0-14 | CAMSHAFT AND VALVE
ELF
NLR NMR
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 112 | I8-97227 074-0 | GEAR, IDLE | 1 | 1512-1804 | 4HG1-T | (C) Z=72-30, ID=30 | ||
| 4 | I6-94395 882-0 | VALVE, INL | 8 | 1807- | 4HL1-TC | (IADG) | ||
| 44 | I0-28050 816-0 | BOLT | 2 | 1512- | 4JB1-TC | (A) M8X16 | ||
| 84 | I8-94152 345-A | BRACKET: ROCKER SHAFT, INTER | 4 | 1512- | 4JB1-TC | |||
| 68 | I8-97210 682-0 | SPRING, VLV | 8 | 1807- | 4HL1-TC | EXHAUST MARK RED | ||
| 57 | I8-94393 131-0 | BOLT, ROCKER ARM BRKT | 3 | 1807- | 4HL1-TC | M10X62 FLANGE | ||
| 5 | I8-97171 399-0 | VALVE, EXH | 4 | 1512- | 4HG1-T | |||
| 71 | I5-12563 001-0 | SEAT, SPR | 8 | 1512- | 4JB1-TC | (D) LOWER OD=34 | ||
| 65 | I5-12565 004-0 | COLLAR, SPLIT | 32 | 1807- | 4HL1-TC | |||
| 78 | I8-97306 424-3 | ARM, ROCKER | 4 | 1807- | 4HL1-TC | EXHAUST | ||
| 68 | I8-98276 958-A | SPRING, VLV | 8 | 1512- | 4JB1-TC | |||
| 102 | I8-94334 681-1 | COVER, IDLE GEAR | 1 | 1512- | 4HG1-T | (A) | ||
| 56 | I9-09180 019-0 | RING, SNAP, ROCKER ARM | 2 | 1512- | 4JB1-TC | ID=17.5 | ||
| 112 | I8-97112 607-1 | GEAR, IDLE | 1 | 1512- | 4HG1-T | (B) Z=41 | ||
| 224 | I0-28050 816-0 | BOLT COVER | 2 | 1512- | 4HG1-T | M8X16 FLANGE | ||
| 53 | I8-97074 617-1 | SHAFT, ROCKER ARM | 1 | 1512- | 4HG1-T | |||
| 106 | I5-12519 002-1 | WASHER, IDLE GEAR SHAFT | 1 | 1512- | 4JB1-TC | ID=13 OD=36 | ||
| 112 | I8-97606 929-0 | GEAR, IDLE | 1 | 1807- | 4HL1-TC | (B) Z=41 | ||
| 206 | I8-97606 768-0 | BUSHING, IDLE GEAR | 1 | 1512- | 4HG1-T | (B) | ||
| 1 | I8-97262 166-0 | CAMSHAFT | 1 | 1807- | 4HL1-TC | |||
| 84 | I8-94388 109-3 | BRACKET, ROCKER SHAFT, INTER | 3 | 1512- | 4HG1-T | |||
| 37 | I8-97386 189-0 | METAL, CM/SHF | 10 | 1512- | 4HG1-T | B=16 | ||
| 101 | I8-94372 221-1 | BOLT, THRUST COLLAR | 1 | 1807- | 4HL1-TC | (A) M14X36.5 | ||
| 5 | I8-97209 876-4 | VALVE, EXH | 8 | 1807- | 4HL1-TC | |||
| 102 | I8-97096 826-A | COVER, IDLE GEAR | 1 | 1807- | 4HL1-TC | (B) OD=51 | ||
| 107 | I8-98060 780-0 | SHAFT, IDLE GEAR | 1 | 1512-1804 | 4HG1-T | (B) | ||
| 111 | I8-97209 728-A | COLLAR, THRUST,IDLE GEAR | 3 | 1807- | 4HL1-TC | (A) ID=14.5 OD=46 | ||
