| 9 |
I8-97039 777-1 |
|
GASKET, TURBOCHARGER TO EXH DUCT |
1 |
1807- |
|
4HL1-TC |
|
| 1 |
I8-98388 224-0 |
|
TURBOCHARGER ASM |
1 |
1512- |
|
4JB1-TC |
|
| 9 |
I8-97039 777-1 |
|
GASKET, TURBOCHARGER TO EXH DUCT |
1 |
1512- |
|
4HG1-T |
|
| 143 |
I8-98133 350-0 |
|
CLIP, HOSE,TURBOCHARGER OUTLET |
1 |
1807- |
|
4HL1-TC |
(B) ID=65-85 |
| 131 |
I8-94394 671-0 |
|
GASKET, OIL PIPE,C/BL |
1 |
1807- |
|
4HL1-TC |
ID=30 |
| 217 |
I8-94368 563-1 |
|
BOLT, BRKT |
1 |
1807- |
|
4HL1-TC |
(D) M8X18 |
| 18 |
I8-97161 607-0 |
|
NUT, EXH PIPE |
4 |
1512- |
|
4JB1-TC |
M8 |
| 66 |
I0-44011 025-0 |
|
STUD, EXH PIPE |
3 |
1512- |
|
4HG1-T |
|
| 7 |
I8-94174 537-0 |
|
WASHER, PL, BKRT |
1 |
1512- |
|
4HG1-T |
ID=8 OD=18 T=3 |
| 115 |
I8-98261 645-0 |
|
PIPE, WATER , TURBOCHARGER OUT |
1 |
1512- |
|
4HG1-T |
|
| 16 |
I8-97178 487-A |
|
ADAPTER, EXH PIPE |
1 |
1512- |
|
4HG1-T |
|
| 16 |
I8-97178 487-A |
|
ADAPTER, EXH PIPE |
1 |
1807- |
|
4HL1-TC |
|
| 178 |
I0-41010 625-0 |
|
STUD, DUCT |
4 |
1512- |
|
4HG1-T |
M6X25 L=34 |
| 14 |
I8-97019 477-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
2 |
1512- |
|
4HG1-T |
(A) M8X94 L=108 |
| 14 |
I8-97019 477-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
2 |
1807- |
|
4HL1-TC |
(A) M8X94 L=108 |
| 389 |
I8-98366 895-A |
|
PIPE, INL,TURBOCHARGER TO CAC |
1 |
1807- |
|
4HL1-TC |
|
| 137 |
I8-98213 680-0 |
|
PIPE, WATER,TURBOCHARGER IN |
1 |
1807- |
|
4HL1-TC |
|
| 2 |
I8-97315 266-0 |
|
GASKET, TURBOCHARGER TO EXH MANI |
1 |
1512- |
|
4JB1-TC |
|
| 66 |
I0-44011 025-0 |
|
STUD, EXH PIPE |
3 |
1807- |
|
4HL1-TC |
M10X25 L=40 |
| 9 |
I8-97139 726-0 |
|
GASKET, TURBOCHARGER TO EXH DUCT |
1 |
1512- |
|
4JB1-TC |
|
| 162 |
I5-09000 275-0 |
|
BOLT, ADAPTER |
1 |
1807- |
|
4HL1-TC |
M8X57 |
| 391 |
I8-97221 061-0 |
|
BRACKET, WATER PIPE |
1 |
1512- |
|
4HG1-T |
(B) |
| 231 |
I6-97209 950-0 |
|
HOSE, RUBBER, TURBOCHARGER OUT |
1 |
1807- |
|
4HL1-TC |
(IADG) |
| 71 |
I8-98346 108-0 |
|
HOSE, INLET PIPE TO TURBOCHARGER |
1 |
1807- |
|
4HL1-TC |
(B) |
| 117 |
I9-09571 414-0 |
|
GASKET, WATER PIPE |
2 |
1807- |
|
4HL1-TC |
(B) ID=14.2 OD=20 |
| 130 |
I0-50540 616-0 |
|
BOLT, OIL PIPE TO TURBOCHARGER D |
2 |
1512- |
|
4HG1-T |
M6X16 |
| 204 |
I8-97214 384-1 |
|
COLLAR, PIPE ADAPTER |
1 |
1807- |
|
4HL1-TC |
|
| 116 |
I8-98037 827-0 |
|
BOLT, WATER PIPE |
1 |
1807- |
|
4HL1-TC |
(B) M14X30 EYE-BOLT |
| 66 |
I8-97032 977-1 |
|
STUD, EXH PIPE |
2 |
1512- |
|
4JB1-TC |
M10X45 L=60 |
| 26 |
I8-97202 328-A |
|
GASKET, DUCT |
1 |
1807- |
|
4HL1-TC |
ID=47 |
| 135 |
I0-28050 820-0 |
|
BOLT, OIL PIPE TO C/BL |
2 |
1807- |
|
4HL1-TC |
M8X20 |
| 133 |
I8-98261 657-0 |
|
PIPE, OIL DRAIN, TURBOCHAARGER |
1 |
1512- |
|
