0-33 | FAN AND FAN BELT
ELF
NLR NMR
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 182 | I0-28650 835-0 | BOLT, BRKT | 2 | 1807- | 4HL1-TC | M8X35 | ||
| 109 | I8-97049 577-1 | STUD, FAN CLU | 4 | 1807- | 4HL1-TC | M8X13.5 L=22 | ||
| 24 | I0-28080 818-0 | BOLT, FAN | 4 | 1807- | 4HL1-TC | M8X18 | ||
| 88 | I0-91614 708-0 | WASHER, PL ADJ PLATE | 1 | 1512- | 4JB1-TC | ID=8.4 OD=22 | ||
| 8 | I8-97129 735-0 | CLUTCH, COOLING FAN | 1 | 1512- | 4JB1-TC | |||
| 8 | I8-97139 299-0 | CLUTCH, COOLING FAN | 1 | 1512- | 4HG1-T | |||
| 230 | I8-97140 854-1 | FAN, COOL ING | 1 | 1512- | 4HG1-T | |||
| 38 | I8-97108 643-0 | SPACER, FAN | 1 | 1512- | 4HG1-T | |||
| 26 | I8-94389 764-0 | BOLT, FAN TO CLU | 4 | 1512- | 4JB1-TC | |||
| 80 | I8-97249 636-0 | PLATE, ADJ | 1 | 1807- | 4HL1-TC | |||
| 24 | I0-28080 818-0 | BOLT, FAN | 4 | 1512- | 4HG1-T | M8X18 | ||
| 109 | I0-41010 618-0 | STUD, FAN CLU | 4 | 1512- | 4JB1-TC | M6X18 L=27 | ||
| 38 | I8-97108 643-0 | SPACER, FAN | 1 | 1807- | 4HL1-TC | |||
| 13 | I0-91180 108-0 | NUT, COOLING FAN | 4 | 1512- | 4HG1-T | M8 | ||
| 36 | I2-97014 252-1 | BELT, COOLING FAN | 1 | 1807- | 4HL1-TC | 1 SET= 2 PIECE (8971801810) | ||
| 96 | I0-50540 825-0 | BOLT, ADJ PLATE | 1 | 1512- | 4JB1-TC | (B) M8X25 | ||
| 71 | I8-97011 792-4 | BOLT, ADJNPLATE, GEN | 1 | 1512- | 4HG1-T | M8X40 | ||
| 1 | I8-97129 769-2 | FAN, COOLING | 1 | 1512- | 4JB1-TC | OD=410 | ||
| 1 | I8-98270 107-1 | FAN, COOLING | 1 | 1807- | 4HL1-TC | |||
| 14 | I0-91180 108-0 | NUT, FAN TO CLU | 4 | 1807- | 4HL1-TC | M8 | ||
| 26 | I0-28050 612-0 | BOLT, FAN TO CLU | 4 | 1512- | 4HG1-T | M6X12 | ||
| 230 | I8-98246 761-0 | FAN, COOLING | 1 | 1807- | 4HL1-TC | |||
| 13 | I8-98049 362-0 | NUT, COOLING FAN | 4 | 1512- | 4JB1-TC | M6 | ||
| 93 | I0-28651 025-0 | BOLT, ADJ PLATE BRKT | 1 | 1512- | 4HG1-T | M10X25 | ||
| 96 | I0-28050 845-0 | BOLT, ADJ PLATE | 1 | 1512- | 4JB1-TC | (A) M8X45 | ||
| 230 | I6-97140 854-0 | FAN, COOL ING | 1 | 1512- | 4HG1-T | (IADG) | ||
| 8 | I8-98019 743-0 | CLUTCH, COOLING FAN | 1 | 1807- | 4HL1-TC | MXR | ||
| 36 | I2-97014 252-1 | BELT, COOLING FAN | 1 | 1512- | 4HG1-T | 1 SET= 2 PIECE (8971801810) | ||
| 8 | I8-98273 482-0 | CLUTCH, COOLING FAN | 1 | 1807- | 4HL1-TC | |||
| 80 | I8-97172 415-0 | PLATE, ADJ | 1 | 1512- | 4HG1-T | |||
| 1 | I8-97141 195-2 | FAN, COOLING | 1 | 1512- | 4HG1-T | OD=430 | ||
| 26 | I8-94389 764-0 | BOLT, FAN TO CLU | 4 | 1807- | 4HL1-TC | |||
| 109 | I8-97049 577-1 | STUD, FAN CLU | 4 | 1512- | 4HG1-T | M8X13.5 L=22 | ||
| 230 | I8-97094 660-0 | FAN, COOL ING | 1 | 1512- | 4JB1-TC | |||
| 95 | I8-97037 510-0 | BRACKET, ADJ PLATE | 1 | 1512- | 4HG1-T | |||
| 182 | I0-28650 835-0 | BOLT, BRKT | 3 | 1512- | 4HG1-T | M8X35 | ||
| 82 | I7-05110 010-A | NUT, ADJ PLATE | 1 | 1512- | 4HG1-T | |||
| 81 | I8-97257 223-0 | PIECE, SLIDING | 1 | 1807- | 4HL1-TC | |||
| 36 | I8-97043 551-B | BELT, COOLING FAN | 1 | 1512- | 4JB1-TC | L=1041 MITSUBOSHI | ||
| 80 | I8-97080 556-2 | PLATE, ADJ | 1 | 1512- | 4JB1-TC | |||
| 86 | I8-97172 720-1 | BOLT, ADJ | 1 | 1807- | 4HL1-TC | M8X130 | ||
| 230 | I8-98190 058-0 | FAN, COOLING | 1 | 1807- | 4HL1-TC | MXR |
