| 006 |
I1-47126 713-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1811- |
|
GXZ |
LEADING RWD |
| 014 |
I1-09744 061-0 |
|
PIN; CAM ROLLER,BRK SHOE |
8 |
1811- |
|
GXZ |
|
| 002 |
I1-88311 435-0 |
|
LINING SET; RR BRK, STANDARD |
1 |
1811- |
|
GXZ |
LEADING FWD |
| 046 |
I1-47143 005-0 |
|
RING; SPACER,CM/SHF,RR BRK |
4 |
1811- |
|
GXZ |
|
| 006 |
I1-47125 442-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
8 |
1811- |
|
GXZ |
TRAILING |
| 065 |
I1-47143 014-0 |
|
SPACER; SLACK ADJ,BRK |
1 |
1811- |
L |
GXZ |
(B) |
| 077 |
I1-47146 003-1 |
|
BUSHING |
2 |
1811- |
|
GXZ |
|
| 080 |
I9-09561 340-0 |
|
GASKET; BUSHING |
4 |
1811- |
|
GXZ |
ID=39.7 |
| 070 |
I0-91111 516-0 |
|
NUT; LK,JAW JOINT |
2 |
1811- |
|
GXZ |
M16 |
| 072 |
I0-81124 028-0 |
|
PIN; SPLIT |
2 |
1811- |
|
GXZ |
OD=3.7 L=28 |
| 001 |
I8-98326 245-1 |
|
SHOE; BRK,RR |
2 |
1811- |
L |
GXZ |
LEADING |
| 049 |
I1-47146 009-0 |
|
BUSHING; CM/SHF,RR BRK |
2 |
1811- |
|
GXZ |
(B) |
| 196 |
I8-98325 931-0 |
|
DISTANCE; CM/SHF |
1 |
1811- |
|
GXZ |
(B) |
| 244 |
I8-98320 862-0 |
|
BRACKET; SLACK ADJUSTER |
4 |
1811- |
|
GXZ |
(B) |
| 048 |
I1-09625 228-0 |
|
SEAL; OIL,CM/SHF,RR BRK |
4 |
1811- |
|
GXZ |
|
| 001 |
I8-98326 248-1 |
|
SHOE; BRK,RR |
2 |
1811- |
R |
GXZ |
TRAILING |
| 049 |
I1-47146 003-1 |
|
BUSHING; CM/SHF,RR BRK |
4 |
1811- |
|
GXZ |
(A) |
| 007 |
I1-09732 035-0 |
|
RIVET; LINING,RR BRK |
AR |
1811- |
|
GXZ |
L=19.5 |
| 063 |
I8-98325 929-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
1 |
1811- |
L |
GXZ |
(B) |
| 050 |
I1-47141 068-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
GXZ |
(A) |
| 203 |
I8-98325 931-0 |
|
DISTANCE; CM/SHF |
1 |
1811- |
|
GXZ |
|
| 083 |
I0-91510 510-0 |
|
WASHER; PL |
4 |
1811- |
|
GXZ |
ID=10.2 |
| 202 |
I0-91510 514-0 |
|
WASHER; LK,BRKT |
8 |
1811- |
|
GXZ |
ID=14.2 |
| 050 |
I8-98326 266-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
R |
GXZ |
(B) |
| 045 |
I8-98325 888-0 |
|
BRACKET; ANCHOR PIN, W/BUSHING |
1 |
1811- |
R |
GXZ |
(A) FORWARD |
| 001 |
I8-98326 247-1 |
|
SHOE; BRK,RR |
2 |
1811- |
R |
GXZ |
LEADING |
| 078 |
I1-47146 008-0 |
|
BUSHING; BRKT |
2 |
1811- |
|
GXZ |
|
| 063 |
I8-98325 927-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
2 |
1811- |
|
GXZ |
(A) |
| 082 |
