| 026 |
I7-05110 010-A |
|
NUT; BRKT |
4 |
1811- |
|
ALL |
M10 FLANGE ; WB4900MM |
| 029 |
I0-28651 035-0 |
|
BOLT; BRKT TO FRAME |
4 |
1707-1810 |
|
ALL |
(B) M10X35 FLANGE ; WB5400MM , WB7100MM |
| 052 |
I0-91118 408-0 |
|
NUT; WING,COVER FIX |
2 |
1811- |
|
ALL |
M8 WING NUT |
| 043 |
I0-91614 708-0 |
|
WASHER; PL,CLAMP |
2 |
1811- |
|
ALL |
ID=8.4 OD=22 T=2 |
| 030 |
I5-53615 004-B |
|
PLATE; BATTERY |
1 |
1811- |
|
ALL |
|
| 045 |
I9-53616 615-A |
|
ROD; TENSION,BATTERY |
2 |
1811- |
|
ALL |
L=120 |
| 037 |
I8-98162 291-1 |
|
BRACKET; BATTERY |
1 |
1707- |
|
FVZ |
(C) WB4900MM |
| 051 |
I8-97120 747-A |
|
COVER; BATTERY |
1 |
1811- |
|
ALL |
|
| 081 |
I0-91180 108-0 |
|
NUT; BATTERY |
2 |
1811- |
|
ALL |
M8 FLANGE |
| 026 |
I7-05110 010-A |
|
NUT; BRKT |
2 |
1707- |
|
ALL |
M10 FLANGE |
| 035 |
I0-91614 610-0 |
|
WASHER; PL,BATTERY CARRIER |
4 |
1811- |
|
ALL |
ID=10.5 OD=22 |
| 037 |
I8-98362 936-A |
|
BRACKET; BATTERY |
1 |
1811- |
|
GVZ |
(D) |
| 037 |
I8-98361 601-2 |
|
BRACKET; BATTERY |
1 |
1707- |
|
FVZ |
(B) WB4900MM |
| 029 |
I0-28651 035-0 |
|
BOLT; BRKT TO FRAME |
4 |
1811- |
|
GVZ |
(B) M10X35 FLANGE |
| 011 |
I0-28651 035-0 |
|
BOLT; BRKT FIX |
2 |
1707- |
|
FVZ |
M10X35 FLANGE ; WB4900MM |
| 029 |
I0-28051 040-0 |
|
BOLT; BRKT TO FRAME |
4 |
1707- |
|
FVZ |
(A) M10X40 FLANGE ; WB4900MM |
| 037 |
I8-98362 937-A |
|
BRACKET; BATTERY |
1 |
1811- |
|
GVZ |
(E) |
| 037 |
I8-97695 343-A |
|
BRACKET; BATTERY |
1 |
1811- |
|
ALL |
(A) |
