| 002 |
I1-88311 463-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
LEADING |
| 196 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 005 |
I8-97524 546-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
TRAILING |
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
2 |
1706- |
|
FVM |
M10X16 |
| 005 |
I8-97524 546-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
TRAILING |
| 065 |
I1-47143 014-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(B) |
| 005 |
I1-47126 712-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 034 |
I0-90301 510-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
2 |
1706- |
|
FVM |
(A) PT1/8 ELBOW 67.5 DEGREES |
| 006 |
I1-47125 442-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 048 |
I1-09625 228-0 |
|
SEAL; OIL,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
AR |
1811- |
|
FVM |
L=18.5 |
| 076 |
I8-97517 243-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
L |
FVM |
|
| 050 |
I8-97524 144-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(B) |
| 045 |
I8-98325 888-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
R |
FVM |
(A) FORWARD |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 002 |
I1-88311 435-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 155 |
I0-91614 516-0 |
|
WASHER; PL,WHEEL CYL |
4 |
1706- |
|
FVM |
ID=17 |
| 003 |
I1-88310 320-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 006 |
I1-47125 441-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 083 |
I1-09503 223-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(B) ID=16.2 |
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
AR |
1811- |
|
FVM |
L=18.5 |
| 195 |
I8-97524 559-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(D) |
| 225 |
I1-48279 031-0 |
|
PIN; SPLIT |
1 |
1706- |
|
FVM |
|
| 002 |
I1-88311 435-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 049 |
I1-47146 003-1 |
|
BUSHING; CM/SHF,RR BRK |
4 |
1706- |
|
FVM |
(A) |
| 200 |
I0-28050 816-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(A) M8X16 |
| 005 |
I1-47125 439-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 050 |
I8-97524 141-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(A) |
| 073 |
I8-98325 924-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 049 |
I1-47146 003-1 |
|
BUSHING; CM/SHF,RR BRK |
4 |
1706- |
|
FVM |
(A) |
| 083 |
I9-09851 672-2 |
|
WASHER; PL |
2 |
1707-1810 |
|
FVM |
(B) ID=16.2 |
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,RR BRK |
AR |
1811- |
|
FVM |
L=18.5 |
| 350 |
I1-48279 060-0 |
|
CLEVIS; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 045 |
I8-98325 889-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
L |
FVM |
(A) FORWARD |
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 083 |
I0-91510 510-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(A) ID=10.2 |
| 001 |
I8-98326 245-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
LEADING |
| 049 |
I1-47146 011-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1811- |
|
FVM |
(B) |
| 065 |
I8-98325 931-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1811- |
|
FVM |
(C) |
| 001 |
I8-97524 152-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
TRAILING |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 045 |
I8-97524 115-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1811- |
|
FVM |
(D) REARWARD |
| 083 |
I1-48279 033-0 |
|
WASHER; PL |
1 |
1706- |
|
FVM |
(C) |
| 196 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 065 |
I8-98325 931-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1811- |
|
FVM |
(C) |
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 073 |
I1-47143 016-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(B) |
| 006 |
I1-47126 713-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 195 |
I1-09589 018-0 |
|
RING; SNAP,CM/SHF |
2 |
1811- |
|
FVM |
(E) |
| 008 |
I8-97524 557-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1811- |
|
FVM |
|
| 003 |
I1-88310 318-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 065 |