| 72 | I8-97376 720-0 | SEAL, VLV GUIDE | 16 | 1807- | 4HL1-TC | |||
| 87 | I0-28050 835-0 | BOLT, ROCKER SHAFT | 2 | 1512- | 4HG1-T | M8X35 FLANGE | ||
| 267 | I8-98019 024-0 | SENSOR, CAM ANGLE | 1 | 1807- | 4HL1-TC | |||
| 66 | I8-94396 015-2 | CAP, VLV STEM END | 8 | 1512- | 4HG1-T | |||
| 95 | I8-97174 654-0 | SPRING, ROCKER SHAFT | 4 | 1512- | 4HG1-T | |||
| 84 | I8-97174 568-0 | BRACKET, ROCKER SHAFT, INTER | 3 | 1512- | 4HG1-T | |||
| 107 | I8-94334 682-1 | SHAFT, IDLE GEAR | 1 | 1512- | 4HG1-T | (C) | ||
| 117 | I8-97113 167-0 | BOLT, FLANGE | 1 | 1807- | 4HL1-TC | M14X65 FLANGE | ||
| 350 | I8-97369 404-0 | GASKET, SENSOR,CAM ANGLE | 1 | 1807- | 4HL1-TC | ID=14.2 OD=18.8 | ||
| 62 | I9-09844 574-0 | NUT, ADJ SCREW LK BRIDGE | 8 | 1807- | 4HL1-TC | M8 | ||
| 63 | I8-94392 002-3 | BRIDGE | 8 | 1807- | 4HL1-TC | |||
| 95 | I8-94392 999-0 | SPRING, ROCKER SHAFT | 4 | 1807- | 4HL1-TC | |||
| 107 | I8-98163 984-0 | SHAFT, IDLE GEAR | 1 | 1805- | 4HG1-T | (B) | ||
| 101 | I0-23951 425-0 | BOLT, THRUST COLLAR | 1 | 1512- | 4HG1-T | (C) M14X25 | ||
| 37 | I8-97386 189-0 | METAL, CM/SHF | 10 | 1807- | 4HL1-TC | B=16 | ||
| 206 | I8-97606 768-0 | BUSHING, IDLE GEAR | 1 | 1807- | 4HL1-TC | (B) | ||
| 112 | I8-97229 601-0 | GEAR, IDLE | 1 | 1512- | 4JB1-TC | (E) Z=31 | ||
| 9 | I8-97094 440-2 | GEAR, CM/SHF | 1 | 1512- | 4HG1-T | Z=35 | ||
| 305 | I8-98140 110-0 | BEARING, IDLE GEAR | 1 | 1512- | 4JB1-TC | |||
| 109 | I8-97218 780-0 | SHAFT, IDLE GEAR | 1 | 1512- | 4JB1-TC | |||
| 107 | I8-97186 398-1 | SHAFT, IDLE GEAR | 1 | 1512- | 4HG1-T | (A) | ||
| 105 | I0-16956 460-0 | BOLT, IDLE GEAR SHAFT | 1 | 1512- | 4HG1-T | M14X60 | ||
| 107 | I8-97920 007-0 | SHAFT, IDLE GEAR | 1 | 1512- | 4JB1-TC | (E) | ||
| 78 | I8-97074 614-1 | ARM, ROCKER | 4 | 1512- | 4HG1-T | (A) | ||
| 44 | I8-94433 407-0 | BOLT | 1 | 1512- | 4JB1-TC | (B) M12X47 | ||
| 101 | I0-28060 816-0 | BOLT, THRUST COLLAR | 3 | 1807- | 4HL1-TC | (B) M8X16 FLANGE | ||
| 87 | I0-28050 840-0 | BOLT, ROCKER SHAFT | 2 | 1807- | 4HL1-TC | M8X40 FLANGE | ||
| 101 | I8-97223 999-0 | BOLT, THRUST COLLAR | 2 | 1512- | 4JB1-TC | (D) M8X53 FLANGE | ||
| 88 | I8-97071 673-0 | ROD, PUSH | 8 | 1512- | 4JB1-TC | |||