I8-98328 346-0 |
|
NUT |
4 |
1811- |
|
GXZ |
(B) |
| 001 |
I8-98326 246-1 |
|
SHOE; BRK,RR |
2 |
1811- |
L |
GXZ |
TRAILING |
| 054 |
I1-47133 011-0 |
|
WASHER; LK,ANCHOR PIN,RR BRK |
4 |
1811- |
|
GXZ |
|
| 005 |
I1-47125 439-0 |
|
LINING; RR BRK SHOE, STANDARD |
4 |
1811- |
|
GXZ |
LEADING RWD |
| 045 |
I8-98325 896-0 |
|
BRACKET; ANCHOR PIN, W/BUSHING |
1 |
1811- |
R |
GXZ |
(B) REARWARD |
| 002 |
I6-88310 317-0 |
|
LINING SET; RR BRK, STANDARD |
1 |
1811- |
|
GXZ |
(IADG) LEADING RWD |
| 009 |
I8-98326 267-0 |
|
SPRING; RETURN,BRK SHOE |
4 |
1811- |
|
GXZ |
|
| 003 |
I1-88310 320-1 |
|
LINING SET; RR BRK,OVER SIZE |
2 |
1811- |
|
GXZ |
TRAILING |
| 065 |
I8-97517 193-0 |
|
SPACER; SLACK ADJ,BRK |
1 |
1811- |
|
GXZ |
(A) |
| 076 |
I8-97517 243-0 |
|
BRACKET; POWER CHAMBER, RR,W/BUSHING |
1 |
1811- |
L |
GXZ |
|
| 025 |
I1-47151 487-1 |
|
COVER SET; RR BRK DRUM |
4 |
1811- |
|
GXZ |
|
| 084 |
I8-98327 430-0 |
|
BOLT; BRKT TO CASE |
4 |
1811- |
|
GXZ |
|
| 002 |
I1-88310 319-1 |
|
LINING SET; RR BRK, STANDARD |
2 |
1811- |
|
GXZ |
TRAILING |
| 045 |
I8-98325 889-0 |
|
BRACKET; ANCHOR PIN, W/BUSHING |
1 |
1811- |
L |
GXZ |
(A) FORWARD |
| 008 |
I1-47119 029-0 |
|
PIN; RETURN SPRING,RR BRK SHOE |
7 |
1811- |
|
GXZ |
|
| 222 |
I1-47139 173-0 |
|
BOLT; LK,ANCHOR PIN |
1 |
1811- |
|
GXZ |
M10X16 |
| 066 |
I1-09744 088-0 |
|
PIN; JAW JOINT |
2 |
1811- |
|
GXZ |
|
| 063 |
I8-98325 930-0 |
|
ADJUSTER ASM; SLACK,RR BRK |
1 |
1811- |
R |
GXZ |
(B) |
| 013 |
I9-47119 022-0 |
|
CLIP; ROLLER PIN,BRK SHOE |
8 |
1811- |
|
GXZ |
|
| 079 |
I9-47145 013-0 |
|
BRACKET; CM/SHF |
4 |
1811- |
|
GXZ |
|
| 034 |
I0-90301 510-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
2 |
1811- |
|
GXZ |
(B) PT1/8 ELBOW 67.5 DEGREES |
| 030 |
I1-47159 187-0 |
|
BOLT; DRUM COVER |
24 |
1811- |
|
GXZ |
M10X12 |
| 069 |
I1-09768 060-1 |
|
JOINT; JAW |
2 |
1811- |
|
GXZ |
|
| 071 |
I0-91610 616-0 |
|
WASHER; PL,JAW JOINT |
2 |
1811- |
|
GXZ |
ID=17 OD=32 |
| 027 |
I1-09333 151-0 |
|
COVER; CHECK HOLE,DRUM COVER |
4 |
1811- |
|
GXZ |
|
| 076 |
I8-97517 242-0 |
|
BRACKET; POWER CHAMBER, RR,W/BUSHING |
1 |
1811- |
R |
GXZ |
|
| 195 |
I9-09180 038-0 |
|
RING; SNAP,CM/SHF |
4 |
1811- |
|
GXZ |
|
| 034 |
I0-90301 410-0 |
|
NIPPLE; GREASE,CHAMBER BRKT |
4 |
1811- |
|
GXZ |