I8-97517 193-0 |
|
SPACER; SLACK ADJ,BRK |
1 |
1807- |
|
FVM |
(A) |
| 063 |
I8-98325 927-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
2 |
1706- |
|
FVM |
(A) |
| 083 |
I0-91510 510-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(A) ID=10.2 |
| 001 |
I8-98326 245-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
LEADING |
| 007 |
I1-09732 035-0 |
|
RIVET; LINING,RR BRK |
AR |
1706-1810 |
|
FVM |
L=19.5 |
| 200 |
I0-28050 825-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(B) M8X25 |
| 012 |
I8-97524 550-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 244 |
I8-98316 129-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(A) |
| 076 |
I8-98326 252-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
R |
FVM |
|
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 063 |
I8-98325 927-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
2 |
1706- |
|
FVM |
(A) |
| 084 |
I0-20951 640-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(B) M16X40 |
| 084 |
I8-98327 430-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(A) |
| 253 |
I1-48279 030-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(B) |
| 048 |
I1-09625 228-0 |
|
SEAL; OIL,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 009 |
I8-97524 156-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1811- |
|
FVM |
(B) |
| 049 |
I1-47146 003-1 |
|
BUSHING; CM/SHF,RR BRK |
4 |
1706- |
|
FVM |
(A) |
| 197 |
I0-91510 514-0 |
|
WASHER; LK,BRKT TO CASE |
2 |
1706- |
|
FVM |
ID=14.2 |
| 065 |
I8-97517 211-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1807- |
|
FVM |
(B) |
| 076 |
I8-97517 242-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
R |
FVM |
|
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 045 |
I8-97524 111-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
R |
FVM |
(C) FORWARD |
| 195 |
I8-97524 558-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(C) |
| 079 |
I9-47145 013-0 |
|
BRACKET; CM/SHF |
6 |
1706- |
|
FVM |
(B) |
| 003 |
I1-88311 436-0 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 244 |
I8-98316 130-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(B) |
| 001 |
I8-97524 152-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
TRAILING |
| 076 |
I8-98326 253-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
L |
FVM |
|
| 045 |
I8-97524 112-1 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
L |
FVM |
(C) FORWARD |
| 002 |
I6-88311 463-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) LEADING |
| 009 |
I8-98326 267-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1706-1810 |
|
FVM |
|
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
2 |
1706- |
|
FVM |
M10X16 |
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 025 |
I1-87831 636-0 |
|
COVER SET; RR BRK DRUM |
2 |
1811- |
|
FVM |
|
| 005 |
I1-47125 440-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 005 |
I1-47126 712-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 350 |
I1-48279 060-0 |
|
CLEVIS; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 197 |
I0-91510 514-0 |
|
WASHER; LK,BRKT TO CASE |
2 |
1706- |
|
FVM |
ID=14.2 |
| 202 |
I0-91510 514-0 |
|
WASHER; LK,BRKT |
8 |
1706- |
|
FVM |
ID=14.2 |
| 003 |
I1-88310 320-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 050 |
I8-97524 141-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(A) |
| 002 |
I6-88310 317-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
(IADG) LEADING FWD |
| 253 |
I1-48279 029-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(A) |
| 025 |
I1-47151 487-1 |
|
COVER SET; RR BRK DRUM |
4 |
1706-1810 |
|
FVM |
|
| 050 |
I8-98326 263-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(B) |
| 201 |
I0-20851 440-0 |
|
BOLT; BRKT,POWER CHAMBER |
8 |
1706- |
|
FVM |
M14X40 |
| 017 |
I8-97524 138-0 |
|
SPRING; SHOE HOLD DOWN |
8 |
1811- |
|
FVM |
|
| 005 |
I8-97524 546-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
TRAILING |
| 079 |
I9-47145 013-0 |
|
BRACKET; CM/SHF |
6 |
1706- |
|
FVM |
(B) |
| 045 |