| 7 | I8-94396 439-0 | BOLT, CM/SHF GEAR | 1 | 1512- | 4HG1-T | M14X40 | ||
| 224 | I0-28050 816-0 | BOLT, COVER | 2 | 1807- | 4HL1-TC | M8X16 FLANGE | ||
| 206 | I1-12528 006-0 | BUSHING, IDLE GEAR | 1 | 1512- | 4HG1-T | (A) | ||
| 102 | I8-94334 681-1 | COVER, IDLE GEAR | 1 | 1807- | 4HL1-TC | (A) | ||
| 1 | I8-97077 829-0 | CAMSHAFT | 1 | 1512- | 4HG1-T | |||
| 8 | I9-09851 850-A | WASHER, CM/SHF GEAR | 1 | 1512- | 4HG1-T | ID=14.5 | ||
| 107 | I8-97350 021-A | SHAFT, IDLE GEAR | 1 | 1807- | 4HL1-TC | (D) | ||
| 65 | I5-12565 004-0 | COLLAR, SPLIT | 16 | 1512- | 4JB1-TC | |||
| 45 | I5-12519 002-1 | WASHER, GEAR CAM | 1 | 1512- | 4JB1-TC | ID=13 OD=36 | ||
| 65 | I5-12565 006-0 | COLLAR, SPLIT | 16 | 1512- | 4HG1-T | |||
| 53 | I8-97174 567-0 | SHAFT, ROCKER ARM | 1 | 1512- | 4HG1-T | |||
| 12 | I8-94399 487-0 | KEY, CAM GEAR SET | 1 | 1512- | 4HG1-T | OD=7 L=7.5 | ||
| 81 | I8-94367 526-2 | SCREW, ADJ, ROCKER ARM | 8 | 1512- | 4HG1-T | |||
| 87 | I8-94433 302-0 | BOLT, ROCKER SHAFT | 1 | 1512- | 4JB1-TC | M10X60 | ||
| 107 | I8-94334 682-1 | SHAFT, IDLE GEAR | 1 | 1807- | 4HL1-TC | (C) | ||
| 81 | I8-94395 024-0 | SCREW, ADJ,ROCKER ARM | 8 | 1807- | 4HL1-TC | M10 L=32 | ||
| 112 | I8-97094 546-2 | GEAR, IDLE | 1 | 1512- | 4HG1-T | (A) Z=61 | ||
| 1 | I8-94127 797-A | CAMSHAFT | 1 | 1512- | 4JB1-TC | |||
| 101 | I8-94372 221-1 | BOLT, THRUST COLLAR | 1 | 1512- | 4HG1-T | (A) M14X36.5 | ||
| 71 | I8-94385 029-2 | SEAT, SPR | 8 | 1512- | 4HG1-T | (E) UPPER OD=38 | ||
| 9 | I8-97229 594-2 | GEAR, CM/SHF | 1 | 1512- | 4JB1-TC | Z=42 | ||
| 5 | I6-97209 876-0 | VALVE, EXH | 8 | 1807- | 4HL1-TC | (IADG) | ||
| 71 | I8-94390 783-2 | SEAT, SPR | 16 | 1807- | 4HL1-TC | (A) UPPER OD=32.8 T=12.75 | ||
| 82 | I8-94396 015-2 | CAP, ROCKER SHAFT | 8 | 1807- | 4HL1-TC | |||
| 269 | I0-28050 612-0 | BOLT, SENSOR | 1 | 1807- | 4HL1-TC | M6X12 FLANGE | ||
| 112 | I8-97120 005-1 | GEAR, IDLE | 1 | 1512- | 4HG1-T | (D) Z=34 | ||
| 112 | I8-98021 069-0 | GEAR, IDLE | 1 | 1807- | 4HL1-TC | (C) Z=72-60-30 | ||
| 107 | I8-97186 398-1 | SHAFT, IDLE GEAR | 1 | 1807- | 4HL1-TC | (A) | ||
| 54 | I8-94341 906-0 | WASHER, ROCKER SPR | 6 | 1512- | 4JB1-TC | ID=19.1 OD=23 | ||
