| 062 |
I1-09700 604-0 |
|
CLIP; CLU PIPE |
4 |
1811- |
|
ALL |
(A) ID=8 H=20 L=20 |
| 047 |
I8-98340 200-0 |
|
HOSE; FLEX,CLU CONT |
1 |
1707- |
|
FVZ |
(A) L=410 ; POWER TAKE OFF-FLYWHEEL |
| 104 |
I8-98343 752-A |
|
PIPE; OIL,FLEX HOSE TO CONNECTOR |
1 |
1811- |
|
ALL |
(B) L=2585 |
| 031 |
I0-91180 108-0 |
|
NUT; BRKT |
1 |
1811- |
|
ALL |
M8 FLANGE |
| 048 |
I9-09571 410-0 |
|
GASKET; FLEX HOSE,CLU CONT |
2 |
1811- |
|
ALL |
ID=10.2 OD=16.0 |
| 051 |
I0-91510 512-0 |
|
WASHER; LK |
1 |
1811- |
|
ALL |
ID=12.2 |
| 239 |
I1-09654 141-2 |
|
UNION; CLU HOSE |
1 |
1811- |
|
ALL |
M12 & M14 2WAY |
| 047 |
I1-09363 657-0 |
|
HOSE; FLEX,CLU CONT |
1 |
1707- |
|
ALL |
(B) L=520 |
| 050 |
I0-91111 514-0 |
|
NUT; UNION |
1 |
1811- |
|
ALL |
(B) M14 |
| 115 |
I0-91111 514-0 |
|
NUT; FLEX HOSE,CLU CONT |
1 |
1811- |
|
ALL |
M14 |
| 053 |
I8-98251 345-0 |
|
GASKET; JOINT BOLT |
2 |
1811- |
|
ALL |
ID=14.2 OD=19.2 |
| 054 |
I8-98081 247-0 |
|
BRACKET; AIR,FLEX HOSE |
1 |
1811- |
|
ALL |
|
| 101 |
I8-98072 350-A |
|
HOSE; FLEX,OIL PIPE TO OIL PIPE |
1 |
1811- |
|
ALL |
L=500 |
| 050 |
I0-91111 512-0 |
|
NUT; UNION |
1 |
1811- |
|
ALL |
(A) M12 |
| 129 |
I0-28650 820-0 |
|
BOLT; PIPE CLIP |
1 |
1811- |
|
ALL |
M8X20 FLANGE |
| 049 |
I1-49124 974-A |
|
PIPE; AIR,FLEX HOSE TO CLU BOOSTER |
1 |
1811- |
|
ALL |
|
| 030 |
I0-28650 830-0 |
|
BOLT; BRKT |
1 |
1811- |
|
ALL |
M8X30 FLANGE |
| 184 |
I0-92125 208-0 |
|
UNION; FLEX HOSE |
1 |
1811- |
|
ALL |
M14 ELBOW |
| 062 |
I0-95234 825-0 |
|
CLIP; CLU PIPE |
1 |
1811- |
|
ALL |
(B) ID=9 L=16 |
| 050 |
I9-09840 280-0 |
|
NUT; UNION |
2 |
1811- |
|
ALL |
(C) M12 |
| 009 |
I7-05110 010-A |
|
NUT; BRKT,FLEX HOSE |
2 |
1811- |
|
ALL |
M10 FLANGE |
| 165 |
I0-91180 108-0 |
|
NUT; CLIP,FLEX HOSE |
1 |
1811- |
|
ALL |
M8 FLANGE |
| 004 |
I1-09700 604-0 |
|
CLIP; FLEX HOSE,CLU CONT |
1 |
1811- |
|
ALL |
ID=8 H=20 L=20 |
| 043 |
I0-28650 830-0 |
|
BOLT; BRKT,FLEX HOSE,CLU BOOSTER |
2 |
1811- |
|
ALL |
M8X30 FLANGE |
| 042 |
I8-98309 074-0 |
|
BRACKET; FLEX HOSE,CLU CONT |
1 |
1811- |
|
ALL |
|
| 173 |
I1-09660 873-0 |
|
CONNECTOR |
1 |
1811- |
|
ALL |
DIN8 & M12 STRAIGHT |
| 129 |
I0-28650 830-0 |
|
BOLT; PIPE CLIP |
4 |
1811- |
|
ALL |
M8X30 FLANGE |
| 052 |
I1-09675 086-0 |
|
BOLT; EYE,AIR PIPE |
1 |
1811- |
|
ALL |
M14X27 EYE-BOLT |
| 047 |
I1-09363 630-0 |
|
HOSE; FLEX,CLU CONT |
1 |
1707- |
|
FVZ |
(B) OD=12.7 L=450 ; POWER TAKE OFF-FLYWHEEL |
| 117 |
I0-28650 830-0 |
|
BOLT; CLIP,FLEX HOSE |
1 |
1811- |
|
ALL |
M8X30 FLANGE |
| 044 |
I0-91180 108-0 |
|
NUT; BRKT,FLEX HOSE,CLU BOOSTER |
2 |
1811- |
|
ALL |
M8 FLANGE |
| 104 |
I1-47426 384-0 |
|
PIPE; OIL,FLEX HOSE TO CONNECTOR |
1 |
1811- |
|
ALL |
(A) L=802 |
| 130 |
I0-91180 108-0 |
|
NUT; PIPE CLIP |
5 |
1811- |
|
ALL |
M8 FLANGE |
| 047 |
I8-98072 325-A |
|
HOSE; FLEX,CLU CONT |
1 |
1707- |
|
ALL |
(A) L=470 |
| 025 |
I8-98335 184-0 |
|
BRACKET; OIL PIPE |
1 |
1811- |
|
ALL |
|
| 016 |
I1-09709 278-1 |
|
CLIP; FLEX HOSE |
1 |
1811- |
|
ALL |
ID=10 & 12 |
| 048 |
I6-09571 410-0 |
|
GASKET; FLEX HOSE,CLU CONT |
2 |
1811- |
|
ALL |
(IADG) ID=10.2 OD=16.0 |
| 200 |
I1-87411 006-0 |
|
TUBE; NYLON |
1 |
1811- |
|
ALL |
OD=8 |