I8-97524 112-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
L |
FVM |
(C) FORWARD |
| 201 |
I0-20851 440-0 |
|
BOLT; BRKT,POWER CHAMBER |
8 |
1706- |
|
FVM |
M14X40 |
| 074 |
I1-48279 078-0 |
|
BUSHING; SLACK ADJ |
3 |
1706- |
|
FVM |
|
| 222 |
I1-47139 173-0 |
|
BOLT; LK,ANCHOR PIN |
1 |
1706- |
|
FVM |
M10X16 |
| 014 |
I1-09744 061-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 050 |
I1-47141 068-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(A) |
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 076 |
I8-97517 242-1 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
R |
FVM |
|
| 001 |
I8-98326 246-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
TRAILING |
| 025 |
I1-87831 636-0 |
|
COVER SET; RR BRK DRUM |
4 |
1811- |
|
FVM |
|
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 195 |
I8-97524 128-0 |
|
RING; SNAP,CM/SHF |
4 |
1811- |
|
FVM |
(B) |
| 306 |
I1-48279 044-0 |
|
BOOT; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 077 |
I1-47146 003-1 |
|
BUSHING |
2 |
1706- |
|
FVM |
|
| 084 |
I0-20951 640-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(B) M16X40 |
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 034 |
I0-90301 410-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
4 |
1706- |
|
FVM |
(B) PT1/8 STRAIGHT |
| 088 |
I1-09589 018-0 |
|
CLIP; BRKT |
2 |
1706- |
|
FVM |
|
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 084 |
I8-98327 430-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(A) |
| 017 |
I8-97524 138-0 |
|
SPRING; SHOE HOLD DOWN |
8 |
1811- |
|
FVM |
|
| 078 |
I1-47146 008-0 |
|
BUSHING; BRKT |
2 |
1811- |
|
FVM |
|
| 073 |
I8-98325 924-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 049 |
I1-47146 011-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1811- |
|
FVM |
(B) |
| 002 |
I1-88310 317-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 222 |
I1-47139 173-0 |
|
BOLT; LK,ANCHOR PIN |
1 |
1706- |
|
FVM |
M10X16 |
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 050 |
I1-47141 067-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(A) |
| 050 |
I1-47141 067-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(A) |
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 002 |
I6-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) TRAILING |
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 034 |
I0-90301 510-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
2 |
1706- |
|
FVM |
(A) PT1/8 ELBOW 67.5 DEGREES |
| 203 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
|
| 082 |
I0-91180 216-0 |
|
NUT |
4 |
1706- |
|
FVM |
(A) M16 |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 065 |
I8-97517 211-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1807- |
|
FVM |
(B) |
| 045 |
I8-97524 112-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
L |
FVM |
(C) FORWARD |
| 005 |
I1-47125 439-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 006 |
I1-47126 713-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 065 |
I8-97517 193-0 |
|
SPACER; SLACK ADJ,BRK |
1 |
1807- |
|
FVM |
(A) |
| 079 |
I8-98326 270-0 |
|
BRACKET; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 073 |
I8-98325 924-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 065 |
I8-98325 931-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1811- |
|
FVM |
(C) |
| 083 |
I1-48279 033-0 |
|
WASHER; PL |
1 |
1706- |
|
FVM |
(C) |
| 045 |
I8-98325 888-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
R |
FVM |
(A) FORWARD |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 045 |
I8-98325 892-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1706-1810 |
|
FVM |
(B) REARWARD |
| 195 |
I8-97524 559-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(D) |
| 200 |
I0-28050 816-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(A) M8X16 |
| 005 |
I1-47126 712-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 076 |
I8-98326 253-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
L |
FVM |
|
| 195 |
I8-97524 558-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(C) |