| 5 | I8-98277 383-0 | VALVE, EXH | 4 | 1512- | 4JB1-TC | |||
| 83 | I0-91111 510-0 | NUT, ADJ SCREW, LK | 8 | 1512- | 4HG1-T | M10 | ||
| 111 | I8-97209 728-A | COLLAR, THRUST, IDLE GEAR | 4 | 1512- | 4HG1-T | (A) ID=14.5 OD=46 | ||
| 68 | I8-97648 793-A | SPRING, VLV | 8 | 1807- | 4HL1-TC | INLET MARK BLUE | ||
| 4 | I8-97171 398-0 | VALVE, INL | 4 | 1512- | 4HG1-T | |||
| 89 | I8-94438 305-1 | TAPPET, VLV | 8 | 1512- | 4JB1-TC | |||
| 85 | I8-97174 650-0 | BOLT BRKT | 3 | 1512- | 4HG1-T | M10X62 FLANGE | ||
| 206 | I8-97606 770-0 | BUSHING, IDLE GEAR | 1 | 1807- | 4HL1-TC | (C) | ||
| 107 | I8-98163 984-0 | SHAFT, IDLE GEAR | 1 | 1807- | 4HL1-TC | (B) | ||
| 223 | I1-09623 423-0 | GASKET, COVER,IDLE GEAR | 1 | 1807- | 4HL1-TC | ID=105.6 | ||
| 85 | I8-94433 304-0 | BOLT BRKT | 3 | 1512- | 4JB1-TC | M8X15, M10X60 L=82 | ||
| 68 | I8-97023 559-0 | SPRING, VLV | 8 | 1512- | 4HG1-T | ID=28.5 | ||
| 72 | I8-94396 609-2 | SEAL, VLV GUIDE | 8 | 1512- | 4HG1-T | |||
| 14 | I9-08000 718-0 | KEY, CM/SHF | 1 | 1512- | 4JB1-TC | |||
| 95 | I8-94341 905-A | SPRING, ROCKER SHAFT | 3 | 1512- | 4JB1-TC | |||
| 206 | I8-97606 770-0 | BUSHING, IDLE GEAR | 1 | 1512- | 4HG1-T | (C) | ||
| 223 | I1-09623 423-0 | GASKET, COVER, IDLE GEAR | 1 | 1512- | 4HG1-T | ID=105.6 | ||
| 102 | I8-97096 826-A | COVER, IDLE GEAR | 1 | 1512- | 4HG1-T | (B) OD=51 | ||
| 117 | I8-97113 167-0 | BOLT, FLANGE | 1 | 1512- | 4HG1-T | M14X65 FLANGE | ||
| 104 | I8-94109 706-1 | BOLT, SHAFT IDLE | 1 | 1512- | 4JB1-TC | M12X67 | ||
| 105 | I0-16956 460-0 | BOLT, IDLE GEAR SHAFT | 1 | 1807- | 4HL1-TC | M14X60 | ||
| 107 | I8-97350 021-A | SHAFT, IDLE GEAR | 1 | 1908- | 4HG1-T | (D) | ||
| 53 | I8-97036 197-0 | SHAFT, ROCKER ARM | 1 | 1512- | 4JB1-TC | |||
| 8 | I9-09851 850-A | WASHER, CM/SHF GEAR | 1 | 1807- | 4HL1-TC | ID=14.5 | ||
| 81 | I8-94152 283-A | SCREW, ADJ, ROCKER ARM | 8 | 1512- | 4JB1-TC | M8 L=30 | ||
| 71 | I8-94133 731-2 | SEAT, SPR | 8 | 1512- | 4JB1-TC | (C) UPPER OD=32.8 | ||
| 95 | I8-94397 263-0 | SPRING, ROCKER SHAFT | 4 | 1512- | 4HG1-T | |||
| 83 | I0-91111 510-0 | NUT, ADJ SCREW,LK | 8 | 1807- | 4HL1-TC | M10 | ||