4HG1-T |
|
| 116 |
I8-98037 827-0 |
|
BOLT, WATER PIPE |
1 |
1512- |
|
4HG1-T |
(A) M14X30 |
| 133 |
I8-97484 294-0 |
|
PIPE, OIL DRAIN, TURBOCHARGER |
1 |
1807- |
|
4HL1-TC |
|
| 14 |
I8-97019 478-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
3 |
1512- |
|
4HG1-T |
(B) M8X49 L=63 |
| 1 |
I8-98213 669-3 |
|
TURBOCHARGER ASM |
1 |
1807- |
|
4HL1-TC |
|
| 332 |
I8-98218 562-1 |
|
DUCT, AIR,TURBOCHARGER |
1 |
1807- |
|
4HL1-TC |
|
| 11 |
I8-97161 607-0 |
|
NUT, TURBOCHARGER |
4 |
1512- |
|
4JB1-TC |
M8 |
| 288 |
I0-28151 016-0 |
|
BOLT, WATER PIPE CLIP |
1 |
1512- |
|
4HG1-T |
(B) M10X16 |
| 391 |
I8-97210 078-A |
|
BRACKET, WATER PIPE |
1 |
1512- |
|
4HG1-T |
(A) |
| 288 |
I0-28050 812-A |
|
BOLT, WATER PIPE CLIP |
1 |
1512- |
|
4HG1-T |
(A) M8X12 |
| 217 |
I0-28050 670-0 |
|
BOLT, BRKT |
1 |
1807- |
|
4HL1-TC |
(B) M6X70 |
| 14 |
I8-97378 067-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
2 |
1512- |
|
4JB1-TC |
(D) M8X43 L=54 |
| 130 |
I0-50540 616-0 |
|
BOLT, OIL PIPE TO TURBOCHARGER DRAIN |
2 |
1807- |
|
4HL1-TC |
M6X16 W/LK WASHER |
| 288 |
I0-28050 816-0 |
|
BOLT, WATER PIPE CLIP |
1 |
1807- |
|
4HL1-TC |
(B) M8X16 |
| 135 |
I0-28050 820-0 |
|
BOLT, OIL PIPE TO C/BL |
2 |
1512- |
|
4HG1-T |
M8X20 |
| 1 |
I8-98254 714-0 |
|
TURBOCHARGER ASM |
1 |
1512- |
|
4HG1-T |
|
| 71 |
I8-97221 914-3 |
|
HOSE, INLET PIPE TO TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
(A) |
| 14 |
I8-97019 478-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
3 |
1807- |
|
4HL1-TC |
(B) M8X49 L=63 |
| 33 |
I8-97108 669-0 |
|
BOLT, HEAT PROTECTOR |
4 |
1807- |
|
4HL1-TC |
M6X12 |
| 71 |
I6-97217 911-0 |
|
HOSE, INLET PIPE TO TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
(IADG) (B) |
| 71 |
I8-98367 471-A |
|
HOSE, INLET PIPE TO TURBOCHARGER |
1 |
1807- |
|
4HL1-TC |
(A) |
| 116 |
I8-98037 067-0 |
|
BOLT, WATER PIPE |
2 |
1807- |
|
4HL1-TC |
(A) M14X31 EYE-BOLT |
| 19 |
I8-97061 401-1 |
|
NUT, EXH PIPE,TURBOCHARGER |
5 |
1807- |
|
4HL1-TC |
M8 |
| 21 |
I0-28050 812-A |
|
BOLT, PIPE |
1 |
1807- |
|
4HL1-TC |
M8X12 |
| 217 |
I0-28050 630-0 |
|
BOLT, BRKT |
1 |
1807- |
|
4HL1-TC |
(A) M6X30 |
| 143 |
I8-98133 348-0 |
|
CLIP , HOSE, TURBOCHARGER OUTLATE |
2 |
1512- |
|
4HG1-T |
ID=45.65 |
| 288 |
I0-28050 812-A |
|
BOLT, WATER PIPE CLIP |
1 |
1807- |
|
4HL1-TC |
(A) M8X12 |
| 182 |
I0-91180 106-0 |
|
NUT, DUCT |
1 |
1807- |
|
4HL1-TC |
M6 |
| 137 |
I8-98213 680-0 |
|
PIPE, WATER, TURBOCHARGER IN |
1 |
1512- |
|
4HG1-T |
|
| 162 |
I5-09000 275-0 |
|
BOLT, ADAPTER |
1 |
1512- |
|
4HG1-T |
M8X57 |
| 12 |
I8-97378 060-0 |
|
STUD, TURBOCHARGER |
4 |
1512- |
|
4JB1-TC |
M8X20 L=31 |
| 148 |
I0-03559 300-0 |
|
HOSE, TURBOCHARGER, INL |