(A) PT1/8 STRAIGHT |
| 073 |
I8-98325 924-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1811- |
|
GXZ |
(A) |
| 200 |
I0-20951 640-0 |
|
BOLT |
4 |
1811- |
|
GXZ |
(B) M16X40 |
| 012 |
I1-47113 005-0 |
|
ROLLER; CAM,BRK SHOE |
8 |
1811- |
|
GXZ |
|
| 002 |
I1-88310 317-1 |
|
LINING SET; RR BRK, STANDARD |
1 |
1811- |
|
GXZ |
LEADING RWD |
| 055 |
I1-47133 005-0 |
|
PLATE; LK,RR WHEEL CYL |
4 |
1811- |
|
GXZ |
|
| 201 |
I0-20851 440-0 |
|
BOLT; BRKT,POWER CHAMBER |
8 |
1811- |
|
GXZ |
M14X40 |
| 197 |
I8-97517 193-0 |
|
WASHER; LK,BRKT TO CASE |
1 |
1811- |
|
GXZ |
|
| 244 |
I8-98316 129-0 |
|
BRACKET; SLACK ADJUSTER |
4 |
1811- |
|
GXZ |
(A) |
| 200 |
I0-28050 816-0 |
|
BOLT |
4 |
1811- |
|
GXZ |
(A) M8X16 FLANGE |
| 045 |
I8-98325 895-0 |
|
BRACKET; ANCHOR PIN, W/BUSHING |
1 |
1811- |
L |
GXZ |
(B) REARWARD |
| 005 |
I1-47125 440-0 |
|
LINING; RR BRK SHOE, STANDARD |
8 |
1811- |
|
GXZ |
TRAILING |
| 005 |
I1-47126 712-0 |
|
LINING; RR BRK SHOE, STANDARD |
4 |
1811- |
|
GXZ |
LEADING FWD |
| 067 |
I0-91180 216-0 |
|
NUT; POWER CHAMBER FIX |
4 |
1811- |
|
GXZ |
M16 FLANGE |
| 155 |
I0-91614 516-0 |
|
WASHER; PL,WHEEL CYL |
4 |
1811- |
|
GXZ |
ID=17 |
| 003 |
I1-88310 318-1 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1811- |
|
GXZ |
LEADING RWD |
| 050 |
I8-98326 265-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
GXZ |
(B) |
| 152 |
I8-98011 328-0 |
|
NUT; ANCHOR BRKT |
8 |
1811- |
|
GXZ |
M10 |
| 011 |
I1-47131 039-0 |
|
PIN; ANCHOR,RR WHEEL BRK |
8 |
1811- |
|
GXZ |
L=121.5 |
| 053 |
I1-47139 173-0 |
|
BOLT; LOCK PLATE |
3 |
1811- |
|
GXZ |
M10X16 |
| 052 |
I8-98320 803-0 |
|
BOLT; ANCHOR BRKT |
8 |
1811- |
|
GXZ |
|
| 088 |
I1-09589 018-0 |
|
CLIP; BRKT |
2 |
1811- |
|
GXZ |
|
| 050 |
I1-47141 067-0 |
|
CAMSHAFT; BRK,RR BRK |
1 |
1811- |
L |
GXZ |
(A) |
| 075 |
I1-09620 009-0 |
|
RING; FELT,CM/SHF |
4 |
1811- |
|
GXZ |
|
| 082 |
I8-98316 253-1 |
|
NUT |
2 |
1811- |
|
GXZ |
(A) |
| 073 |
I1-47143 016-0 |
|
COLLAR; FELT RING,CM/SHF |
2 |
1811- |
|
GXZ |
(B) |
| 006 |
I1-47125 441-0 |
|
LINING; RR BRK SHOE,OVER SIZE |
4 |
1811- |
|
GXZ |
LEADING FWD |
| 196 |
I8-97517 210-0 |
|
DISTANCE; CM/SHF |
1 |
1811- |
R |
GXZ |
(A) |
| 003 |
I1-88311 436-0 |
|
LINING SET; RR BRK,OVER SIZE |
1 |
1811- |
|
GXZ |
LEADING FWD |