| 009 |
I8-98326 267-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1706-1810 |
|
FVM |
|
| 034 |
I0-90301 510-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
2 |
1706- |
|
FVM |
(A) PT1/8 ELBOW 67.5 DEGREES |
| 001 |
I8-98326 248-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
TRAILING |
| 196 |
I1-47143 004-0 |
|
DISTANCE; CM/SHF |
1 |
1706- |
|
FVM |
(B) |
| 065 |
I8-97517 193-0 |
|
SPACER; SLACK ADJ,BRK |
1 |
1807- |
|
FVM |
(A) |
| 080 |
I9-09561 340-0 |
|
GASKET; BUSHING |
4 |
1706- |
|
FVM |
ID=39.7 |
| 201 |
I0-20851 440-0 |
|
BOLT; BRKT,POWER CHAMBER |
8 |
1706- |
|
FVM |
M14X40 |
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 244 |
I8-98316 129-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(A) |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 195 |
I8-97524 558-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(C) |
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 001 |
I8-97524 151-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
LEADING |
| 222 |
I1-47139 173-0 |
|
BOLT; LK,ANCHOR PIN |
1 |
1706- |
|
FVM |
M10X16 |
| 244 |
I8-98316 129-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(A) |
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 001 |
I8-98326 248-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
TRAILING |
| 079 |
I8-98326 270-0 |
|
BRACKET; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 006 |
I1-47126 713-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING RWD |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 049 |
I1-47146 009-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1706-1810 |
|
FVM |
(B) |
| 006 |
I1-47125 441-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 045 |
I8-98325 889-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
L |
FVM |
(A) FORWARD |
| 050 |
I1-47141 067-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(A) |
| 155 |
I0-91614 516-0 |
|
WASHER; PL,WHEEL CYL |
4 |
1706- |
|
FVM |
ID=17 |
| 046 |
I1-47143 005-0 |
|
RING; SPACER,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 050 |
I8-97524 143-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(B) |
| 082 |
I0-91110 516-0 |
|
NUT |
2 |
1706- |
|
FVM |
(C) M16 |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 197 |
I0-91510 514-0 |
|
WASHER; LK,BRKT TO CASE |
2 |
1706- |
|
FVM |
ID=14.2 |
| 011 |
I8-97524 125-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1811- |
|
FVM |
(B) |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 001 |
I8-97524 152-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
TRAILING |
| 005 |
I8-97524 545-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
LEADING |
| 011 |
I8-97524 125-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1811- |
|
FVM |
(B) |
| 225 |
I1-48279 031-0 |
|
PIN; SPLIT |
1 |
1706- |
|
FVM |
|
| 199 |
I1-48279 034-0 |
|
NUT |
1 |
1706- |
|
FVM |
|
| 002 |
#REF! |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) LEADING |
| 045 |
I8-98325 892-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1706-1810 |
|
FVM |
(B) REARWARD |
| 002 |
I1-88311 463-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
LEADING |
| 012 |
I8-97524 550-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 001 |
I8-97524 151-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
LEADING |
| 065 |
I1-47143 014-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(B) |
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 002 |
I1-88310 317-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 003 |
I1-88310 318-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 045 |
I8-98325 889-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
L |
FVM |
(A) FORWARD |
| 014 |
I8-97524 552-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 195 |
I1-09589 018-0 |
|
RING; SNAP,CM/SHF |
2 |
1811- |
|
FVM |
(E) |
| 253 |
I1-48279 030-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(B) |
| 195 |
I8-97524 128-0 |
|
RING; SNAP,CM/SHF |
4 |
1811- |
|
FVM |
(B) |
| 084 |
I8-98327 430-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(A) |
