |
|
PLATE; LK,FRT UJT,PROP SHAFT |
4 |
1104-1309 |
|
ALL |
|
| 001 |
I1-37124 233-0 |
|
SHAFT; PROP |
1 |
1104- |
|
FVZ |
(A) L=1407 ; DUMP |
| 022 |
I1-37516 048-2 |
|
RUBBER; CUSHION,CENTER BRG,1ST |
1 |
1310- |
|
FVZ |
LWB |
| 023 |
I9-00090 256-0 |
|
BEARING; CENTER,PROP SHAFT |
1 |
1310- |
|
FVZ |
LWB |
| 001 |
I1-37124 182-0 |
|
SHAFT; PROP |
1 |
1310- |
|
FVZ |
(B) L=1172 ; LWB |
| 049 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1310- |
|
FVZ |
M16 FLANGE ; LWB |
| 078 |
I1-09042 030-0 |
|
BOLT; HOLDER SET,CENTER BRG,1ST PROP |
2 |
1310- |
|
FVZ |
M16X45 ; LWB |
| 017 |
I0-90301 510-0 |
|
NIPPLE; GREASE,PROP SHAFT |
2 |
1310- |
|
ALL |
PT1/8 ELBOW 67.5 DEGREES |
| 074 |
I1-09000 383-0 |
|
BOLT; YOKE,TRANS |
4 |
1104-1309 |
|
ALL |
M16X48 ; EXC. MIXER |
| 015 |
I1-37300 100-1 |
|
UNIVERSAL CENTER |
1 |
1104- |
|
ALL |
|
| 021 |
I1-09625 127-0 |
|
SEAL; OIL,CENTER BRG |
2 |
1310- |
|
FVZ |
D=120 ; LWB |
| 001 |
I1-37124 496-0 |
|
SHAFT; PROP |
1 |
1402- |
|
FVZ |
(A) MIXER |
| 004 |
I1-37171 127-2 |
|
SHAFT; PROP |
1 |
1104- |
|
ALL |
L=348 ; EXC. MIXER |
| 001 |
I1-37124 132-0 |
|
SHAFT; PROP |
1 |
1310- |
|
FVZ |
(A) L=1482 ; DUMP |
| 083 |
I1-37356 008-0 |
|
PLATE; LK,UJT,PROP SHAFT |
4 |
1104-1309 |
|
ALL |
|
| 056 |
I1-09449 065-0 |
|
NUT; YOKE |
4 |
1104-1309 |
|
ALL |
M16 FLANGE ; EXC. MIXER |
| 001 |
I1-37124 184-0 |
|
SHAFT; PROP |
1 |
1404- |
|
FVZ |
(A) L=927 ; MIXER |
| 094 |
I0-81124 025-0 |
|
PIN; SPLIT,HOLDER SET CTR BRG |
2 |
1310- |
|
FVZ |
OD=3.7 L=25 ; LWB |
| 128 |
I1-37247 019-0 |
|
SEAL; SLEEVE |
1 |
1104-1309 |
|
ALL |
(A) EXC. MIXER |
| 104 |
I1-09600 049-0 |
|
PLUG; SLEEVE YOKE |
1 |
1104- |
|
ALL |
(B) EXC. MIXER |
