2-25 | SPEEDOMETER DRIVEN GEAR
GIGA
NEW GIGA FVM
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 034 | IE-88746 990-0 | STUD; CLU HSG | 2 | 1706- | 9SP | (B) | ||
| 027 | IE-91204 000-0 | NUT; CLU HSG TO TRANS | 12 | 1706- | 9SP | |||
| 032 | I0-28051 035-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 8 | 1706- | 6SP | (D) M10X35 | ||
| 032 | I0-28051 035-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 10 | 1706- | 9SP | (A) M10X35 | ||
| 018 | IE-33054 800-0 | BOLT; CLU HSG TO TRANS | 4 | 1706- | 6SP | |||
| 032 | I0-28751 030-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 2 | 1706- | 6SP | (C) M10X30 | ||
| 032 | I0-28051 045-0 | BOLT; CLU HSG TO FLYWHEEL HSG | 2 | 1706- | ALL | (B) M10X45 | ||
| 035 | IE-31000 000-0 | WASHER; LK,CLU HSG TO TRANS | 4 | 1706- | 6SP | |||
| 034 | I1-33119 581-0 | STUD; CLU HSG | 10 | 1706- | 9SP | (A) |