| 244 |
I8-98316 130-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(B) |
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 017 |
I8-97524 138-0 |
|
SPRING; SHOE HOLD DOWN |
8 |
1811- |
|
FVM |
|
| 065 |
I8-98325 932-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(A) |
| 200 |
I0-20951 640-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(C) M16X40 |
| 082 |
I0-91110 516-0 |
|
NUT |
2 |
1706- |
|
FVM |
(C) M16 |
| 050 |
I8-98326 263-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(B) |
| 083 |
I1-09503 223-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(B) ID=16.2 |
| 002 |
I1-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
TRAILING |
| 050 |
I1-47141 068-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(A) |
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 065 |
I8-97517 211-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1807- |
|
FVM |
(B) |
| 082 |
I8-98328 346-0 |
|
NUT |
2 |
1706- |
|
FVM |
(B) |
| 002 |
I6-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) TRAILING |
| 079 |
I8-98326 270-0 |
|
BRACKET; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 202 |
I0-91510 514-0 |
|
WASHER; LK,BRKT |
8 |
1706- |
|
FVM |
ID=14.2 |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
2 |
1706- |
|
FVM |
M10X16 |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 003 |
I1-88311 436-0 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 088 |
I1-09589 018-0 |
|
CLIP; BRKT |
2 |
1706- |
|
FVM |
|
| 082 |
I0-91180 216-0 |
|
NUT |
4 |
1706- |
|
FVM |
(A) M16 |
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 001 |
I8-98326 247-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
LEADING |
| 083 |
I0-91510 510-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(A) ID=10.2 |
| 084 |
I0-20951 640-0 |
|
BOLT; BRKT TO CASE |
2 |
1706- |
|
FVM |
(B) M16X40 |
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 073 |
I1-47143 016-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(B) |
| 200 |
I0-20951 640-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(C) M16X40 |
| 200 |
I0-20951 640-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(C) M16X40 |
| 001 |
I8-98326 246-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
TRAILING |
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 197 |
I8-97517 193-0 |
|
WASHER; LK,BRKT TO CASE |
1 |
1807- |
|
FVM |
|
| 350 |
I1-48279 060-0 |
|
CLEVIS; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 155 |
I0-91614 516-0 |
|
WASHER; PL,WHEEL CYL |
4 |
1706- |
|
FVM |
ID=17 |
| 317 |
I1-48279 032-0 |
|
RING; RETAINER |
1 |
1706- |
|
FVM |
|
| 012 |
I1-47113 005-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 008 |
I8-97524 557-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1811- |
|
FVM |
|
| 002 |
I1-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
TRAILING |
| 001 |
I8-98326 248-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
TRAILING |
| 076 |
I8-97517 242-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
R |
FVM |
|
| 050 |
I8-97524 141-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(A) |
| 006 |
I1-47125 441-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 014 |
I1-09744 061-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 002 |
I1-88310 317-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 078 |
I1-47146 008-0 |
|
BUSHING; BRKT |
2 |
1811- |
|
FVM |
|
| 011 |
I1-47131 039-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1706-1810 |
|
FVM |
L=121.5 |
| 065 |
I8-98325 932-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(A) |
| 001 |
I8-98326 247-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
LEADING |
| 196 |
I1-47143 004-0 |
|
DISTANCE; CM/SHF |
1 |
1706- |
|
FVM |
(B) |
| 046 |
I1-47143 005-0 |
|
RING; SPACER,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 203 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
|
| 003 |
I1-88311 436-0 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 045 |
I8-97524 111-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