| 213 | I5-87311 136-0 | METAL KIT, CM/SHF | 1 | 1512- | 4HG1-T | |||
| 12 | I8-94399 487-0 | KEY, CAM GEAR SET | 1 | 1807- | 4HL1-TC | OD=7 L=7.5 | ||
| 7 | I8-94396 439-0 | BOLT, CM/SHF GEAR | 1 | 1807- | 4HL1-TC | M14X40 | ||
| 96 | I8-97334 414-0 | BRACKET, ROCKER ARM SHAFT | 3 | 1807- | 4HL1-TC | |||
| 112 | I8-97120 005-1 | GEAR, IDLE | 1 | 1807- | 4HL1-TC | (D) Z=34 | ||
| 61 | I8-94394 803-0 | SCREW, ADJ,BRIDGE | 8 | 1807- | 4HL1-TC | M8X21 | ||
| 72 | I8-97120 307-0 | SEAL, VLV GUIDE | 8 | 1512- | 4JB1-TC | |||
| 113 | I8-98140 217-0 | GEAR, IDLE | 1 | 1512- | 4JB1-TC | Z=37 | ||
| 83 | I9-09111 508-A | NUT, ADJ SCREW, LK | 8 | 1512- | 4JB1-TC | M8 | ||
| 78 | I8-94152 344-A | ARM, ROCKER | 8 | 1512- | 4JB1-TC | (C) | ||
| 112 | I8-94395 109-4 | GEAR, IDLE | 1 | 1805- | 4HG1-T | (C) Z=72-30, ID=39.8 | ||
| 85 | I8-94393 131-0 | BOLT BRKT | 4 | 1512- | 4HG1-T | M10X62 FLANGE | ||
| 55 | I9-12626 005-0 | PLUG, ROCKER SHAFT END | 2 | 1512- | 4JB1-TC | |||
| 78 | I8-97014 258-2 | ARM, ROCKER | 4 | 1512- | 4HG1-T | (B) | ||
| 4 | I8-94464 921-2 | VALVE, INL | 4 | 1512- | 4JB1-TC | |||
| 53 | I8-97389 921-0 | SHAFT, ROCKER ARM | 1 | 1807- | 4HL1-TC | |||
| 206 | I8-98021 070-0 | BUSHING, IDLE GEAR | 1 | 1807- | 4HL1-TC | (A) | ||
| 9 | I8-98018 935-3 | GEAR, CM/SHF | 1 | 1807- | 4HL1-TC | Z=35 | ||
| 78 | I8-97306 421-3 | ARM, ROCKER | 4 | 1807- | 4HL1-TC | INLET | ||
| 86 | I9-09164 510-0 | WASHER, ROCKER ARM FIX | 4 | 1512- | 4JB1-TC | ID=10.5 | ||
| 101 | I0-28060 816-0 | BOLT, THRUST COLLAR | 3 | 1512- | 4HG1-T | (B) M8X16 FLANGE | ||
| 71 | I8-94391 468-0 | SEAT, SPR | 16 | 1807- | 4HL1-TC | (B) LOWER ID=14.3 T=1.0 | ||
| 71 | I8-94399 526-1 | SEAT, SPR | 8 | 1512- | 4HG1-T | (F) LOWER ID=14.3 OD=40 | ||
| 10 | I8-94110 480-1 | PLATE, THRUST | 1 | 1512- | 4JB1-TC | |||
| 111 | I1-12535 030-1 | COLLAR, THRUST,IDLE GEAR | 1 | 1807- | 4HL1-TC | (B) ID=14.5 OD=59 | ||
| 101 | I0-23951 425-0 | BOLT, THRUST COLLAR | 1 | 1807- | 4HL1-TC | (C) M14X25 | ||
| 112 | I8-97606 767-0 | GEAR, IDLE | 1 | 1807- | 4HL1-TC | (A) Z=61 | ||
| 111 | I8-94141 937-1 | COLLAR, THRUST, IDLE GEAR | 1 | 1512- | 4JB1-TC | (C) | ||
| 4 | I8-94395 882-2 | VALVE, INL | 8 | 1807- | 4HL1-TC |