1 |
1512- |
|
4JB1-TC |
L= 180 |
| 143 |
I8-98133 348-0 |
|
CLIP, HOSE,TURBOCHARGER OUTLET |
2 |
1807- |
|
4HL1-TC |
(A) ID=45-65 |
| 231 |
I8-97209 950-A |
|
HOSE, RUBBER, TURBOCHARGER OUT |
1 |
1807- |
|
4HL1-TC |
|
| 7 |
I8-94174 537-0 |
|
WASHER, PL,BRKT |
1 |
1807- |
|
4HL1-TC |
ID=8 OD=18 T=3 |
| 117 |
I9-09571 414-0 |
|
GASKET, WATER PIPE |
6 |
1512- |
|
4HG1-T |
ID=14.2 OD=20.0 |
| 231 |
I8-97209 950-A |
|
HOSE, RUBBER, TURBOCHARGER |
1 |
1512- |
|
4HG1-T |
|
| 115 |
I8-98213 681-4 |
|
PIPE, WATER,TURBOCHARGER OUT |
1 |
1807- |
|
4HL1-TC |
|
| 252 |
I0-28050 812-A |
|
BOLT, BRKT |
1 |
1512- |
|
4HG1-T |
M8X12 |
| 173 |
I8-97178 497-2 |
|
PROTECTOR, HEAT,FUEL PIPE |
1 |
1807- |
|
4HL1-TC |
|
| 178 |
I0-41010 630-0 |
|
STUD, DUCT |
1 |
1807- |
|
4HL1-TC |
M6X30 L=38 |
| 231 |
I6-97209 950-0 |
|
HOSE, RUBBER, TURBOCHARGER |
1 |
1512- |
|
4HG1-T |
(IADG) |
| 117 |
I8-98251 345-0 |
|
GASKET, WATER PIPE |
2 |
1807- |
|
4HL1-TC |
(A) ID=14.2 OD=19.2 |
| 423 |
I0-41010 620-0 |
|
STUD, WATER PIPE |
1 |
1512- |
|
4JB1-TC |
M6X20 L=28 |
| 16 |
I8-97192 332-0 |
|
ADAPTER, EXH PIPE |
1 |
1512- |
|
4JB1-TC |
|
| 389 |
I8-97216 223-0 |
|
PIPE, INL, TURBOCHARGER TO CAC |
1 |
1512- |
|
4JB1-TC |
|
| 231 |
I8-97212 155-0 |
|
HOSE, RUBBER, TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
|
| 33 |
I8-97108 669-0 |
|
BOLT, HEAT PROTECTOR |
4 |
1512- |
|
4HG1-T |
M6X12 |
| 131 |
I8-94394 671-0 |
|
GASKET, OIL PIPE, C/BL |
1 |
1512- |
|
4HG1-T |
ID=30 |
| 19 |
I8-94170 486-0 |
|
NUT, EXH PIPE, TURBOCHARGER |
5 |
1512- |
|
4HG1-T |
M8 |
| 14 |
I8-97200 763-0 |
|
STUD, TURBOCHARGER TO EXH PIPE |
2 |
1512- |
|
4JB1-TC |
(C) M8X126 L=137 |
| 118 |
I8-94221 519-0 |
|
CLIP, WATER HOSE |
2 |
1512- |
|
4HG1-T |
ID=15.5 |
| 217 |
I0-28050 830-0 |
|
BOLT, BRKT |
1 |
1807- |
|
4HL1-TC |
(C) M8X30 |
| 231 |
I6-97212 155-0 |
|
HOSE, RUBBER, TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
(IADG) |
| 204 |
I8-97214 384-1 |
|
COLLAR, PIPE ADAPTER |
1 |
1512- |
|
4HG1-T |
|
| 31 |
I8-98227 651-1 |
|
BRACKET, INL DUCT,HEAT PROTECTOR |
1 |
1807- |
|
4HL1-TC |
|
| 143 |
I8-98133 347-0 |
|
CLIP , HOSE, TURBOCHARGER OUTLATE |
4 |
1512- |
|
4JB1-TC |
ID=40-50 |
| 118 |
I8-94221 519-0 |
|
CLIP, WATER HOSE |
2 |
1807- |
|
4HL1-TC |
ID=15.5 |
| 116 |
I8-98037 067-0 |
|
BOLT, WATER PIPE |
2 |
1512- |
|
4HG1-T |
(B) |
| 291 |
I0-91180 108-0 |
|
NUT, PIPE TO BRKT |
1 |
1512- |
|
4HG1-T |
M8 |
| 136 |
I8-98251 345-0 |
|
GASKET, WATER PIPE |
2 |
1807- |
|
4HL1-TC |
ID=14.2 OD=19.2 |
| 71 |
I8-97217 911-4 |
|
HOSE, INLET PIPE TO TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
(B) |
| 173 |
I8-97178 497-2 |
|
PROTECTOR, HEAT, FUEL PIPE |
1 |
1512- |
|
4HG1-T |
|