R |
FVM |
(C) FORWARD |
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 317 |
I1-48279 032-0 |
|
RING; RETAINER |
1 |
1706- |
|
FVM |
|
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 080 |
I9-09561 340-0 |
|
GASKET; BUSHING |
4 |
1706- |
|
FVM |
ID=39.7 |
| 014 |
I8-97524 552-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 074 |
I1-48279 078-0 |
|
BUSHING; SLACK ADJ |
3 |
1706- |
|
FVM |
|
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 074 |
I1-48279 078-0 |
|
BUSHING; SLACK ADJ |
3 |
1706- |
|
FVM |
|
| 082 |
I8-98328 346-0 |
|
NUT |
2 |
1706- |
|
FVM |
(B) |
| 001 |
I8-98326 245-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
LEADING |
| 088 |
I1-09589 018-0 |
|
CLIP; BRKT |
2 |
1706- |
|
FVM |
|
| 012 |
I8-97524 550-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 063 |
I8-98325 928-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
1 |
1706- |
|
FVM |
(B) |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 196 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
(A) |
| 195 |
I1-09589 018-0 |
|
RING; SNAP,CM/SHF |
2 |
1811- |
|
FVM |
(E) |
| 203 |
I8-98326 269-0 |
|
DISTANCE; CM/SHF |
2 |
1706- |
|
FVM |
|
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 050 |
I8-97524 144-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(B) |
| 045 |
I8-98325 888-1 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1706-1810 |
R |
FVM |
(A) FORWARD |
| 008 |
I1-47119 029-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 011 |
I1-47131 039-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1706-1810 |
|
FVM |
L=121.5 |
| 076 |
I8-98326 252-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
R |
FVM |
|
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 080 |
I9-09561 340-0 |
|
GASKET; BUSHING |
4 |
1706- |
|
FVM |
ID=39.7 |
| 050 |
I8-97524 142-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(A) |
| 082 |
I0-91110 516-0 |
|
NUT |
2 |
1706- |
|
FVM |
(C) M16 |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
1 |
1706- |
|
FVM |
M10X16 |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
12 |
1706- |
|
FVM |
M10X12 |
| 155 |
I9-09851 672-2 |
|
WASHER; PL,WHEEL CYL |
4 |
1906- |
|
FVM |
ID=16.2 |
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 012 |
I1-47113 005-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 045 |
I8-97524 115-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1811- |
|
FVM |
(D) REARWARD |
| 009 |
I8-97524 156-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1811- |
|
FVM |
(B) |
| 202 |
I0-91510 514-0 |
|
WASHER; LK,BRKT |
8 |
1706- |
|
FVM |
ID=14.2 |
| 050 |
I8-98326 264-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(B) |
| 200 |
I0-28050 816-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(A) M8X16 |
| 049 |
I1-47146 009-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1706-1810 |
|
FVM |
(B) |
| 005 |
I8-97524 545-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
LEADING |
| 008 |
I1-47119 029-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 050 |
I8-97524 143-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(B) |
| 195 |
I8-97524 128-0 |
|
RING; SNAP,CM/SHF |
4 |
1811- |
|
FVM |
(B) |
| 002 |
I1-88311 463-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
LEADING |
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 197 |
I8-97517 193-0 |
|
WASHER; LK,BRKT TO CASE |
1 |
1807- |
|
FVM |
|
| 200 |
I0-28050 825-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(B) M8X25 |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 253 |
I1-48279 030-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(B) |
| 007 |
I1-09732 035-0 |
|
RIVET; LINING,RR BRK |
AR |
1706-1810 |
|
FVM |
L=19.5 |
| 077 |
I1-47146 003-1 |
|
BUSHING |
2 |
1706- |
|
FVM |
|
| 014 |
I8-97524 552-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1811- |
|
FVM |
|
| 049 |
I1-47146 009-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1706-1810 |
|
FVM |
(B) |
| 050 |
I8-97524 144-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(B) |
