| 38 |
I8-94227 500-0 |
|
COVER, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 41 |
I1-15749 493-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.40 |
| 41 |
I1-15748 011-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.80 |
| 73 |
I8-97211 797-0 |
|
WASHER, DRIVE GEAR, INJ PUMP |
4 |
|
|
4HG1-T |
|
| 41 |
I1-15749 393-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=1.00 |
| 48 |
I8-97214 493-0 |
|
PIN, ROLLER HOLDER, TIMER, INJ PUM |
1 |
|
|
4JB1-TC |
|
| 40 |
I8-97383 765-0 |
|
GASKET, TIMER COVER, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 35 |
I8-98283 548-0 |
|
SPRING, TIMER, OUTER, INJ PUMP |
4 |
|
|
4HG1-T |
|
| 20 |
I1-15749 396-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.50 |
| 28 |
I8-94172 269-0 |
|
CAM, INNER, ECCENTRIC, TIMER, INJ P |
2 |
|
|
4HG1-T |
|
| 38 |
I8-97085 037-0 |
|
COVER, TIMER, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 41 |
I8-94227 499-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=1.20 |
| 20 |
I8-94174 746-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
1 |
|
|
4JB1-TC |
|
| 33 |
I8-97085 026-0 |
|
SEAT, OUTER SPRING, TIMER, INJ PUM |
4 |
|
|
4HG1-T |
|
| 20 |
I1-15749 397-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=1.00 |
| 46 |
I8-94227 488-0 |
|
CLIP, HOLDER PIN, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 41 |
I1-15748 012-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.90 |
| 44 |
I8-97085 040-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.14 |
| 34 |
I8-98283 549-0 |
|
SPRING, TIMER, INNER, INJ PUMP |
4 |
|
|
4HG1-T |
|
| 44 |
I8-97085 044-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=1.10 |
| 51 |
I8-94227 671-0 |
|
GASKET, TIMING SENSOR, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 52 |
I8-94343 307-0 |
|
SENSOR, TIMING, TACHOMETER, INJ PU |
1 |
|
|
4JB1-TC |
|
| 43 |
I8-97231 931-0 |
|
SPRING, PISTON, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
L=42.0 |
| 44 |
I8-97085 039-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.12 |
| 44 |
I8-97085 047-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=1.70 |
| 44 |
I8-97085 042-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.18 |
| 41 |
I8-94227 495-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=0.60 |
| 41 |
I1-15749 390-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.10 |
| 22 |
I8-97085 026-0 |
|
SEAT, INNER SPRING, TIMER, INJ PUM |
4 |
|
|
4HG1-T |
|
| 58 |
I8-98283 546-0 |
|
FLYWEIGHT ASM, TIMER, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 41 |
I8-94227 497-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=0.90 |
| 44 |
I8-97085 043-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.90 |
| 41 |
I1-15749 392-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.50 |
| 6 |
I8-97223 409-0 |
|
FLANGE, DRIVE GEAR, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 70 |
I8-97085 032-0 |
|
SHIM, FLANGE, TIMER |
AR |
|
|
4HG1-T |
T=0.20 |
| 20 |
I1-15749 394-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.10 |
| 70 |
I8-97085 036-0 |
|
SHIM, FLANGE, TIMER |
AR |
|
|
4HG1-T |
T=0.80 |
| 70 |
I8-97085 035-0 |
|
SHIM, FLANGE, TIMER |
AR |
|
|
4HG1-T |
T=0.50 |
| 36 |
I8-97085 029-0 |
|
PIN, PILOT, TIMER SPRING, INJ PUMP |
2 |
|
|
4HG1-T |
|
| 44 |
I8-97085 045-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=1.30 |
| 50 |
I8-97218 961-0 |
|
SLIDER, TIMER PISTON, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 70 |
I8-97085 034-0 |
|
SHIM, FLANGE, TIMER |
AR |
|
|
4HG1-T |
T=0.40 |
| 44 |
I8-97085 041-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.16 |
| 23 |
I1-15749 144-0 |
|
NUT, TIMER FLANGE, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 26 |
I8-97223 399-0 |
|
FLANGE, TIMER, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 20 |
I1-15749 495-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.40 |
| 47 |
I8-94227 487-0 |
|
PIN, HOLDER PIN, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 41 |
I8-94227 496-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=0.70 |
| 70 |
I8-97085 033-0 |
|
SHIM, FLANGE, TIMER |
AR |
|
|
4HG1-T |
T=0.30 |
| 43 |
I8-97231 930-0 |
|
SPRING, PISTON, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
L=41.7 |
| 8 |
I8-97223 410-0 |
|
BOLT, DRIVE GEAR FIX, INJ PUMP |
4 |
|
|
4HG1-T |
|
| 32 |
I1-15749 159-0 |
|
RING, SNAP, SPRING SEAT, TIMER, INJ |
4 |
|
|
4HG1-T |
|
| 42 |
I1-15749 185-0 |
|
RING, SNAP, TIMER COVER, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 20 |
I1-15749 395-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.30 |
| 29 |
I8-97085 030-0 |
|
CAM, OUTER, ECCENTRIC, TIMER, INJ P |
2 |
|
|
4HG1-T |
|
| 20 |
I1-15749 496-0 |
|
SHIM, INNER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.70 |
| 49 |
I8-97231 928-0 |
|
PISTON, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
|
| 15 |
I8-98283 547-0 |
|
FLYWEIGHT, TIMER, INJ PUMP |
2 |
|
|
4HG1-T |
|
| 43 |
I8-97231 929-0 |
|
SPRING, PISTON, TIMER, INJ PUMP |
1 |
|
|
4JB1-TC |
L=44.0 |
| 41 |
I1-15748 010-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.60 |
| 41 |
I8-94121 620-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=2.40 |
| 25 |
I1-15749 145-0 |
|
WASHER, LK, TIMER FLANGE, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 72 |
I1-15749 205-0 |
|
RING, SNAP, FLANGE TIMER |
1 |
|
|
4HG1-T |
|
| 41 |
I1-15749 391-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.30 |
| 44 |
I8-97085 038-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=0.10 |
| 3 |
I8-98269 497-0 |
|
GEAR, DRIVE, INJ PUMP |
1 |
|
|
4HG1-T |
|
| 41 |
I1-15749 494-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4HG1-T |
T=0.70 |
| 41 |
I8-94227 498-0 |
|
SHIM, OUTER SPRING, TIMER, INJ PUM |
AR |
|
|
4JB1-TC |
T=1.00 |
| 44 |
I8-97085 046-0 |
|
SHIM, TIMER COVER, INJ PUMP |
AR |
|
|
4HG1-T |
T=1.50 |
| 31 |
I8-97231 933-0 |
|
SCREW, TIMER COVER, INJ PUMP |
2 |
|
|
4JB1-TC |
|
| 1 |
I8-98272 999-0 |
|
TIMER ASM, INJ PUMP |
1 |
|
|
4HG1-T |
|
