| 003 |
I1-47126 660-0 |
|
LINING; FRT BRK SHOE,OVER SIZE |
4 |
1811- |
|
GXZ |
TRAILING |
| 030 |
I8-98325 886-0 |
|
BRACKET; ANCHOR,FRT |
1 |
1811- |
|
GXZ |
(A) |
| 002 |
I1-47126 659-0 |
|
LINING; FRT BRK SHOE, STANDARD |
4 |
1811- |
|
GXZ |
TRAILING |
| 030 |
I8-98320 805-0 |
|
BRACKET; ANCHOR,FRT |
1 |
1811- |
|
GXZ |
(B) |
| 014 |
I1-47119 017-1 |
|
PIN; SHOE RETURN SPR |
4 |
1811- |
|
GXZ |
L=73.5 |
| 268 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
2 |
1811- |
|
GXZ |
(B) |
| 045 |
I1-47133 011-0 |
|
WASHER; LK |
2 |
1811- |
|
GXZ |
(B) |
| 053 |
I8-98325 925-0 |
|
ADJUSTER ASM; SLACK |
1 |
1811- |
|
GXZ |
|
| 060 |
I1-09768 060-1 |
|
JOINT; JAW,POWER CHAMBER |
2 |
1811- |
|
GXZ |
|
| 029 |
I1-09583 185-2 |
|
SPRING; RETURN,FRT BRK SHOE |
2 |
1811- |
|
GXZ |
|
| 001 |
I8-98326 239-1 |
|
SHOE; BRK,FRT |
1 |
1811- |
|
GXZ |
LEADING |
| 109 |
I1-47146 003-1 |
|
BUSHING; CM/SHF,FRT BRK |
2 |
1811- |
|
GXZ |
|
| 047 |
I1-47141 051-0 |
|
CAMSHAFT; FRT BRK |
1 |
1811- |
|
GXZ |
|
| 030 |
I8-98325 887-0 |
|
BRACKET; ANCHOR,FRT |
1 |
1811- |
|
GXZ |
(A) |
| 001 |
I8-98326 237-1 |
|
SHOE; BRK,FRT |
1 |
1811- |
|
GXZ |
LEADING |
| 063 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER |
4 |
1811- |
|
GXZ |
M16 FLANGE |
| 050 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
2 |
1811- |
|
GXZ |
|
| 002 |
I1-47125 915-0 |
|
LINING; FRT BRK SHOE, STANDARD |
4 |
1811- |
|
GXZ |
LEADING |
| 031 |
I1-09625 228-0 |
|
SEAL; OIL,CM/SHF |
2 |
1811- |
|
GXZ |
|
| 047 |
I1-47141 052-0 |
|
CAMSHAFT; FRT BRK |
1 |
1811- |
|
GXZ |
|
| 004 |
I6-88311 250-0 |
|
LINING SET; FRT BRK, STANDARD |
1 |
1811- |
|
GXZ |
(IADG) LEADING |
| 004 |
I1-88311 251-0 |
|
LINING SET; FRT BRK, STANDARD |
1 |
1811- |
|
GXZ |
TRAILING |
| 001 |
I8-98326 238-1 |
|
SHOE; BRK,FRT |
1 |
1811- |
|
GXZ |
TRAILING |
| 268 |
I0-28050 816-0 |
|
BOLT; ANCHOR BRKT |
4 |
1811- |
|
GXZ |
(A) M8X16 FLANGE |
| 044 |
I1-47139 173-0 |
|
BOLT; LOCK,ANCHOR PIN |
2 |
1811- |
|
GXZ |
M10X16 |
| 062 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1811- |
|
GXZ |
M16 |
| 007 |
I1-09732 034-0 |
|
RIVET; LINING,FRT BRK |
AR |
1811- |
|
GXZ |
L=18.5 |
| 005 |
I1-88311 253-0 |
|
LINING SET; FRT BRK,OVER SIZE |
1 |
1811- |
|
GXZ |
TRAILING |
| 003 |
I1-47125 916-0 |
|
LINING; FRT BRK SHOE,OVER SIZE |
4 |
1811- |
|
GXZ |
LEADING |
| 056 |
I9-09180 038-0 |
|
CLIP; ANCHOR PIN |
2 |
1811- |
|
GXZ |
|
| 057 |
I0-90301 510-0 |
|
NIPPLE; GREASE,ANCHOR BRKT |
2 |
1811- |
|
GXZ |
PT1/8 ELBOW 67.5 DEGREES |
| 005 |
I1-88311 252-0 |
|
LINING SET; FRT BRK,OVER SIZE |
1 |
1811- |
|
GXZ |
LEADING |
| 004 |
I1-88311 250-0 |
|
LINING SET; FRT BRK, STANDARD |
1 |
1811- |
|
GXZ |
LEADING |
| 133 |
I0-20851 440-0 |
|
BOLT; BRKT |
8 |
1811- |
|
GXZ |
M14X40 |
| 012 |
I1-47113 007-0 |
|
ROLLER; CAM,BRK SHOE |
8 |
1811- |
|
GXZ |
|
| 030 |
I8-98320 804-0 |
|
BRACKET; ANCHOR,FRT |
1 |
1811- |
|
GXZ |
(B) |
| 046 |
I1-47133 005-0 |
|
PLATE; LOCK |
2 |
1811- |
|
GXZ |
|
| 009 |
I1-09744 060-0 |
|
PIN; SHOE HOLDER |
8 |
1811- |
|
GXZ |
|
| 051 |
I8-98325 924-0 |
|
COLLAR; RING,CM/SHF |
2 |
1811- |
|
GXZ |
|
| 043 |
I1-47131 038-0 |
|
PIN; ANCHOR |
4 |
1811- |
|
GXZ |
L=106.5 |
| 053 |
I8-98325 926-0 |
|
ADJUSTER ASM; SLACK |
1 |
1811- |
|
GXZ |
|
| 131 |
I8-98326 250-0 |
|
BRACKET; POWER CHAMBER |
1 |
1811- |
|
GXZ |
|
| 048 |
I1-47143 005-0 |
|
RING; SPACER,CM/SHF |
2 |
1811- |
|
GXZ |
|
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
8 |
1811- |
|
GXZ |
|
| 058 |
I0-81124 028-0 |
|
PIN; SPLIT,JAW JOINT |
2 |
1811- |
|
GXZ |
OD=3.7 L=28 |
| 052 |
I1-47146 003-1 |
|
BUSHING; SLACK ADJ |
2 |
1811- |
|
GXZ |
|
| 270 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
2 |
1811- |
|
GXZ |
M10 |
| 061 |
I1-09744 088-0 |
|
PIN; JAW JOINT,POWER CHAMBER |
2 |
1811- |
|
GXZ |
|
| 059 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1811- |
|
GXZ |
ID=17 OD=32 |
| 054 |
I8-97517 193-0 |
|
SPACER; CM/SHF |
2 |
1811- |
|
GXZ |
|
| 045 |
I0-91510 514-0 |
|
WASHER; LK |
8 |
1811- |
|
GXZ |
(A) ID=14.2 |
| 131 |
I8-98326 251-0 |
|
BRACKET; POWER CHAMBER |
1 |
1811- |
|
GXZ |
|
| 001 |
I8-98326 240-1 |
|
SHOE; BRK,FRT |
1 |
1811- |
|
GXZ |
TRAILING |