| 317 |
I1-48279 032-0 |
|
RING; RETAINER |
1 |
1706- |
|
FVM |
|
| 014 |
I1-09744 061-0 |
|
PIN; CAM ROLLER,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 008 |
I8-97524 557-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1811- |
|
FVM |
|
| 005 |
I1-47125 440-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 050 |
I1-47141 068-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(A) |
| 050 |
I8-97524 142-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(A) |
| 073 |
I1-47143 016-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1706- |
|
FVM |
(B) |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 253 |
I1-48279 029-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(A) |
| 225 |
I1-48279 031-0 |
|
PIN; SPLIT |
1 |
1706- |
|
FVM |
|
| 048 |
I1-09625 228-0 |
|
SEAL; OIL,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 083 |
I1-09503 223-0 |
|
WASHER; PL |
2 |
1706- |
|
FVM |
(B) ID=16.2 |
| 065 |
I1-47143 014-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(B) |
| 050 |
I8-98326 264-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(B) |
| 009 |
I8-98326 267-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1706-1810 |
|
FVM |
|
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1706- |
|
FVM |
|
| 025 |
I1-47151 487-1 |
|
COVER SET; RR BRK DRUM |
2 |
1706-1810 |
|
FVM |
|
| 083 |
I9-09851 672-2 |
|
WASHER; PL |
2 |
1707-1810 |
|
FVM |
(B) ID=16.2 |
| 306 |
I1-48279 044-0 |
|
BOOT; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 200 |
I0-28050 825-0 |
|
BOLT |
4 |
1706- |
|
FVM |
(B) M8X25 |
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
2 |
1706- |
|
FVM |
|
| 199 |
I1-48279 034-0 |
|
NUT |
1 |
1706- |
|
FVM |
|
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 006 |
I1-47125 442-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
1 |
1706- |
|
FVM |
M10X16 |
| 076 |
I8-97517 243-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
L |
FVM |
|
| 009 |
I8-97524 156-0 |
|
SPRING; RETURN,BRK SHOE |
2 |
1811- |
|
FVM |
(B) |
| 049 |
I1-47146 011-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1811- |
|
FVM |
(B) |
| 002 |
I1-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
TRAILING |
| 008 |
I1-47119 029-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 025 |
I1-47151 487-1 |
|
COVER SET; RR BRK DRUM |
2 |
1706-1810 |
|
FVM |
|
| 197 |
I8-97517 193-0 |
|
WASHER; LK,BRKT TO CASE |
1 |
1807- |
|
FVM |
|
| 002 |
I6-88310 317-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
(IADG) LEADING FWD |
| 045 |
I8-97524 115-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1811- |
|
FVM |
(D) REARWARD |
| 076 |
I8-97517 243-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1807- |
L |
FVM |
|
| 002 |
I1-88311 435-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
LEADING RWD |
| 063 |
I8-98325 927-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
2 |
1706- |
|
FVM |
(A) |
| 063 |
I8-98325 928-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
1 |
1706- |
|
FVM |
(B) |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1706- |
|
FVM |
M16 |
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 001 |
I8-97524 151-0 |
|
SHOE; BRK,RR |
2 |
1811- |
|
FVM |
LEADING |
| 079 |
I9-47145 013-0 |
|
BRACKET; CM/SHF |
6 |
1706- |
|
FVM |
(B) |
| 050 |
I8-97524 143-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
FVM |
(B) |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1706- |
|
FVM |
|
| 005 |
I1-47125 440-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 011 |
I8-97524 125-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1811- |
|
FVM |
(B) |
| 065 |
I8-98325 932-0 |
|
SPACER; SLACK ADJ,BRK |
2 |
1706- |
|
FVM |
(A) |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 045 |
I8-98325 892-0 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
2 |
1706-1810 |
|
FVM |
(B) REARWARD |
| 045 |
I8-97524 111-1 |
|
BRACKET; ANCHOR PIN,W/BUSHING |
1 |
1811- |
R |
FVM |
(C) FORWARD |
| 244 |
I8-98316 130-0 |
|
BRACKET; SLACK ADJUSTER |
2 |
1706- |
|
FVM |
