0-30 | WATER PUMP AND CORROSION RESISTOR
GIGA
NEW GIGA GXZ
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 024 | I0-28055 811-0 | BOLT; WATER PUMP | 3 | 1811- | GXZ | (B) M8X110 FLANGE | ||
| 024 | I8-94458 474-1 | BOLT; WATER PUMP | 1 | 1811- | GXZ | (C) M8X53 FLANGE | ||
| 007 | I8-98368 469-0 | PULLEY; WATER PUMP | 1 | 1811- | GXZ | |||
| 054 | I0-28051 025-0 | BOLT; PULLEY | 2 | 1811- | GXZ | (B) M10X25 FLANGE | ||
| 125 | I0-91180 108-0 | NUT; WATER PUMP | 1 | 1811- | GXZ | (A) M8 FLANGE | ||
| 024 | I0-28050 880-0 | BOLT; WATER PUMP | 4 | 1811- | GXZ | (A) M8X80 FLANGE | ||
| 002 | I8-98319 649-0 | PUMP ASM; WATER | 1 | 1811- | GXZ | |||
| 054 | I0-28050 825-0 | BOLT; PULLEY | 2 | 1811- | GXZ | (A) M8X25 FLANGE | ||
| 125 | I0-91180 110-0 | NUT; WATER PUMP | 1 | 1811- | GXZ | (B) M10 FLANGE |
