| Key |
PART NO |
ITC |
DESCRIPTION |
QTY |
APP DATE |
LR |
MODEL |
REMARKS |
|
|
|
|
|
|
|
|
|
| 8 |
I8-98321 326-1 |
|
COVER ASM, ACL |
1 |
1512- |
|
ALL |
|
| 94 |
I8-98257 847-0 |
|
VALVE, VACUATOR |
1 |
1512- |
|
4JB1-TC |
|
| 54 |
I8-98317 829-1 |
|
BRACKET, ACL |
1 |
1512- |
|
4JB1-TC |
WB 3300MM |
| 54 |
I8-98317 829-1 |
|
BRACKET, ACL |
1 |
1512- |
|
4HG1-T |
|
| 196 |
I0-28651 035-0 |
|
BOLT, BRKT, ACL |
4 |
1512- |
|
ALL |
M10X35 |
| 94 |
I8-98486 969-0 |
|
VALVE, VACUATOR |
1 |
1807- |
|
4HL1-TC |
|
| 224 |
I0-91180 110-0 |
|
NUT, BRKT |
4 |
1512- |
|
ALL |
M10 |
| 53 |
I0-91180 108-0 |
|
NUT, ACL |
4 |
1512- |
|
ALL |
M8 |
| 6 |
I8-98321 413-A |
|
FILTER, ACL |
1 |
1512- |
|
ALL |
(IADG) |
| 1 |
I8-98321 353-1 |
|
CLEANER ASM, AIR |
1 |
1512- |
|
ALL |
|
| 54 |
I8-98317 830-0 |
|
BRACKET, ACL |
1 |
1512- |
|
4JB1-TC |
WB 2400MM |
| 54 |
I8-98317 829-1 |
|
BRACKET, ACL |
1 |
1807- |
|
4HL1-TC |
|
| 4 |
I8-98321 327-0 |
|
GASKET, COVER TO BODY |
1 |
1512- |
|
ALL |
|
| 94 |
I8-98257 847-0 |
|
VALVE, VACUATOR |
1 |
1512- |
|
4HG1-T |
|
| 6 |
I8-98321 413-0 |
|
FILTER, ACL |
1 |
1512- |
|
ALL |
|