(B) |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
1 |
1706- |
|
FVM |
M10X16 |
| 003 |
I1-88310 318-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
LEADING FWD |
| 006 |
I1-47125 442-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1706-1810 |
|
FVM |
TRAILING |
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1706- |
|
FVM |
|
| 078 |
I1-47146 008-0 |
|
BUSHING; BRKT |
2 |
1811- |
|
FVM |
|
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 002 |
I6-88310 317-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1706-1810 |
|
FVM |
(IADG) LEADING FWD |
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 001 |
I8-98326 247-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
R |
FVM |
LEADING |
| 155 |
I9-09851 672-2 |
|
WASHER; PL,WHEEL CYL |
4 |
1906- |
|
FVM |
ID=16.2 |
| 306 |
I1-48279 044-0 |
|
BOOT; SLACK ADJ |
1 |
1706- |
|
FVM |
|
| 001 |
I8-98326 246-1 |
|
SHOE; BRK,RR |
1 |
1706-1810 |
L |
FVM |
TRAILING |
| 005 |
I1-47125 439-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1706-1810 |
|
FVM |
LEADING FWD |
| 077 |
I1-47146 003-1 |
|
BUSHING |
2 |
1706- |
|
FVM |
|
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
M10 |
| 083 |
I1-48279 033-0 |
|
WASHER; PL |
1 |
1706- |
|
FVM |
(C) |
| 083 |
I9-09851 672-2 |
|
WASHER; PL |
2 |
1707-1810 |
|
FVM |
(B) ID=16.2 |
| 196 |
I1-47143 004-0 |
|
DISTANCE; CM/SHF |
1 |
1706- |
|
FVM |
(B) |
| 076 |
I8-98326 252-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
R |
FVM |
|
| 082 |
I8-98328 346-0 |
|
NUT |
2 |
1706- |
|
FVM |
(B) |
| 195 |
I8-97524 559-0 |
|
RING; SNAP,CM/SHF |
16 |
1811- |
|
FVM |
(D) |
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1706- |
|
FVM |
|
| 076 |
I8-98326 253-0 |
|
BRACKET; POWER CHAMBER,RR,W/BUSHING |
1 |
1706-1806 |
L |
FVM |
|
| 199 |
I1-48279 034-0 |
|
NUT |
1 |
1706- |
|
FVM |
|
| 002 |
I6-88311 463-1 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) LEADING |
| 002 |
I6-88311 464-0 |
|
LINING SET; RR BRK,STANDARD |
1 |
1811- |
|
FVM |
(IADG) TRAILING |
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1706- |
|
FVM |
M16 |
| 046 |
I1-47143 005-0 |
|
RING; SPACER,CM/SHF,RR BRK |
2 |
1706- |
|
FVM |
|
| 082 |
I0-91180 216-0 |
|
NUT |
4 |
1706- |
|
FVM |
(A) M16 |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
2 |
1706- |
|
FVM |
|
| 063 |
I8-98325 928-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
1 |
1706- |
|
FVM |
(B) |
| 050 |
I8-98326 264-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
R |
FVM |
(B) |
| 253 |
I1-48279 029-0 |
|
PIN; CLEVIS |
1 |
1706- |
|
FVM |
(A) |
| 050 |
I8-97524 142-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
FVM |
(A) |
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 012 |
I1-47113 005-0 |
|
ROLLER; CAM,BRK SHOE |
4 |
1706-1810 |
|
FVM |
|
| 034 |
I0-90301 410-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
4 |
1706- |
|
FVM |
(B) PT1/8 STRAIGHT |
| 007 |
I1-09732 035-0 |
|
RIVET; LINING,RR BRK |
AR |
1706-1810 |
|
FVM |
L=19.5 |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
4 |
1706- |
|
FVM |
|
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1706- |
|
FVM |
OD=3.7 L=28 |
| 011 |
I1-47131 039-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
4 |
1706-1810 |
|
FVM |
L=121.5 |
| 034 |
I0-90301 410-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
4 |
1706- |
|
FVM |
(B) PT1/8 STRAIGHT |
| 003 |
I1-88310 320-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1706-1810 |
|
FVM |
TRAILING |
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
2 |
1706- |
|
FVM |
|
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1706- |
|
FVM |
|
| 050 |
I8-98326 263-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1706-1810 |
L |
FVM |
(B) |
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1706- |
|
FVM |
|
| 155 |
I9-09851 672-2 |
|
WASHER; PL,WHEEL CYL |
4 |
1906- |
|
FVM |
ID=16.2 |
| 005 |
I8-97524 545-0 |
|
LINING; RR BRK SHOE,STANDARD |
4 |
1811- |
|
FVM |
LEADING |
| 025 |
I1-87831 636-0 |
|
COVER SET; RR BRK DRUM |
2 |
1811- |
|
FVM |
|
